Product catalog summary

Regulations for Workplace Safety
The document outlines OSHA regulation (29 CFR 1910.147) for controlling hazardous energy during machine maintenance. Key requirements include disconnecting energy sources and locking them to prevent reactivation.

Pneumatic Energy Control

Shut-off Valve: Each equipment must have a shut-off valve to isolate it from its air supply.
Lockable Valve: The valve should be lockable with a padlock.
Pressurized Air: Must be relieved by exhausting to the atmosphere.
Tagout vs. Lockout: Tagout can replace lockout if it provides equivalent safety.

ROSS L-O-X® and EEZ-ON® Products
These products comply with OSHA and EN 1037 regulations, providing shut-off control, lockability, and exhaust functions. The L-O-X®/EEZ-ON® valve combines shut-off and soft start functions.

Affected Parties
Approximately 631,000 businesses, mainly in manufacturing and servicing, are affected. Equipment operators and service personnel are at high risk.

Benefits
The regulation aims to protect 39 million workers, potentially preventing 120 deaths and 60,000 injuries annually.

Implementation
Requires energy isolation devices capable of being locked in the "off" position, formal de-energizing procedures, and employee training.

ROSS L-O-X®/EEZ-ON® Valves
These valves offer shut-off certainty and gradual pressurization, designed for easy installation and cost efficiency.

Overview
The document provides technical specifications and operational procedures for ROSS valve models, designed for controlling air flow in pneumatic systems.

Specifications

Ambient Temperature: 40 to 120°F (4 to 50°C).
Media Temperature: 40 to 175°F (4 to 80°C).
Flow Media: Filtered air with a 5-micron filter recommended.
Inlet Pressure: 15 to 150 psig (1 to 10 bar).
Port Threads: NPT standard, with options for parallel G threads.

Valve Operation

L-O-X® Valves: Feature a red handle for visibility, allowing quick shut-off and exhaust of downstream air.
EEZ-ON® Valves: Allow gradual pressure build-up before full flow.
Solenoid Pilot Valves: Enable remote control of air flow.

Model Numbers & Dimensions
Lists various valve models with port sizes, flow coefficients, dimensions, and weights.

Installation and Safety

Ensure electrical supply is off and the pneumatic system is exhausted before servicing.
Installation and servicing should be performed by trained personnel.

Key Features

Quick response due to poppet construction.
Capability to integrate with silencers for noise reduction.
Energy isolation devices, not emergency stop devices.

Installation and Maintenance
Regular checks and maintenance are essential. Overhauled or serviced valves require functional testing before installation.

Product Specifications
ROSS products must be used within specified limits, and only ROSS parts should be used for repairs.

Filtration and Lubrication
Air systems should have a 5-micron filter. Use compatible lubricants to avoid damage.

Air Flow Restrictions
Avoid restricting air flow to prevent erratic valve action. Silencers must have adequate flow capacity.

Power Presses
Pneumatically controlled machinery must use a press control double valve with a monitoring device for safety.

Energy Isolation
ROSS L-O-X® products are energy isolation devices, not emergency stop devices.

Accessories
ROSS MUFFL-AIR® silencers reduce noise with minimal back pressure.

Warranty
ROSS products are warranted against defects for one year. Misuse or improper maintenance voids the warranty.

Catalog excerpts

he Occupational Safety and Health Administration (OSHA) regulation (29 CFR 1910.147) details safety requirements for the control of hazardous energyduring the maintenance and servicing of machines and equipment. f your company uses pneumatically-controlled equip-ment, or if you are a manufacturer of pneumatically operated equipment, OSHA rules can have a substantialeffect on your business. As an employer, compliance may involve modifications to the air control systems for equipment in your plant. As a manufacturer, the new machines or equipment you deliver should include lockout-and-ex- haust...

Open the catalog to page 2

The L-O-X /EEZ-ON ή valve combines shut-off certainty with gradual pressurization upon start-up. Special labels and adjustment screw indicates EEZ-ON VALVE CLOSED With a short push of the blue handleinward, the flow of supply is blockedand downstream air is exhaustedvia the exhaust port at the bottom ofthe valve. It is required by OSHA thatthe L-O-X 213213 > function. ή /EEZ-ON > valve bepadlocked in this position to preventthe handle from being pulled outward inadvertently when potential forhuman injury exists or servicing ma-chinery. 3/8 - 3/43/4 - 1-1/4 > EEZ-ON > Ү VALVE FUNCTION With the...

Open the catalog to page 4

ADJUSTING NEEDLE INLET PRESSURE REMOVED AIR PRESSURE TO INLET VALVE OPENS TO FULL FLOW When inlet pressure is removed, the exhausting downstream air pressure keeps the inlet poppet open until the downstream pressure drops by approxi- mately 90 percent. The remaining pres- sure is exhausted via the delay orifice. When air pressure is first applied to the inlet, air flow to the piston is restricted by the adjustable needle in the delay orifice. Downstream air pressure gradu- ally builds up at a rate determined by the setting of the adjustable needle. When downstream air pressure reaches approximately...

Open the catalog to page 8

DimensionsModel inches (mm) Weight NumbersWidthLengthThicknesslb. (kg) Model Number 356A30 5500A40033.0 (1.4)3.0 (1.4).4 (.18).3 (.11) For use with any ROSS model with L-O-X > capability. > A AB DimensionsPortNPTModelAverage inches (mm) Weight Size*ThreadsNumbersC > v ABlb. (kg) > B Male Pipe Threads 1/2Male5500A40037.01.3 (32)3.8 (96).3 (.11)3/45500A5003151.2 (.54)1Male5500A6003182.0 (51)5.6 (142)1.1 (.51) For ports 1/8through 1-1/4Ԕ Female Pipe Threads For ports 1-1/4through 2-1/2ԔROSS MUFFL-AIR 1-1/45500A701318.9 (.42) 1-1/2Female5500A8001382.5 (64)5.9 (149)1.2 (.54) > 8. Do not restrict the...

Open the catalog to page 11

Customer Service- 1-800-GET-ROSS Technical Service- 1-888-TEK-ROSS ROSS/FLEX Service- 1-888-ROSS-FLX Robert-Bosch-Stra bbbbb e 2D-63225 Langen, Germany Telephone (011) 49-6103-7597-0 Fax (011) 49-6103-7469-4 St. James Road, BrackleyNorthamptonshire NN13 7XY United Kingdom Telephone (011) 44-1280-706668 Fax (011) 44-1280-705630 10209-5 Tana, Sagamihara-shiKanagawa 229-1124, Japan Telephone (011) 81-427-78-7251 Fax (011) 81-427-78-7256 Room 701, Taiji Building, No. 33.1249 Street Xikang Rood Shanghai, China Telephone (011) 021-6298-5123 Fax (011) 021-6299-0529 Sao Paulo Telephone (011) 55-11-9916-3296...
