Catalog excerpts
![Selection assistant - linear technology - 1](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_1m.jpg)
A Phoenix Mecano Company Selection guide
Open the catalog to page 1![Selection assistant - linear technology - 2](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_2m.jpg)
Reliable movements Guiding, adjustment, positioning or uniform motion, the requirements for linear motion operations are as numerous as the solutions. We offer you a wide spectrum of linear motion components, starting with an occasional manual movement, as well as frequent operation, through to continuous high dynamic positioning. In order for you to preselect the most suitable range quick and easy, we have developed a system which is strictly application orientated. You can determine the most suitable size and design based on your performance requirements from within the range. We are...
Open the catalog to page 2![Selection assistant - linear technology - 3](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_3m.jpg)
The four steps to your product recommendation Step 1: The application is always the focus • Width, length and height adjustment • Loading and unloading, palletising, pick & place • Numerically controlled operation tasks Which product design do you want? • Rodless style (Linear actuator) • Rodstyle (E-cylinder, lifting column) What features should the product have? • Guide • Drive • Guide + drive Which performance category do you require? • Travel • Load • Speed • Accuracy • etc. …follow our system and the term
Open the catalog to page 3![Selection assistant - linear technology - 4](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_4m.jpg)
Place-Tec continue on page 8 Your appli takes centr Width, length, height adjustment Features: 99Manual or electric drive 99Occasional to daily multiple adjustment 99Low duty cycle 99Low speed 99Moderate to high stability Move-Tec continue on page 6
Open the catalog to page 4![Selection assistant - linear technology - 5](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_5m.jpg)
99High repeatability 99Short cycle time 99High number of cycles 993-shift operation 99High reliability Loading and unloading, palletising, pick & place 99High positioning accuracy 99Uniform motion 99High drive stiffness 993 shift operation 99IP40 protected Control-Tec continue on page 10 Numerically controlled travel 5
Open the catalog to page 5![Selection assistant - linear technology - 6](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_6m.jpg)
Move-Tec Width, length and height adjustment Twin tube (Lifting columns) Single tube actuator Twin tube Cylinder performance class 1
Open the catalog to page 6![Selection assistant - linear technology - 7](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_7m.jpg)
Profile guides LZ 60 E-cylinder Travel max: 597 mm Fd max: 4,000 N Fz max: 4,000 N Vmax: 85 mm/s lifting columns RK Powerlift Travel max: 500 mm Fd max: 3,000 N Fz max: 1,500 N Vmax: 50 mm/s Profile actuators Cylinder performance class 2 LAMBDA E-cylinder Travel max: 600 mm Fd max: 6,000 N Fz max: 4,000 N Vmax: 21 mm/s Heavy load cylinder LZ 70 TR PL E-cylinder Travel max: 1.000 mm Fd max: 5,000 N Fz max: 5,000 N Vmax: 48 mm/s LZ 80 E-cylinder Travel max: 1,005 mm Fd max: 10,000 N Fz max: 10,000 N Vmax: 25 mm/s SLZ 63 TR FL/PL E-cylinder Travel max: 1,005 mm Fd max: 15,000 N Fz max: 15,000...
Open the catalog to page 7![Selection assistant - linear technology - 8](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_8m.jpg)
Loading and unloading, palletising, pick & place Roller guides Roller guide actuators Roller guide actuators RK MonoLine Travel max: 5,780 mm Fx max: 2,600 N Fy max: 4,367 N Fz max: 2,509 N v max: 10 m/s a max: 20 m/s² Repeatability
Open the catalog to page 8![Selection assistant - linear technology - 9](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_9m.jpg)
Ball return guides Ball return rails actuators MultiLine Travel max: 5,620 mm Fx max: 4,700 N Fy max: 10,000 N Fz max: 10,000 N v max: 5 m/s a max: 50 m/s² Repeatability ± 0,05 mm RK DuoLine Z Travel max: 9,010 mm Fx max: 6,000 N Fy max: 5,100 N Fz max: 8,900 N v max: 5 m/s a max: 50 m/s² Repeatability ± 0,05 mm Heavy duty actuators D-Line (on request) Travel max: 50,000 mm Fx max: 4,700 N Fy max: 10,000 N Fz max: 10,000 N v max: 5 m/s a max: 50 m/s² Repeatability ± 0,1 mm For detailed information, sizing, accessories, motors and controls please look in our main catalogue ‚Linear Tec
Open the catalog to page 9![Selection assistant - linear technology - 10](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_10m.jpg)
Control-Tec Numerically controlled travel Ball return guides Ball return rails actuators (Linear actuator) Heavy load cylinder For detailed information, sizing, accessories, motors and controls please look in our main catalogue .Linear Technology'
Open the catalog to page 10![Selection assistant - linear technology - 11](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_11m.jpg)
Our service What we can do for you: CAD-component library (Part server) To support your design work we offer component data free of charge in the Rose+Krieger-component library (drawings, technical descriptions). About 60 different file formats (2D/3D) can be selected here. RK-Infomobile – the exhibition at your location Over 20 presentation boards with exhibits and functional examples, as well as many applications of drive and linear technology to give you a complete overview of RK products. RK-Field service - Advice on site Our Key Account managers and sales consultants are happy to visit...
Open the catalog to page 11![Selection assistant - linear technology - 12](https://img.directindustry.com/pdf/repository_di/11638/selection-assistant-linear-technology-213621_12m.jpg)
A Phoenix Mecano Company
