RKB Bearings Catalogue
168Pages

Catalog excerpts

ball bearings ball bearings ball bearings separable ball contact ball bearings ball bearings direction thrust ball bearings cylindrical roller spherical roller BEARING INDUSTRIES Bearings Catalogue © 2010The contents of this catalogue are copyright of the publisher Every care has been taken to ensure the accuracy of the information in the present catalogue but no liability can be accepted for any errors or omissions contained herein, or in case losses and/or damages (direct, indirect, consequential) should occur. RKB Bearing Industries reserves the right to make amendments and withdraw...

Open the catalog to page 2

BEARING INDUSTRIES manufacturing organization operating in the bearing industry with headquarters in Switzerland. The experience gained in this sector provides RKB with the know-how and expertise necessary for technological value-added bearings, particularly in the field of heavy duty machines and equipments. All conformity with the International Standards in owned plants that are ISO its pioneer business model, based on a vertically integrated system, RKB offers reliable cost-effective solutions in the long run, with extreme operational flexibility, leading-edge service and the quality...

Open the catalog to page 3

Roadmap for eligibility criteria XII Recommendations to customers XIII RKB Bearings Production Range XV Materials, design and load ratings 5 Bearing tolerances definitions 11 Bearing tolerances definitions (Italian) 12 Bearing tolerances definitions (Spanish) 14 Bearing tolerances data 17 Snap ring and groove tolerances 22 Radial internal clearance 23 Single row radial ball bearings 31 Double row radial ball bearings 42 Double row self-aligning ball bearings 44 Single row separable ball bearings 50 Single row angular contact ball bearings 51 Double row angular contact ball bearings 54...

Open the catalog to page 4

The present catalogue lists the types and technical specifications of the standard ball and roller bearings manufactured and offered by RKB Bearing Industries. All the bearings in this catalogue are produced in accordance with the standards of the International Organization for Standardization (ISO).The load ratings in this volume are principally based on ISO 281 and ISO 76, but are not calculated according to the latest available bearing design and execution. In order to get further background information on calculations please ask RKB Technical Department for related data. Unilaterally...

Open the catalog to page 6

VI 525 78 - Machined brass cage guided on inner ring (rivet-type) - Speed rating oil lubrication 600 rpm - 29 balls dia 1-7/8'' - Outer ring raceway diameter 882,625 - Inner ring raceway diameter 787,375 - Raceways curvature R25 116 920 618/MB CN - P0 5,0 5,0 5,0 5,0 Brass 1250 750 618/750 MB GGC140410

Open the catalog to page 7

VII 410 Brass 48 180 - Optimized inner geometry E Type - Machined brass cage guided on outer ring (rivet-type) - ZB roller profile - Max axial displacement +/-2 mm - For general industry purpose 8,0 240 NU/EMA C3 - P0 2,1 2,1 1,5 1,5 670 160 NU 2032 EMAC3ZB CC270510

Open the catalog to page 8

VIII 7300 300 - Annular groove and 6 lubrication holes in outer ring b;K (suffix W33X) - Optimized cage design (integrated guiding slinger) - For general industry purpose 547,0 760 CAW33X C3 0,37/13°30' P0 - - 7,5 7,5 Brass 14000 460 24192 CAC3W33X GGC260510

Open the catalog to page 9

XI 165 33,325 - Optimized cage design (elastic pin-type retention method) - 18 rollers - For general industry purpose 1,71 138,887 Inch/AT600 - - Normal 1,5 1,5 1,5 1,5 Brass 588 88,900 AT 626 CC280510

Open the catalog to page 12

Roadmap for eligibility criteria Procurement compliance procedure for technological bearings The knowledge and experience gained over the years, along with the close cooperation with international academic centers, have enabled RKB to establish the steps of the procurement compliance procedure for technological bearings. For reasons of responsibility and transparency, all customers are invited to read thoroughly and follow carefully the following roadmap: (1) Signing of non-disclosure agreement (where required). (2) Commercial evaluation (price, delivery terms and conditions). (3) Technical...

Open the catalog to page 13

As a matter of responsibility, RKB has also developed a series of recommendations in order to help customers choose after due consideration and keep away from unpleasant surprises: Always follow the Roadmap for eligibility criteria in the procurement process of technological bearings. Always formally define representations and warranties to avoid incurring fraudulent cases, including misleading or deceiving conduct with regard to corporate consistency and (3) Scientific background and conformity to International As a matter of transparency, always request suppliers to show the scientific...

Open the catalog to page 14

BEARING INDUSTRIES PRODUCTION RANGE

Open the catalog to page 16

Deep groove ball bearings Non-separable, for operations at high speeds, of simple design and little maintenance, RKB deep groove ball bearings are the most versatile and popular bearings in rolling applications. The internal designs are the Conrad assembly (the majority of the production) and the filling slot assembly (for special applications with cage or with full ball complement). The single row deep groove ball bearings can take radial and double direction axial loads. They have limited abilities to compensate for errors of misalignment. Because of the values, in order to avoid...

Open the catalog to page 17

The axial clearance is generally not standardized and depends on the values of the radial clearance, ball size The cage depends on the bearing series and size; RKB single row deep groove ball bearings are supplied with one of the following designs: ribbon type cage of steel or brass sheet, riveted type of steel or brass sheet and machined brass type centered on balls, inner ring or outer ring. Large size bearings are also available in special executions such as lubrication grooves in the guiding surfaces of machined brass cage (suffix MAS or MBS) and/or one notch in the outer ring side face...

Open the catalog to page 18

Single row angular contact ball bearings RKB single row angular contact ball bearings are designed to accommodate combined loads acting in radial and axial direction.They can take axial loads in one direction only. When radially loaded, in the bearing occurs an axially acting load which has to be compensated. For this reason one bearing or paired bearings are mounted on each shaft end. These bearings are not separable and their use at relatively high speed is allowed. Manufactured in various constructive versions, they can be with different contact angles, depending on the RKB produces two...
