RK multi-axis modular system Perfectly tailored to each other, selected quickly and easily

RK multi-axis modular system Application example empty goods sorting system Multi-axis systems are an economic alternative to robots in many applications, such as handling solutions.

RK ROSE+KRIEGER RK multi-axis modular system

RK multi-axis modular system Everything from a single source, perfectly tailored to each other - selected quickly and easily. System angle bracket, system plates and clamping bars • Enable the quick and easy connection of linear actuators • Reduced assembly work through the integrated installation aids • Prepared as standard for attaching drag chains • Scope of delivery complete with the required fixing material Cable management • Multi-axis systems are optionally available with matching holders and support surface profiles • The support surface profiles are suitable for the use of drag chains...

fUiRK ROSE+KRIEGER_ Motor adaption • Standard motor adapter kits available for a variety of motor and gear unit manufacturers • Motor adapter, servo coupling with zero backlash and assembly material as a complete set • Complete motor adapter kits manufactured to your specifications on request • Assembly by the customer according to instructions • Assembly by RK Rose+Krieger completely or segmentally RK ROSE+KRIEGER RK multi-axis modular system

RK multi-axis modular system Tried-and-tested RK linear technology as the basis for the RK multi-axis modular system With the new modular system, linear, planar and three-dimensional gantries can be set up quickly and simply using the RK DuoLine and RK MonoLine series as the basis. RK MonoLine Z The RK MonoLine Z is a high-performance roller guide that impresses with its very good value for money. RK MonoLine MT Linear unit with Omega drive. A typical application is use as a moving axis. RK DuoLine S Optimum performance, precision and features for dynamic adjustments. RK DuoLine Z All-round talent...

RK ROSE+KRIEGER RK multi-axis modular system

RK multi-axis modular system Crossing system System angle bracket Guide profile on guide carriage System plate Guide carriage on guide carriage System angle bracket Guide carriage on guide carriage Guide profile on guide carriage Guide profile on guide carriage System angle bracket Guide profile on guide carriage

3-axis system Type of adaptation System angle bracket Guide profile on guide carriage System plate Guide carriage on guide carriage System angle bracket Guide profile on guide carriage Guide carriage on guide carriage Clamping bar Guide profile on guide carriage + System angle bracket Guide carriage on guide carriage RK ROSE+KRIEGER RK multi-axis modular syst

RK multi-axis modular system Order information: • Other size combinations on request Material:Aluminium clear anodised, galvanised fastenings Scope of delivery:1x system angle bracket with fastenings System angle bracket Combination options - RK MonoLine Code No.

Order information: • Other size combinations on request fUiRK ROSE+KRIEGERMaterial: Aluminium clear anodised, galvanised fastenings Scope of delivery: 1x system angle bracket with fastenings Guide profile on guide carriage - flush termination of the upper axisCombination options - RK MonoLine Code No. Combination options - RK DuoLine Code No. RK ROSE+KRIEGER RK multi-axis modular system 11

RK multi-axis modular system Order information: • Other size combinations on request Material:Vibration finished aluminium, galvanised fasteningsScope of delivery:2x clamping bars with fastenings Clamping bar Combination options - RK MonoLine Code No.

Order information: • Other size combinations on request fUiRK ROSE+KRIEGERMaterial: Vibration finished aluminium, galvanised fastenings Scope of delivery: 1x System plate with fastenings System plate Guide carriage on guide carriage Combination options - RK MonoLine Code No. Combination options - RK DuoLine Code No. RK ROSE+KRIEGER RK multi-axis modular system 13

RK multi-axis modular system Order information: • Other size combinations on request Material:Aluminium clear anodised, galvanised fasteningsScope of delivery:1x system angle bracket with fastenings System angle bracket Combination options - RK MonoLine Code No.

Drag chains Due to the large range of versions, not all connections for drag chains can be represented as order numbers. Storage profile 30x38 for energy chain linear axis as standard via BLOCAN®- profile 15 x 40 or 15 x 60 with angle bracket or special adapter plates • Variable in length and width, flexible attachment via clamping plates and slot stones • Special support surface profiles with slots and possibility of installing a silencer RK ROSE+KRIEGER RK multi-axis modular syste

RK multi-axis modular system RK Rose+Krieger GmbH Customer number: Technical data: (See enquiry form "Controllers") □ Yes (please include sketch) □ Yes (please include sketch)

Application examples:

RK multi-axis modular system Enquiry form motors and controllers for multi-axis systems RK Rose+Krieger GmbH E-mail: [email protected] Motor type:  DC motor EHL electronic handwheel: Speed controller:  Three-phase drive Worm gear motor: Motor temperature monitoring: Spur gear motor: Spiroplan gear motor: With brake:  Yes Voltage for brake control:  24V/DC  230V/AC  Stepper motor driver with integrated control and power electronics (24-48VDC) Motor connection cable length: Switching power supplies which are required for operation of the motor: Programming cable:  Servo drive...

Sketches & commentaries: RK ROSE+KRIEGER RK multi-axis modular system

A Phoenix Mecano Company RK Rose+Krieger GmbH Verbindungs- und Positioniersysteme Potsdamer StralBe 9 32423 Minden, Germany + 49 571 9335-0 [email protected] www.rk-rose-krieger.com
