Catalog excerpts
With Roland machines, I can combine modern technology with high-skill handwork to create designs nobody has been able to make before.ӔBringing rapid prototyping into your jewellery business gives you the possibility of having jobs nished a lot faster.Ӕ Kristian Saarikorpi Designer, Finland www.saarikorpidesign. >
Open the catalog to page 2our next piece Produce complex wax models with clockwork precision e ry in four eps > Design jewellery digitally with JewelStudio software, or scan your hand drawn sketches and trace them in the software.Create a digital model in a couple of minutes and render the design for your clients approval. The JWX-30 carves the wax master, without need of your supervision. The wax master can be used to produce the nal piece, or to create a master model for lager scale production. Square Clamps (Small/Large) 1. Double-sided index cut 2. Rotary cut 3. Complete Swivel Clamp 1. Four-sided index cut 2....
Open the catalog to page 3Roland JewelStudio, the jewellery design software for the JWX-30, has been developed speci cally for jewellery designers and goldsmiths. With JewelStudio you can digitize your hand drawn sketches or create original digital designs in a quick and intuitive way by following simple step-by-step instructions, without limiting your creativity. Moreover, you can tilt and rotate the on-screen model as if you are holding a real model in your hands. In this way, you can review every aspect of your design and present it to your client. This gives you the possibility to modify and nalize designs...
Open the catalog to page 4The JWX-30 is a complete, fast and versatile solution for the production of jewellery wax masters. The modelling machine quickly produces a wide variety of wax models for rings, pendants, bracelets, brooches, earrings and cuinks. It also automates laborious tasks such as rescaling, duplicating, replicating left and right earrings and reducing model weight. With the JWX-30, you can devote more time to your creative work while increasing the number of highly protable complex wax master models. Pin-sharp accuracy, consistency and reliability are the keywords. >
Open the catalog to page 5Cuttable materialModelling waxLoadable workpiece weight1.9 kg (including the weight of jig) Maximum angle of rotation18ї10 > 5 (б5000 rotations)X, Y, and Z operation strokesX, Y, and Z: 305 x 205 x 100 mm X-, Y-, and Z-axis drive systemStepping motor Operating speedX and Y axes: 0.1 to 60 mm/sec. ; Z axis: 0.1to 30 mm/sec. ; A axis: 11.25rpm Software resolutionX, Y and Z axis: 0.01mm/step, A axis: 0.0225 Mechanical resolutionX and Y axis: 0.00125 mm/step (micro-step control) ; Z axis: 0.00125 mm/step (micro-step control) ; A axis: 0.0028125а (micro-step control)Spindle motorBrushless DC...
