ROL d.o.o.
Alpa metrology

Alpa metrology

Product catalog summary

Company Overview
ALPA, established in 1943, is renowned for its Italian quality in manufacturing measuring instruments for the mechanical industry. The company offers high-quality products that adhere to the highest industry standards and provides a qualified technical service.

Catalogue Overview
The catalogue includes over 3500 items, ranging from simple bench tools to advanced Coordinate Measuring Machines (CMMs), providing solutions for diverse needs.

Brand Evolution
ALPA has evolved from a local manufacturer to an international entity in the metrological field, known for reliability and simplicity in technology.

Product Development
Products are developed based on detailed market analysis and customer experiences, ensuring precision, repeatability, and reliability. ALPA offers high-tech instruments that are easy to use.

Training Services
ALPA offers training courses both in classrooms and on-site, with options for tailored courses using online platforms.

Calibration Services
ALPA provides various calibration tools and certificates according to UNI EN ISO 9000, VISION 2000, ACCREDIA, and UKAS standards.

Logistics
In 2017, ALPA opened a new logistics facility with a 30,000 m2 automated warehouse, ensuring 24-hour delivery for most catalogue items.

Research & Development
ALPA offers a range of 3D machines with intuitive software, suitable for production environments. The R&D team is available to find solutions for specific needs.

Events and Connectivity
ALPA participates in major trade fairs and offers connectivity solutions like Bluetooth and wired options to meet modern measurement tracking needs.

Technical Specifications
The catalogue includes detailed technical specifications for various products, such as digital calipers with IP67 protection, ensuring high resistance to dust and liquids.

Technical Specifications Overview:

IP67 Preset Digital Caliper: Designed for internal/external grooves with an accuracy of ±0.02 mm and a resolution of 0.01 mm. Features include Swiss-made electronics, dust and water protection, zero setting at any position, and interchangeable threaded caps. Specific models come with hardened pins of different diameters.
Digital Caliper with Interchangeable Tips: Offers an accuracy of ±0.05 mm and a resolution of 0.01 mm. It includes an ON/OFF button, zero setting, and a locking screw. Different tips are available separately.
Internal Groove Vernier Caliper: Provides an accuracy of ±0.04 mm and a resolution of 0.05 mm. Made of stainless steel with a matt chrome finish and a locking screw.
IP67 Preset Ring Joint Digital Caliper: Features an accuracy of ±0.03 mm and a resolution of 0.01 mm. It is protected against dust and water, with Swiss electronics and a locking screw.
Long Jaws Vernier Caliper: Designed for external measurements with an accuracy of ±0.04 mm and a resolution of 0.05 mm. It includes long jaws and a locking button.
Gear Tooth Digital Caliper: Offers an accuracy of ±0.04 mm and a resolution of 0.01 mm. Made of stainless steel with hardened measuring surfaces and fine adjustment capabilities.
IP54 Preset Universal Digital Caliper with Dial Gauge: Provides an accuracy of ±0.02 mm and a resolution of 0.01 mm. It is dust and water-resistant, with interchangeable threaded caps and a dial gauge.

Accessories:

Various connection cables (OPTO-USB, OPTO-RS232).
Battery options include 3V CR2032 and 1.5V LR44.
Proximity connectors for RS232 and USB.

General Recommendations:

Ensure proper calibration and zero setting before use.
Use appropriate adapters and tips for specific measurement needs.
Regular maintenance and battery checks are recommended for optimal performance.

Overview: The document is a technical catalogue detailing various types of micrometers, their specifications, and features. It includes digital micrometers with different protection ratings, resolutions, and functionalities, as well as traditional micrometers with mechanical counters and interchangeable anvils.

1. Digital Micrometers:

IP67 Digital Micrometer: Features include a resolution of 0.001 mm, automatic wake-up and sleep modes, Bluetooth data transmission, and a spindle feed of 1 mm per thimble revolution. It is protected against dust and water.
IP65 Digital Micrometer: Offers similar resolution and protection against dust and liquids. It includes an ABS function for returning to the absolute scale and has a painted frame with hard metal contact surfaces.

2. Traditional Micrometers:

Micrometer with Counter: Features a resolution of 0.01 mm, a painted frame, and a mechanical digit counter for quick reading.
External Micrometer: Available in various ranges with a resolution of 0.01 mm, featuring a ratchet friction thimble and a painted frame.

3. Specialized Micrometers:

Interchangeable Anvils Micrometer: Comes with 7 types of anvils and is protected against dust and water. It has a resolution of 0.001 mm.
Disk Micrometer: Designed for gear measurement, with a resolution of 0.001 mm and a non-rotating spindle.

4. Calibration Services: ALPA offers calibration certificates according to UNI EN ISO 9000 and VISION 2000 standards, as well as ACCREDIA and UKAS certificates.

Key Specifications:

Resolution: Ranges from 0.001 mm to 0.01 mm depending on the model.
Accuracy: Varies by model and range, with specific tolerances provided for each.
Protection: IP65 and IP67 ratings indicate resistance to dust and water.

Conclusion: The catalogue provides comprehensive details on a range of micrometers suitable for various precision measurement tasks, highlighting their technical specifications, protective features, and calibration options.

Technical Specifications Overview

This document provides detailed specifications for various types of micrometers, focusing on their measurement ranges, accuracy, and specific features. The micrometers are designed for precision measurement tasks and are categorized based on their specific applications and design features.

1. General Specifications

Resolution: Most micrometers have a resolution of 0.001 mm, with some offering 0.01 mm.
Accuracy: Varies by model, typically ranging from ±0.002 mm to ±0.007 mm.
Frame: Painted and designed to be dust and water-resistant (IP65 rating).
Contact Surfaces: Made from hardened materials like carbide for durability.

2. Types of Micrometers

a. Pointed Anvil Micrometers

Available with 15° and 30° pointed anvils.
Used for measuring small grooves and features.

b. Blade Micrometers

Feature blade measuring surfaces for narrow grooves.
Non-rotating spindle design.

c. Spherical Contact Micrometers

Designed for measuring tube thickness.
Interchangeable spherical tips available for different applications.

d. External Thread Micrometers

Equipped with anvils for measuring pitch diameter of threads.
Available for metric and UN thread standards.

e. V-Anvil Micrometers

Used for measuring the outside diameter of cutting tools with multiple flutes.

f. Internal Micrometers

Designed for internal measurements with tungsten carbide tipped contacts.

3. Additional Features

Most models include features like automatic power off, absolute and incremental measurement modes, and zero setting functions.
Power Source: Typically powered by a 1.5V LR44 battery.

4. Applications

These micrometers are suitable for precision engineering tasks, including gear measurement, thread inspection, and tool diameter verification.

5. Key Considerations

Selection of the appropriate micrometer depends on the specific measurement task, required accuracy, and environmental conditions.

Technical Specifications Overview:
The document provides detailed specifications for various types of micrometers used in precision measurement. These include snap micrometers, wire micrometers, disk sheet metal micrometers, depth micrometers, and three-point bore gauges. Each type is designed for specific measurement tasks, such as measuring wires, sheet metal thickness, or internal diameters.

Key Features:

Snap Micrometers: Available with IP54 protection, these are ideal for measuring cylindrical workpieces and have a resolution of 0.001 mm.
Wire Micrometers: Specially designed for measuring wires and spheres with a resolution of 0.01 mm.
Disk Sheet Metal Micrometers: Suited for measuring metal sheet thickness with a resolution of 0.01 mm.
Depth Micrometers: Available with IP65 protection, these micrometers are dust and water-resistant, featuring interchangeable rods for a wider measurement range.
Three-Point Bore Gauges: Designed for internal measurements with a resolution of 0.01 mm, these gauges come with setting rings and extension rods.

Product Range and Accuracy:
The document lists various models with their respective measurement ranges and accuracies. For example, the BB04025 model has a range of 0 to 25 mm with an accuracy of ±0.003 mm.

Manufacturing and Quality Assurance:
The Bowers Group, known for high-quality precision measuring equipment, manufactures these tools. The company emphasizes simplicity in design and use, ensuring high accuracy and repeatability. Continuous investment in manufacturing processes has improved precision and reduced production times.

Additional Features:

Some micrometers come with Bluetooth connectivity for digital data transfer.
Various models are equipped with non-rotating spindles and laser-engraved graduations for enhanced measurement accuracy.

Conclusion:
The document serves as a comprehensive catalogue for precision measuring tools, highlighting the technical specifications, applications, and manufacturing excellence of the Bowers Group.

Technical Specifications Overview:
The document provides detailed specifications for various measuring instruments, including electronic and analogue thickness gauges, micrometer holders, anvils sets, and depth indicators. These instruments are designed for precise measurements in various applications, such as thickness measurement of materials like leather, paper, and metal, as well as thread pitch measurement.

Key Instruments and Features:

Electronic Thickness Gauges: These gauges feature a Digimatic data output, with a standard measuring range of 12 mm and accuracy of ±20 µm. They are available with special measuring inserts and a measuring range of 25 mm upon request.
Analogue Thickness Gauges: These include models with monoblock light alloy frames and jewel bearings, offering high precision and shockproof mechanisms. They are suitable for continuous measurements and come with various contact point options.
Micrometer Holders: These stands are made from cast iron with interchangeable clamps, designed to hold micrometers securely during measurements.
Anvils Set for Thread Pitch: These sets are available for both Metric 60° and Whitworth 55° threads, providing a range of sizes for accurate thread measurement.
Depth Indicators: Both digital and analogue models are available, with features such as hardened and chromed steel construction, lapped measuring faces, and the ability to increase depth with extensions.

Calibration and Standards:

Calibration Services: ALPA offers calibration certificates in compliance with UNI EN ISO 9000 and VISION 2000 standards, as well as ACCREDIA and UKAS certifications.
Primary Bench: The ALPA ZEROmax is highlighted as a primary reference for in-house calibration, offering cost-saving benefits.

Additional Features:

IP67 Digital Indicators: These indicators are robust and water-resistant, featuring a large display with tolerance indicators and a variety of user-friendly functions.
Proximity Connectors: Options for USB or RS232 connections are available for data output, enhancing the functionality of digital indicators.

Conclusion: The document provides comprehensive technical details on a range of precision measuring instruments, emphasizing their accuracy, versatility, and suitability for various industrial applications. The availability of calibration services and customizable options further enhances their utility.

Overview: The document is a product catalogue for digital and analog dial indicators, focusing on proximity connections via USB or RS232, and various technical specifications. It highlights features such as user-friendly functions, large displays with LED tolerances, and IP54 protection.

Key Features:

Proximity Connection: Options for USB or RS232 connections for data output.
Display: Large display with integrated LED tolerance indicators for easy reading.
Protection: IP54 rating ensures resistance to water and coolant, suitable for tough environments.
Functionality: Configurable menus with functions like min/max, delta, preset, and automatic on/off.

Technical Specifications:

Repeatability: 2 μm.
Slider Speed: 1.7 m/s.
Display Refresh Rate: 10 readings per second.
Measuring System: Sylvac Inductive System (patented).
Power Supply: 3V battery with a mean consumption of 73 μA and a life of 8,000 hours.
Working Temperature: +5° to +40°C.

Product Variants:

Various models with different ranges (0-12.5 mm, 0-25 mm, 0-50 mm) and resolutions (0.01 mm, 0.001 mm).
Standard, oil-resistant, and flat-bottom variants available.

Standards and Compliance:

Accuracy according to UNI 4180.
Shockproof mechanisms and hardened stainless steel components for durability.

Additional Accessories:

Interchangeable spherical tips with HM contact for dial test indicators.
Various connectors and batteries available for different models.

Technical Specifications Overview

1. Dial Test Indicators
These indicators feature a dovetail snug with a 6 mm diameter and a carbide contact point. They comply with DIN 2270 standards and are available in various ranges and resolutions. The dial test indicators have a 32 mm diameter lever and a length of 12.8 mm, ensuring precision in measurements.

2. Accessories for Dial Test Indicators
A variety of accessories are available, including fixing shanks with dovetail clamps in different sizes, long swivel holders, and centering shoulders. These accessories enhance the functionality and adaptability of the dial test indicators.

3. Interchangeable Tips
Spare tips for dial gauges are available with an M2.5 connection, allowing for use with calipers. These tips come in various shapes, such as rounded, flat, and spiked, catering to different measurement needs.

4. Magnetic Stands
High-quality magnetic stands are offered, featuring adjustable arms, fine adjustment capabilities, and strong holding power. These stands are suitable for various applications in metrology labs and workshops.

5. Column Type Stands
These stands are made from hardened, grinded steel with fixed check plates. They are designed for stability and precision, with various dimensions and configurations available.

6. Measurement Tables
Designed for inside and outside comparative measurements, these tables are ideal for series measurement. They feature interchangeable tips and are suitable for measuring workpieces with parallel, cylindrical, or conical surfaces.

7. Concentricity and Roundness Control Bench
This bench is equipped with a light alloy frame and hardened stainless steel rotors. It includes movable supports for dial gauges and is provided in an ABS case. Dial gauges are ordered separately.

Overview: The document is a technical catalogue for Alpa bore gauges, which are highly regarded for their robust construction, reliability, and high accuracy. These gauges are suitable for use in both workshops and metrology labs.

Specifications: The document details various types of bore gauges, including those for large bores, small bores, and blind bores. Each type is described with its range, accuracy, maximum depth, and materials used (steel or hard metal). The gauges feature carbide moving contacts and are designed for specific measurement ranges.

Product Variants: The catalogue lists multiple product codes with specifications such as range, accuracy, and maximum depth. For example, the DA0101535A model covers a range of 15 to 35 mm with an accuracy of ±3 μm and a maximum depth of 175 mm.

Extensions and Accessories: Extensions are available to enhance the measurement depth of the bore gauges, starting from a diameter of 20 mm. The document specifies the lengths and diameters of these extensions.

Special Features: Some bore gauges are designed for specific applications, such as measuring large diameters with minimal accessories or measuring blind bores with high precision. The document also mentions the availability of interchangeable anvils and the use of hardened stainless steel spheres for certain models.

Digital Levels: The catalogue includes high accuracy digital levels with features like large LCD displays, simple calibration, and RS232 data output. These levels are used for precise leveling of machine tools and surface plates.

Analog Levels: Analog levels are also described, featuring high sensitivity and easy reading. They are suitable for frequent use by builders, installers, and repairers.

Square Spirit Levels: These are made from nickel-chrome cast iron with fine ground surfaces and are used for checking flat and cylindrical surfaces. They come with thermal-insulated grips and vial protection.

Technical Specifications Overview

1. Square Spirit Level: This tool features four 90° surfaces, with two flat and two V-shaped, designed for checking flat and cylindrical surfaces both horizontally and vertically. It includes an insulation board handle for thermal protection and vial protection.

2. Linear Spirit Level: Constructed with a nickel-chrome cast iron frame, this level has a fine-grinded surface and a flat base with a V-groove. It is manufactured according to DIN 877 standards and features a thermal-insulated grip with a vial visible from above and laterally.

3. Digital Level: This digital level functions as a 360° protractor and inclinometer, with zero setting at any position and a 9V battery included. It offers a resolution of 0.1° and data output capabilities.

4. Digital Bevel Protractor: Made of stainless steel, this tool offers high accuracy with a range of 0-360° and features such as a HOLD function, fine adjustment, and digimatic data output for PC connection.

5. Gauge to Zero-Set Tools: Designed for fast and accurate tool setting on traditional and CNC machines, this gauge features a hardened aluminum construction with a magnetic base and a reading accuracy of 0.01 mm.

6. Bevel Protractor with Magnifier: This high-precision tool is made of hardened stainless steel with a satin chrome finish and features a wide lens for enhanced readability.

7. Sine-Bar Table: Made of hardened stainless steel with a hardness of 60 HRC, this table offers lapped surfaces with flatness accuracy of ±0.001 mm.

8. Precision Measuring Milling Vice: These vices are made of hardened precision steel, suitable for accurate measurements and machine operations, featuring a horizontally and vertically ground prism on the movable side.

9. Zirconia Gauge Blocks: These blocks offer excellent abrasion and corrosion resistance, low thermal conductivity, and high dimensional stability. They conform to DIN 861, ISO 3650, and BS 4311 standards.

10. Tungsten Carbide Gauge Blocks: Known for their accuracy and stability, these blocks are made from materials with a hardness of approximately 1500 HV, ensuring durability and excellent wringing characteristics.

Overview: The document is a technical catalogue from Alpametrology, detailing various precision measurement tools and accessories. It includes specifications for optical parallels, gauge blocks, and related accessories used in metrology.

Optical Parallels: These are designed to check the flatness and parallelism of micrometer anvils using interference fringes. The optical parallel described is 30 mm in diameter and 12 mm in height, certified by UKAS.

Gauge Blocks: The catalogue lists single gauge blocks made of steel, available in various sizes and grades according to ISO 3650 and DIN 861 standards. The blocks are used for precise measurement and calibration, with hardness specifications and dimensions provided.

Gauge Block Sets: Sets of gauge blocks are available in different configurations, including 8-piece and 10-piece sets, with specific dimensions and hardness ratings. These sets are used for calibrating external micrometers and other precision instruments.

Accessories: A range of accessories is available for setting bore gauges and using block gauges. These include holders, measuring jaws, and maintenance kits. The accessories are designed to ensure accurate zero-setting and maintenance of measurement tools.

Technical Specifications: Detailed specifications are provided for each product, including dimensions, material hardness, and compliance with international standards. The document emphasizes the precision and quality of the products offered.

Maintenance and Care: The catalogue includes a maintenance kit for gauge blocks, essential for preventing rust and ensuring the longevity of the tools. Protective oils and other maintenance accessories are also listed.

Product Overview: The document is a product catalogue from ALPA Metrology, detailing various thread gauges and height measurement tools. It includes specifications for GO/NO GO thread plug gauges, thread ring gauges, depth gauges, and height gauges.

Thread Gauges: The catalogue lists GO/NO GO thread plug gauges for UNF, GAS ISO 228, and NPT threads, made from hardened steel. Each gauge is specified by its code, diameter, and pitch. The document emphasizes compliance with international standards and daily inspections to ensure accuracy.

Depth Gauges: Depth gauges for metric threads are described, highlighting their construction from hardened steel and their use in measuring the depth of metric coarse threads.

Height Gauges: The catalogue details various height gauges, including the MEGAtower and ALPA height gauges. These tools are noted for their precision, durability, and ease of use, with features like ergonomic displays, air cushions for smooth movement, and electronic measuring force adjustments. Calibration services are available, adhering to UNI EN ISO 9000 and VISION 2000 standards.

Accessories: A range of accessories for height gauges is available, including measuring inserts with carbide and ruby balls, and various holders to enhance the functionality of the gauges.

Technical Specifications: Detailed specifications are provided for each product, including measurement ranges, repeatability, measuring force, battery life, and maximum error tolerances. The document also includes information on the construction materials and additional features like IP67 protection for certain models.

Technical Specifications Overview

This document provides detailed technical specifications for various precision measurement tools and equipment, primarily focusing on straight edges, rules, inspection plates, and calibration systems. The products are manufactured according to specific DIN standards, ensuring high precision and quality.

Straight Edges and Rules

The document lists several types of straight edges and rules made from hardened stainless steel and granite. These tools are designed for precise control of planarity and parallelism. They are manufactured according to DIN 874/00 and DIN 866/A standards, ensuring accuracy and durability. The dimensions and specifications for each product are provided, highlighting their suitability for different measurement tasks.

Inspection Plates

Inspection plates made from granite and diabase are detailed, emphasizing their non-magnetic and non-conductive properties. These plates are used for high-precision testing and are available in various sizes and grades, including African black grade "0" and absolute black grade "00". The document specifies the flatness and accuracy of each plate, making them suitable for metrology rooms.

Calibration and Measurement Systems

The document describes the ALPA ZEROmax system, a calibration and presetting bench designed to simplify the setting of bore gauges. It offers significant cost savings by replacing traditional master rings and gauge blocks. The system features automatic positioning and can store up to 100 positions, enhancing efficiency in calibration processes.

Additional Products

Other products include cleaning agents for lapped surfaces, engineer's blue for marking high areas during scraping, and cleansing oil for maintaining granite instruments. These products support the maintenance and accuracy of measurement tools.

Conclusion

The document serves as a comprehensive catalogue for precision measurement tools, providing essential specifications and standards compliance information. It is a valuable resource for professionals in metrology and quality control, ensuring they have access to high-quality and precise measurement equipment.

Overview: This document is a technical catalogue from Alpametrology, detailing various measuring and hardness testing equipment. It includes specifications, applications, and equipment details for different types of measuring devices and hardness testers.

1. Measuring Devices:

Types: Includes external and internal micrometers, stem and lever dial gauges, and calibration supports.
Specifications: Devices have varying ranges and accuracies, with resolutions as fine as 0.001 mm.
Features: Made from stabilized cast iron with light alloy heads, equipped with glass optical scales, and large displays for ease of use.

2. Hardness Testers:

Types: Includes manual and digital Rockwell hardness testers, ultrasonic portable hardness testers, and Leeb portable impact hardness testers.
Specifications: Testers are compliant with UNI-DIN-ASTM standards, with load capacities for different scales (Rockwell, Brinell, Vickers).
Features: Digital displays, automatic load applications, and various indenter types for different scales.

3. Special Equipment Applications:

Includes thread control, gear control, and control of depth calipers.
Accessories available for specific measurement needs, such as for diameters and internal measurements with height adjustments.

4. Portable Hardness Testers:

Ultrasonic and Leeb Testers: Advanced technology for easy reading in extreme conditions, with digital outputs and memory storage.
Features: Suitable for various materials and shapes, with infrared and USB data outputs for connectivity.

5. Accessories and Equipment:

Includes various indenters and test specimens for calibration and testing across different hardness scales.
Supporting tables and benches are available for proper equipment functioning.

Technical Specifications Overview

1. Hardness Reference Blocks
These blocks are used for calibrating hardness testers across Rockwell, Brinell, and Vickers scales. They are available with Accredia certification and can be customized upon request.

2. Leeb Impact Hardness Tester
This portable device measures hardness with a resolution of 0.1 for HRB, HRC, HS, and 1 for HL, HV, HB. It features a 360° selectable impact direction and is suitable for various materials like iron, stainless steel, and aluminum. It includes a USB connection for data output and storage.

3. Adapter Ring Set for Hardness Testers
Ensures proper distance between the impact body and sample, allowing tests on various shapes like concave, convex, and cylindrical surfaces.

4. Digital Rubber Hardness Tester
Complies with ASTM and ISO standards, featuring a digital display with 0.5 resolution. It is suitable for testing soft to hard rubber and elastomers.

5. Portable Roughness Testers
These devices measure surface roughness with high precision. They offer various parameters according to international standards (ISO, JIS, ASME, MOTIF) and feature Bluetooth connectivity for data transfer. The testers are compact, making them ideal for on-site measurements.

6. Roughness/Surface Profiler Tester
This device offers a wide range of roughness parameters and features a 90° rotatable inductive probe. It supports advanced analysis and graphical display of roughness profiles.

Key Features and Accessories
- High-resolution displays and memory capacity for storing multiple measurements.
- Various probes and adapters for different testing needs.
- Compliance with international standards ensures reliability and accuracy.
- USB and Bluetooth connectivity for easy data management and transfer.

Overall, the document provides detailed specifications and features of various hardness and roughness testing equipment, highlighting their applications, accuracy, and compliance with standards.

Overview: The document provides detailed information about the ALPA PROFIL H100 surface profiler, highlighting its user-friendly features, technical specifications, and the accessories available for enhanced functionality. The profiler is designed for ease of use in both production environments and metrology labs, with manual or motorized column options and automatic CNC measuring and positioning cycles.

Specifications: The ALPA PROFIL H100 offers a measuring range of 220 mm in the X-axis and 50 mm in the Z-axis, with resolutions of 0.5 µm and 0.1 µm respectively. It supports measuring speeds from 0.2 to 2 mm/s and positioning speeds up to 10 mm/s. The profiler is equipped with a USB interface and features a light alloy base for easy installation.

Software and Functionality: The Profile Studio software enhances the profiler's usability, providing intuitive tools for profile characterization, including arcs, lines, and points. The software supports dynamic CAD modifications and features like Best Fit and autocomparing for efficient profile analysis. The profiler can handle complex parts by executing measuring cycles that automatically overcome obstacles like grooves and shoulders.

Probes and Accessories: A variety of probes are available for different surface types and measurement needs, including standard probes for flat surfaces and specialized probes for concave, convex, and small bore measurements. The document lists several probe models with specific applications and technical details.

Calibration and Standards: The document includes information on roughness specimens for visual comparison and calibration, with nominal Ra values provided for different machining methods. These specimens are made from high abrasion-resistant materials and can be certified by Accredia.

Additional Features: The profiler supports automation with interfaces for robotic connections and offers accessories like probe change racks and dual monitors. The Aberlink 3D software provides an intuitive interface for fast and reliable measurements, with features like magnetic joystick control and steel scales for easy cleaning.

Overview: The document is a technical catalogue for ALPA measuring machines, specifically the ALPA SPIDER and ALPA TRUST series. These machines are designed for high precision and efficiency in various industrial environments, offering features like integrated temperature control, automation capabilities, and advanced software integration.

Specifications: The machines come with different configurations and specifications, including:

Axis travel dimensions ranging from 640 x 600 x 500 mm to 800 x 2000 x 600 mm.
Accuracy levels specified as (2.4 + 0.4 L/100) μm for different probe types.
Operational temperature range from 5°C to 45°C, with optimal performance between 18°C and 22°C.
Table load capacities of 300 kg for honeycomb structures and 500 kg for solid structures.
Drive systems using Kevlar belts or rod technology with brushless motors.

Features: Key features of the machines include:

Protection from environmental vibrations and smooth movements due to air bearings.
Available with various probe head configurations, including TP8, TP20, TP200, and SP25M.
Aberlink 3D software for enhanced measurement capabilities, with free software updates.
Optional accessories such as automatic thermal compensation systems, CCD cameras, and dual monitors.

Recommendations: The document advises against exposing the machines to sudden temperature changes to maintain accuracy and performance. It also highlights the importance of using the machines within the specified temperature ranges for optimal results.

Applications: The ALPA SPIDER and TRUST series are suitable for use in workshops, production lines, and automated systems, providing reliable and precise measurements even in extreme conditions. The TRUST HS model is particularly noted for its high speed and precision, making it ideal for large-scale production inspections.

Technical Specifications:
The document provides detailed specifications for various 3D measuring machines by Alpa Metrology. Key specifications include accuracy, scale resolution, temperature ranges, load capacity, drive speed, acceleration, air consumption, and air pressure. The machines feature linear motors, brushless motors with Kevlar belts, and rod technology for smooth and precise movements.

Features:
The machines are equipped with Aberlink 3D software, which offers automatic measurement, feature recognition, and interactive graphic windows. The software supports GD&T dimensions and tolerances, dxf data import/export, and real-time SPC, CP, and CPK. Accessories such as CCD cameras, thermal compensation systems, and probe change racks are available on request.

Design and Construction:
The machines are designed with a focus on structure and materials, using aluminum alloys and granite tops for lightness and precision. The honeycomb bridge structure ensures resistance and reduced weight, making the machines suitable for workshop use.

Software:
Aberlink 3D software is user-friendly and supports both manual and CNC inspections. It allows for the creation of inspection reports in graphical or tabular formats and supports 3D CAD comparison for complex profiles. Vision software enables contactless inspection using a camera, with features like autofocus and digital zoom.

Applications:
These machines are ideal for industries requiring high precision and speed in 3D measurements, such as aerospace and manufacturing. The innovative design and software capabilities make them suitable for both large-scale and detailed inspections.

Overview: The document provides a detailed description of various technical specifications and functionalities of CAD 3D comparison software and different probe heads used in measuring machines. It highlights the capabilities of the software in comparing measured parts with CAD models and the features of different probe heads for precise measurements.

CAD 3D Comparison: This software is designed to compare the points of a measured part with a CAD model, particularly useful for objects with complex profiles. Points within tolerance are marked in green, while those outside are marked in red, yellow, or blue. The software supports 3D IGES or STEP file imports and allows data export to Excel. Reports are available in graphical and tabular formats.

3D CAD Programming: The software allows for measurement preparation using a geometric design in IGES or STEP format. Users can click on model surfaces to generate measurement programs, usable both on measuring machines and offline. It supports simple operations for measuring flat surfaces, circles, and cylinders.

Probe Heads:

TP8 Probe Head: An entry-level option with manual alignment, requiring requalification after each index. Compatible with M3 styli.
MH20i Probe Head: Offers repeatable manual indexing from 0° to 90° on the A axis and 360° on the B axis, in 15° increments. Uses TP20 stylus module.
PH10T Plus Probe Head: Fully motorized, allowing indexing from 0° to 105° on the A axis and 360° on the B axis, in 7.5° increments. Compatible with TP20 or TP200 modules.
RTP20 Probe Head: Provides automatic indexing on CNC machines, using TP20 stylus module, compatible with MCR20 change rack.
PH10M Plus Probe Head: Similar to PH10T Plus but can also support SP25M scanning technology.
PH6M Probe Head: Fixed autojoint for SP25M scanning probe, suitable for non-indexing requirements.

Probes:

TP20 Probe: Robust for general measurement, supports automatic stylus changing with MCR20 change rack.
TP200 Probe: Uses strain gauge technology for accurate form measurement, compatible with SCR200 change rack.
SP25M Scanning Probe: Uses optical metrology for accurate measurements, supports M3 styli up to 400 mm, compatible with FCR 25-6 or FCR 25-MRS systems.

CMM Camera: Offers non-contact inspection with a magnetic joint for quick probe and camera swapping. Features include 16 LED ring lighting, telecentric lens, and high-resolution camera.

Fixture Kit: Utilizes T-slot and T-nut technology for flexible fixture component adjustment, enhancing design simplicity and assembly speed.

Horizontal Profile Projector: Ideal for checking small to medium cylindrical components, featuring robust design, halogen lamp illumination, and optical edge detection for data capture.

Interchangeable Objectives: Composed of multiple lenses for precise light ray collimation, ensuring maximum measurement accuracy.

Product Overview
The document is a product catalogue from ALPA Metrology, detailing various profile projectors used for non-contact measurements and inspections. These projectors are designed for precision measurement of mechanical parts, offering features like adjustable lighting systems, touch screen monitors, and built-in optical edge detection.

Technical Specifications

ALPA PROFIL H400: A horizontal profile projector with a 400mm screen, suitable for small parts like screws and machined components. It offers a measuring range of 300mm x 150mm and features a touch screen monitor with 2D Fusion Touch software.
ALPA PROFIL H600: Designed for larger cylindrical parts, this model has a 600mm screen and a wide workstage, making it ideal for big turned pieces or rods.
ALPA PROFIL V300: A vertical profile projector with a 300mm screen, equipped with a digital readout for measuring radii, diameters, angles, and distances. It includes a bright LCD and supports a maximum load of 15 Kg.
ALPA PROFIL V350 and V500: Vertical projectors suitable for flat small and medium components, commonly used in industries like gaskets, plastics, and glasses.

Features and Capabilities
The projectors feature high-quality optics for precise measurements, interchangeable lenses for different magnifications, and options for motorized movements. They support data output via RS-232 interface and include software for statistical process control and data import/export.

Calibration and Standards
ALPA offers calibration services compliant with UNI EN ISO 9000 and VISION 2000 standards, as well as ACCREDIA and UKAS certifications.

Accessories
The catalogue mentions various accessories like V-blocks, rotating tables, and calibration glass scales, enhancing the functionality of the projectors.

Overview: The document is a technical catalogue from Alpametrology, detailing various optical measurement machines and accessories. It includes specifications, features, and functionalities of different models, focusing on precision measurement capabilities.

Key Sections:

FT2-E Readout: This section describes the FT2-E model, which features a touchscreen and an optical sensor for automatic point detection. It supports data import/export in DXF or TXT formats and offers statistical process control.
Technical Specifications: Detailed specifications for interchangeable objectives and various measurement machines are provided. These include lens configurations for precision, measurement ranges, surface areas, and maximum workpiece loads.
Product Features: The document highlights features such as programmable LED lighting, digital zoom, and self-learning programs. It also mentions the integration of statistical process control (SPC) for quality assurance.
2D/3D Vision Machines: Various models of 2D and 3D vision machines are described, including manual and CNC versions. Specifications cover measuring ranges, magnification capabilities, and error margins.
Advanced 3D Machines: The Alpa Scope VP CNC is an advanced optical 3D machine with non-contact measurement capabilities and a comprehensive lighting system. It supports both optical and contact measurements.
Presetting Equipment: The Eye Trim II is a high-performance entry-level presetting tool with a granite base for stability. It features a 7-inch graphic display and interchangeable spindle holders.

Critical Information: The document emphasizes precision in measurement, the versatility of the machines, and the integration of advanced software for data processing and reporting. It also highlights the importance of programmable lighting and self-learning capabilities for efficient measurement processes.

Technical Specifications Overview

1. Thickness Gauges:

Scale 3: Range: 0-13mm (0-500mils), Accuracy: ±1-3% or ±50μm (±2.0 mils), Resolution: 1μm for 0-2mm and 10μm for 2-13mm.
Scale 1: Range: 0-1500μm (0-60mils), Accuracy: ±1-3% or ±2.5μm (±0.1mil), Resolution: 0.1μm for 0-100μm and 1μm for 100-1500μm.
Scale 2: Range: 0-5mm (0-200 mils), Accuracy: ±1-3% or ±20μm (±1.0 mil), Resolution: 1μm for 0-1mm and 10μm for 1-5mm.
Scale 6: Range F: 0-25mm (0-980mils), N: 0-30mm (1200mils), Accuracy: ±1-3% or ±100μm (±4.0mil), Resolution: 10μm for 0-2mm and 100μm for 2-30mm.
Scale 7: Range F: 0-31mm (0-1220mils), Accuracy: ±1-3% or ±100μm (±4.0mil), Resolution: 10μm for 0-2mm and 100μm for 2-31mm.
Scale 0.5: Range F: 0-500μm (0-20mils), Accuracy: ±1-3% or ±2.5μm (±0.1mil), Resolution: 0.1μm for 0-100μm and 1μm for 100-500μm.

2. Thermometers:

Standard Thermometer: Resolution: 0.1°C, Accuracy: ±0.05°C, Measures temperature via various probes, stores max, min, avg values.
Thermocouple Thermometer: Resolution: 0.01°C, Accuracy: ±0.01°C, Portable with large LCD, supports K, J, T, E thermocouples.
Thermometer Datalogger: Stores up to 80,000 samples, data transfer via RS232C/USB, functions include REL, HOLD, automatic switch-off.

3. Hygro-Thermometers:

Standard Hygro-Thermometer: Resolution: 0.1% RH, Accuracy: ±0.1% RH, Measures relative humidity and temperature.
Hygro-Thermometer Datalogger: Stores up to 38,000 samples, measures temperature and relative humidity, data transfer via RS232C/USB.

4. Dewpoint Meter:

Measures surface temperature, air temperature, and relative humidity to determine dewpoint, delta temperature, wet bulb temperature, and specific humidity. Features include data storage and retrieval via USB or Bluetooth.

5. Accessories:

Includes various adapters, replacement probe caps, USB cables, and power connectors for different probes and devices.

Catalog excerpts

Measuring MEASURING Instruments metrology PRODUCT CATALOGUE

Open the catalog to page 1

OUR COMPANY Since 1943 the name ALPA stands for Italian quality in the manufacturing of measuring instruments for the mechanical industry. Today ALPA produces top quality products that meet the upmost industry standards. In addition to product excellence, ALPA offers a qualified technical service, which is the result of the great deal of experience gained in the measuring instruments market. UNSER UNTERNEHMEN Seit 1943 stellt die Marke ALPA ein Synonym für italienische Qualität in der Herstellung von Messgeräten für die mechanische Industrie dar. Heute ist ALPA in der Lage, die hochwertigsten...

Open the catalog to page 3

ALPA KWBI! Measuring Instruments OUR CATALOGUE The catalogue is full of technical details and images. It allows those who use it, to find solutions to the most different needs. Through a selection of over 3500 items ranging from the simplest bench tools to the most advanced CMMs we are able to provide the right quality for every type of application. Der Katalog Alpa ist reich an technischen Details und Bildern. Er ermdglicht es jedem, die besten Ldsungen fur die unterschiedlichsten Anforderungen zu finden. Durch die beachtliche Auswahl an uber 3500 Artikeln, die von den einfachsten Geraten bis...

Open the catalog to page 4

OUR BRAND The evolution of our brand is the synthesis of our history. From being just a local manufacturers of bench tools to an international reality in the metrological panorama. ALPA is synonim for reliability in every application. Technology is simplicity. UNSERE MARKE Die Entwicklung unserer Marke stellt eine Zusammenfassung unserer Geschichte dar. Von lokalen Herstellern handelsüblicher Geräte bis zu einer internationalen Realität im metrologischen Bereich. Alpa ist ein Synonym für Zuverlässigkeit bei jeder Anwendung. Technologie ist Einfachhei

Open the catalog to page 5

Technology & innovation OUR PRODUCTS We produce our articles by analyzing the needs of the market in detail. The experiences of our customers are the main driver for our R&D team in order to guarantee accuracy, repeatability and reliability. We offer instruments and measuring machines of high technological level and simple and intuitive use. UNSERE PRODUKTE Wir stellen unsere Produkte nach einer sorgfältigen Analyse der Marktanforderungen her. Die Erfahrungen unserer Kunden stellen die Triebfeder unseres Forschung- und Entwicklungsteams dar, um Präzision, Wiederholbarkeit und Zuverlässigkeit...

Open the catalog to page 6

Application engineer Application engineer TRAININGS ALPA provides the great experience of its technicians for training courses in the classroom or at your premises or to help you choose the product that best suits your needs. It is also possible and effective to plan courses tailored on the most interesting Customer's topics, using online platforms. TRAININGS ALPA stellt die große Erfahrung seiner Techniker für Schulungen im Schulungsraum oder bei Ihnen vor Ort zur Verfügung, oder um Sie bei der Auswahl des Produkts zu unterstützen, das sich am besten für Ihre Bedürfnisse eignet. Darüber hinaus...

Open the catalog to page 7

Certified company Zertifiziertes Unternehmen ALPA offers gauge blocks, setting rings, surface plates, hardness masters, roughness masters, precision spheres and pin gauges, limit plug gauges, weight masters. ALPA can also provide calibration certificates according to UNI EN ISO 9000 and VISION 2000 standards, or ACCREDIA and UKAS certificates. ALPA bietet EndmaRe, Messplatten, Ringe Hartevergleichsplatten, Messkugeln und Prufstifte, Grenzlehrdorne und Gewindegrenzlehren, Prufmassen. ALPA ist zudem in der Lage, die eigenen Gerate mit metrologischen Bestatigungszertifikaten auszustatten, die den...

Open the catalog to page 8

Fast deliveries Schnelle Lieferungen LOGISTICS In 2017 we opened a new logistics facility, improving the dispatching service of our customers. With over 30000 m2 of highly automated technologic warehouse, we manage and track every step related to your product, from picking to shipping. We are able to guarantee H24 deliveries on most items in our catalogue. LOGISTIK 2017 haben wir eine neue Logistikanlage eingeweiht, durch die wir den Versandservice für unsere Kunden verbessern konnten. In dem über 30.000 m2 großen Lager mit hochwertiger Automation und Technologie verwalten wir jeden Schritt Ihres...

Open the catalog to page 9

SHOW ROOM We offer a wide range of 3D machines that are extremely easy to operate, thanks to intuitive software and construction specifications that also allows these technologies to be used in production environments. SHOWROOM Wir bieten eine reiche Auswahl an 3D-Maschinen, die dank der intuitiven Softwares und der baulichen Eigenschaften einfach anzuwenden sind und auch in Produktionsbereichen eingesetzt werden können. R&D Our research and development team is available to analyze your every need, in order to find the most suitable solution for each specific need. Forschung & Entwicklung Unser...

Open the catalog to page 10

EVENTS Our attention to detail also sets us apart on these occasions when we fully represent ALPA identity. Alpa is a constant presence in the major trade fairs. VERANSTALTUNGEN Unsere Liebe zum Detail zeichnet uns auch bei diesen Anlässen aus, bei denen wir die Identität von Alpa voll und ganz vertreten. Alpa erwartet Sie auf allen bedeutendsten Messen der Branche. WEB Through the Youtube channel, directly accessible from the official ALPA site, it is possible to better understand our world. WEB Mithilfe des Youtube-Kanals, der direkt über die offizielle Website von Alpa zugänglich ist, haben...

Open the catalog to page 11

Industry and technology are going ahead. In a market where measurements must now be tracked, to be able to access them every time, ALPA offers technological items to meet these needs. For these reasons solutions Bluetooth® and wired solutions are born. Industrie und Technologie sind auf dem Vormarsch (Industrie 4.0, IOT). Auf einem Markt, auf dem die Messungen heutzutage aufgezeichnet werden mussen, um bei Bedarf darauf zuruckzugreifen, bietet Alpa technologische GerSte, die diese Anforderungen erfullen. Und so entstehen die Bluetooth®- oder verkabelten Ldsungen.

Open the catalog to page 12

All ROL d.o.o. catalogs and technical brochures

*Prices are pre-tax. They exclude delivery charges and customs duties and do not include additional charges for installation or activation options. Prices are indicative only and may vary by country, with changes to the cost of raw materials and exchange rates.

Brand list
