Workshop equipment
27Pages

Transmission Jacks and Accessory page 2 Start-Booster Brake Bleeder, Brake Fluid Tester 3Transmission Oil Refilling Units, Drain PansOil Collection Units , Oil Suction Units 4 - 5Creeper / Seat, LED - Floodlight 6Hydraulic StraightenerPull Clamps 7Hydraulic Ram Sets, Pneumatic-Hydraulic Pump Hydraulic Cylinders / Pneumatic Dent Puller 8 - 9 Bottle Jacks Telescopic Bottle Jacks Air-hydraulic Bottle Jacks 10 - 11 Jack Stands Aluminium Trolley Jacks / Trolley Jacks for Cars 12 - 13 Hydraulic Trolley Jacks and Air-hydraulic Jacks / telescopicfor Trucks and Commercial Vehicles 14 - 15 Hydraulic...

order no.: 810030 / 810075 / 810120 order no.: 810020 / 810022 Hands-free operation with foot pedals Universal and mobile transmission jack with hydraulic foot pumpՕ Lifting by foot pump without locking at positions, hands-free Foot pedal also for descent, handsfree (dead man auto-stop valve)Օ 5-wheel safety chassis Includes the transmission claw. Օ When inversing the claw, a saddle plate (model GHT) can be inserted as mechanicđs third arm in order to push up or hold something, i.e. the exhaust system. This plate with rubber cover is available as an extra accessory. ӕ according to EN 292...

Start-Booter for car / truck batteries order no.: 831100 / 831110 model BOS12 BOS1224 article no. 831100 831110voltage [V] 12 12 24 starting current (amps peak) [A.p.] 2200 3400 1700 starting current (amps continuous) [A] 700 700 weight [kg] 8,9 17,9 recharging capacity [Ah] 1,5 (12V) 4 (12V) recharging voltage (net to charger) [V] 230 230 recharging voltage (charger to booster) [V] 14,9 14,9 25,2 recharging time [h] 15 8 cycles * [times] 400 500 cable cross section [mm] 28 50 cable length [cm] 180 170 capacity booster [Ah] 12V 22Ah 12V 32Ah batteries in booster [number] 1 2 dimension...

Pneumatic unit for transmission oil refilling order no.: 810199 Application: transmissions, dfferentials, motorsՕ Very handy because of small dimensions and construction Works independently without permanent connection to air supplyՕ After setting up the pressure it can serve several workplaces Easy handling because of handle with tap model dimension tank capacity up to weight working pressure oil flow rate (l x w x h) [mm] oil level indicator [l] [kg] [bar] [l/min]GF 02 350 x 320 x 880 19 13 3,8 12 Made of oil and petrol resistant polyethylene (HDPE) > Model P 2 Model P 46 order no.:...

order no.: 810196 order no.: 810191 / 810190 order no.: 810219 / 810197 Oil collection unit for carsTank easy to empty using compressed air Mobile oil collection toolՕ Drain pan adjustable for height 2 wheels on axle, 2 swivel wheelsՕ Easy emptying of the tank using compressed air (max. 1.4 bar) Compact version (tank and drain pan) especially suited for cars Oil collection unit for cars Tank easy to empty using compressed airՕ Mobile oil collection tool Round drain pan with integrated sieve for oil filter drainage and splash reductionՕ Drain pan adjustable for height 2 wheels on axle, 2...

order no.: 810400 - Creeper - Chair in one, practical for various working heights- Creeper : for working on floor without lift (use jack stands !!)- Chair : for medium high working spots (fenders, doors, front area of car)Ergonomic design especially for tiring work Folding mechanism with safety lock against unintended folding1. Easy and stable to move on seven large wheels diameter 63 mm oil and acid resistant2. Comfortably upholstered and covered with easy to clean surfaces 3. Ergomically favored height of seat for medium high working spots4. Head rest adjustable in 3 positions to give...

Mobile Hydraulic Straightener with 10 t Ram order-no.: 811049 Easy to move on oil and acid resistant plastic wheelsՕ The strong 8 10 t hydraulic ram has sufficient power for toughest straightening duties.ӕ Being able to tilt the pull arm sideways (up to 45 left and 45а right) ensures an optimum adaptation to the car body. The hand pump can be controlled precisely in order to serve also for smaller or even delicate straightening applications. The air-hydraulic pump is an ideal supplement for this tool that will save time and reduce the manual effort. Please see page 9. The delivery includes:...

Hydraulic Ram Set 10 t, 38 pieceorder no.: 811038 Application: pulling - pushing - widening - clampingՕ Set is equipped with threaded connections for pulling Movable due to included trolley, light and easy to use Օ 2-step hand pump Including a full set of accessories Accessory see page 23 > Hydraulic Ram Set 17 pieceorder no.: 811040 / 811000 Օ Application: pushing - widening - clamping Quick and easy assembly because of unthreaded socket connections Օ 17 piece set in a durable plastic case for easy storage. Each piece with ist own moulded compartment to keep the set complete - NO LOOSE...

stroke cylinder diameter cylinder / diameter piston min. length max. length oil volume [l] max. pressureset model [mm] with rubber cap [mm] [mm] [mm] [mm] cylinder / pump [bar] HRS 04 100 34 / 42 25 268 368 0.4 / 0.4 700 HRS 10 150 56 / 64 38 370 520 0.5 / 0.5 700 HRS 20 130 90 60 280 410 0.9 / 0.9 700 HPP 10 150 57 38 350 500 0.5 / 0.5 700 CYLINDERS APPLICABLE pulling and pushing cylinders, hollow cylinders and spreaders _ > 881004881004882104 model-article no.withinset HKZ12 - 811062HRD02 - 811002HRD10 - 811010 HRD10K - 811009HRD10F - 811008HRD04F - 811007 HRZ05 - 811021 10-03 - 882103...

Hydraulic bottle jacks with threaded extention " The economical series " > ֕ With safety valve against overloading Vertically and horizontally applicable (pump has always to be on lower side)Օ With threaded piston extension within hydraulic piston > Jacks assembled with threaded connections, complete disassembly possible > Օ Double guidance of piston for higher stability at max. load and full stroke Tested according to DIN 76024 With safety valve against overloadingՕ Vertically and horizontally applicable (pump has always to be on lower side) With threaded piston extension within hydraulic...

2 ton models additionally equipped with threaded extension rod within telescopic pistonՕ With safety valve against overloading Vertically and horizontally applicable (pump has always to be on lower side)Օ High standing stability due to large base plate Each jack includes a pump bar set that can be take apartTested according to DIN 76024 > Hydraulic bottle jacks with telescopic piston model MGT 2 MGT 5 MGT 8 MGT 12 MGT 20order-no.: 810612 810614 810615 810617 810618 > Additionally with manual pumporder no.: 810622 With air-hydraulic pump system as well as manual pump for fast and precise...
