Company Overview Company Overview > Roadtec, located in Chattanooga, Tennessee, manufactures and markets a complete line of cold planers, material transfer vehicles and asphalt pavers. These products are sold all over the world through an extensive combination of dealers and direct sales managers. All of our products are built to the highest standards, emphasizing simplicity, productivity, versatility and serviceability. We are further committed to provide unequaled service and parts support to our customers. Our service men are all highly trained, experienced employees of Roadtec, not just field...

8 Foot Rubber Tire Paver 8 Foot Rubber Tire Paver > 8 Foot Rubber Track Paver 8 Foot Rubber Track Paver > 10 Foot Rubber Tire Paver 10 Foot Rubber Tire Paver > 10 Foot Rubber Track Paver 10 Foot Rubber Track Paver >

Engine Outboard Auger Bearings > Roadtecs outboard auger bearing system incorporates a NOMEX TM washer and an AR400 steel plate on each side of the bearing. This prevents material from entering the bearing. All Roadtec Pavers feature CATҮ engines. The name has long been synonymous with reliability. The RP-170 and RP-175 contain a 174 HP version and the RP-190 and RP-195 have a 225 HP version. The engine is transversely mounted which allows for better ground level access and cooling efficiency. Reliability size="-3">

TM 90 series variable displacement pumps are used in all Roadtec pavers. These are the highest output pumps used in the industry. Roadtec uses 90 series pumps since the larger capacity enables them to run at a more op- timal speed which permits them to run cooler and increases their life. > Roadtec pavers feature the sturdiest frame in the industry. The frame starts with a 2 inch thick front cross member. Connected to this are two thick continuous side sheets which run the entire length of the paver and then wrap around to make up the rear. These side sheets are connected to each other with numerous...

Augers > The auger assembly on Roadtec pavers can be hydraulically raised and lowered. This feature can assist in eliminating segregation in certain mixes and is very helpful during the loading and unloading process. Stan- dard sonic feed sensors control the augers. The auger chain case width has been kept to a minimum to further reduce segregation. Conveyors > The conveyers are designed to maximize throughput while maintaining durability. All Roadtec pavers feature a 13 inch high con- veyer opening and extremely wear resistant replaceable liners. Each conveyer is indepen- dently driven so material...

Each auger is driven by its own motor. This allows the conveyers to be much closer together compared to designs where the conveyers drive the augers by a chain. Minimizing the space between the con- veyers allows mix to be conveyed out as one uniform flow, greatly reducing segregation. The Comfort Drive Hydraulic motors drive the conveyers by a chain which allows them to be located above the feed tunnel. This makes for easier access and allows for a wider conveyer tunnel. The conveyer tunnel disperses material over the au- gers more evenly, which prevents segregation. The motors can be controlled...

Access Panels > Conveniently located solenoids simplify diagnostic testing.The hydraulically raised hood provides exceptional engine access. A fuel fill location on each side of the paver lets you refuel on the fly from either side of the machine. Routine maintenance areas are easily reached through numerous access panels to help keep your paver operating at peak performance levels. The left and right side access doors allow you to freely get to radiators, hydraulic pumps, filters and more. Engine AccessDual Fuel FillsCentralized Solenoids > Serviceability size="-2">

TM system comes in a dual grade and slope configura- tion or the optional Big-Sonic-Ski The Topconή Paver System Five comes in a dual grade and slope configuration or the optional Smoothtrac configuration. Each sensor head contains an ultrasonic ground sensor. In the Smoothtracή configuration four of the sensors are set up along a ski and their measure- ments are then averaged together.The MOBA-Matic Provides extra pulling power to the rubber tired pavers by powering the front bogies with independent hy- draulic motors. > TM configuration. Each sensor head contains 5 ultrasonic ground sen- sors....

The Roadtec S series vibratory screeds are available in both 8 (2.5m) and 10Ғ (3.0m) standard paving widths. Standard features include 3 hydraulic strike-offs with electric articulation, dual screed con- trol consoles, power crown control and electrically heated screed plates. The Carlson EZ III hydraulic extendable screed comes in an 8Ғ (2.4m) to 136Ҕ (4.1m) version or a 10 (3m) to 17Ғ (5.2m) version. Both the main screed and the front mounted extensions are electrically heated by a 34kw generator. They also feature vibration, adjustable angle of at- tack, adjustable slide track, berm builder...
