Metal Printers MPX-80

Metal Printers MPX-80

Metal Printers MPX-80

Product catalog summary
Specifications:
The MPX-80 Photo Impact Printer is compatible with materials such as gold, silver, copper, platinum, brass, aluminum, iron, and stainless steel, provided the Vickers hardness of the surface is 200 or less. It can handle materials up to 100 mm in width and height, and 40 mm in thickness. The printing area is 80 mm x 80 mm, with resolutions varying from 529 dpi for high resolution to 1058 dpi for vector graphics. The printer supports both unidirectional and bidirectional printing, with speeds ranging from 16 mm/sec for vector to 50 mm/sec for photos. Connectivity is via USB, and it operates with a dedicated AC adapter, consuming approximately 15 W of power. The device is designed to operate in environments between 10 to 30 °C and 35 to 80% humidity.
Procedures:
The MPX-80 is designed for ease of use, requiring no special training. Users can connect it to a computer via USB and start printing using the METAZAStudio software, which supports various file formats and allows for creative text and design manipulation. The device includes a center vise and adhesive pad for securing items during printing.
Norms and Certifications:
The printer is ISO 14001:2004 and ISO 9001:2000 certified, reflecting Roland's commitment to environmental protection and quality improvement. The company emphasizes reducing organic solvents, recycling waste, and using recycled products.
Recommendations:
For optimal output quality, periodic maintenance of critical components is recommended. Users should contact their Roland dealer for details. The printer is ideal for creating personalized gifts and awards, making it suitable for jewelry stores and mall kiosks.
Additional Information:
The MPX-80 comes with an AC adapter, power cord, test print material, USB cable, CD-ROM, user’s manual, and software guide. Roland reserves the right to change specifications without notice, and users are responsible for complying with copyright laws when scanning three-dimensional shapes.
See more

Catalog excerpts

Metal Printers MPX-80-1

Gifts and Awardswith Lasting Impact >

 Open the catalog to page 1
Metal Printers MPX-80-2

he MPX-80 Photo Impact Printer quickly turnsordinary gifts and promotional items into cherished mementos. Create individualized gifts forany special occasion, from weddings and anniversaries to birthdays and graduations. Produce one-of-a-kind jewelry featuring family photos of children and pets. Add impact to business events with unique personalized awards. >

 Open the catalog to page 2
Metal Printers MPX-80-3

The MPX-80 quickly and easily adds text, photos, logos and illustrations to a wide variety of items from souvenirs and plaques tocharms and pendants. The desktop devices advanced cartridge strikes metal surfaces*1 with high speed and precision, leaving durable photographic impressions of your original design. The MPX-80 removes no material and operates quietly, making it ideal for jewelry stores, mall kiosks and stationery stores. *1 The MPX-80 imprints on a variety of materials including platinum, gold, silver, brass, stainless steel, aluminum and acrylic. Some shapes can not be imprinted. A...

 Open the catalog to page 3
Metal Printers MPX-80-4

Printable material Gold, silver, copper, platinum, brass, aluminium, iron, and stainless steel, etc.(Vickers hardness [HV] of the printing surface must be 200 or less.) Loadable material size Maximum 100 mm (width) x 100 mm (height) x 40 mm (thickness)(3-15/16 in. x 3-15/16 in. x 1-9/16 in.) 20 mm (12/16 in.) thick with center vise Printing area 80 mm x 80 mm (3-1/8 in. x 3-1/8 in.) Resolution High resolution: 529 dpi, photo: 353 dpi, text: 265 dpi, vector: 1058 dpi Printing direction Unidirectional printing or bidirectional printing (selectable with Windows driver) Printing speed (Default) Photo:...

 Open the catalog to page 4
