DATA SHEET RDD01_01 Issue 01, 28th September 2023 OnAxis™ Redundant Incremental Encoders The RM44 and RMF44 redundant are non-contact magnetic encoders with two independent outputs and no common connections between two devices. Redundancy is implemented only on the sensor and driver side. The encoders are suitable for demanding applications that require a higher level of safety. EASY INSTALLATION Redundancy for safety apllications Dual outputs inside one encoder 5 V power supply versions Excellent degree of protection up to IP68 High speed INDUSTRIAL AUTOMATION MOTOR CONTROL

General information The encoder consists of a diametrically polarised magnet and a separate sensor body (RM) or a sensor on a flange (RMF). The redundancy is realized in the sensor and driver side only. The encoder uses only one magnet (Ø7 x 4 mm). Designed for direct integration into high-volume OEM applications, the RM/RMF44 encoders can be used in a wide range of applications, including motor control and industrial automation. RMF44 encoder module on a flange Product range RM44 encoder Encoder system

Storage and handling Operating and storage temperature RMF44: –40 °C to +105 °C (limited by connector) –40 °C to +125 °C (soldering pads) The RM44/RMF44 encoders must be powered from a DC SELV supply that meets the basic requirements of EN (IEC) 60950 or similar specification. Packed individually in antistatic bags. Less than 20 products are packed individually in an antistatic box. If more than 20 systems are ordered, the parts are packed in antistatic plastic trays. Magnets and readheads are pack

Dimensions and installation drawings 2x Molex connector 10 max. Dimensions and are in mm. 2xtolerances Molex connector PCB RMB28 RMF44 dimensions Flange RMF Flange RMF Components area Hmax=1mmComponents area Mounting holes 2x 4.6 ±0.1 Mounting holes Static bend radius > 40 mm Mounting holes Static bend radius 2x R5 ±0.2 > 40 mm Static bend radius > 40 mm S M S

Magnet RMM7040 Actuator RMH06 Components area Hmax=1mm Mounting distance Ride height 14.2 ±0.4 0.2 ±0.5 Flange RMF PCB RMB28 PCB RMB28 Magnet RMM7040 Flange RMF Flange RMF Flange RMF PCB RMB28 2x Molex connector 2x Molex connector PCBRMM7040 RMB28 RMF44 with magnet 2x Molex connector 2x Molex connector 2x Molex connector PCB RMB28 PCB RMB28 2x Molex connector 2x Molex connector

Static bend radius S > 40 mm

Installation tolerances Installation tolerances for RM44/RMF44 Mounting distance See installation drawings of encoder assemblies on pages 5-6. Radial displacement (concentricity)

Technical specifications System data Accuracy Temperature drift error Mechanical data Housing material Wire thickness Maximum speed Maximum cable length Environmental data Operating and storage temperature –40 °C to +105 °C (limited by connector) –40 °C to +125 °C (soldering pads) Environmental sealing

Output type Incremental, RS422 line driver RM44/RMF44 IC Specifications Power supply Current consumption Output signals Short circuits protection Reverse polarity protection Connections RMF44 with connectors Timing diagram Complementary signals not shown Edge separation RMF44 with soldering pads B leads A for clockwise rotation of magnetic actuator. Master Recommended signal termination Customer electronics

Part numbering RM44 Series RM44 - Ø44 mm body RM58 - Ø58 mm body Output type IC - Incremental, RS422, 5 V Resolution For IC output types: counts per revolution: 05B Cable length 10 - 1.0 m (cable length in dm) Connector A - ‘D’ type connector - 9 way F - Flying lead (no connector) Body style and cable exit 2 - Cylindrical body, radial cable exit Environment and material E - IP64, die-cast body (Zinc alloy), standard EMC grade (standard) F - IP68, die-cast body (Zinc alloy), standard EMC grade Special requirements R2 - Redundant

Series RMF44- Ø44 mm diameter flange RMF58- Ø58 mm diameter flange Resolution For IC (counts per revolution): 05B Shape and connector A - Standard aluminium flange M - Standard aluminium flange, Molex connector Special requirements R2 - Redundant

Magnetic actuator and magnet ordering information Actuator for integration onto shaft Magnet 11 Part number: RMA06B1A00 Shaft = Ø6 mm × h7 Fixing: Grub screw provided Actuator for integration into shaft Magnet Magnet for direct recessing in non-ferrous shafts Part numbers: RMM7040A1A00 (individually packed) – sample quantities only RMM7040A1B00 (packed in tubes) Fixing: Adhesive (recommended – LOCTITE 648 or 2701)

Accessories Cable assembly Cable assembly 12 core, 0.3 m, 0.5 m or 1 m ACC001, ACC002. ACC003 Compatible with RMF44. Dimensions Dimensions and tolerances in mm. L ±10 40 ±5 Cable specifications Cable length Cable specifications Wire diameter Sheath color Rated voltage Operating temperature range Environmental conformation RoHS conform 73/23/EWG-Guideline CE conform Halogen free Wire color

Head office RLS Merilna tehnika d. o. o. Poslovna cona Žeje pri Komendi Pod vrbami 2 SI-1218 Komenda Slovenia Global support Visit our website to contact your nearest sales representative. Document issues Issue This product is not designed or intended for use outside the environmental limitations and operating parameters expressly stated on the product’s datasheet. Products are not designed or intended for use in medical, military, aerospace, automotive or oil & gas applications or any safety-critical applications where a failure of the product could cause severe environmental or property...
