TopTherm chiller

TopTherm chiller

Product catalog summary

Overview: The Rittal TopTherm chiller is designed for maximum efficiency, reduced costs, and energy savings. It is part of Rittal's comprehensive system solutions, which include power distribution, automation, building installation, and IT infrastructure.

Key Features:

Modular Design: The chiller features a standardized modular design for faster availability and easy integration into existing systems.
International Compatibility: One version supports two frequencies (400 V/50 Hz, 460 V/60 Hz), making it suitable for global use.
Flexible Air Intake: The chiller module allows air intake from the rear, left, or right, optimizing installation based on local conditions.
Refrigerant: Utilizes R410A refrigerant.
Water Module: Includes a standard water bypass and flow monitor, with easy module exchange for different capacities.

Technical Specifications:

Cooling Output: Ranges from 8 to 40 kW, with specific outputs at different water and ambient temperatures.
Power Consumption: Varies by model, with maximum consumption ranging from 3.4 to 19.8 kW.
Temperature Range: Environment: +10°C to +43°C; Water: +7°C to +25°C.
Pump Capacity: At 2.5 bar, varies by model and frequency.
Protection Category: IP 44 for electrical components.

Benefits:

Small Footprint: Compact design for space efficiency.
Convenient Servicing: Easy maintenance and servicing.
High Reliability: Standard water bypass ensures consistent performance.
Fast Delivery: Pre-assembled modules allow quick setup and integration.

Accessories: Includes air filters, levelling feet, base/plinth components, and Rifrost canisters and barrels.

Catalog excerpts

Standardised modular design for faster availability 2

Open the catalog to page 2

Control module œ One version for two frequencies 400 V/50 Hz, 460 V/60 Hz œ Temperature control by way of fixed or differential values, switchable Chiller module œ Air intake at rear, optionally also on left or right for the 8, 12 and 16 kW versions œ Refrigerant R410A œ Simple exchanging of modules with different outputs Water module œ Water bypass as standard œ Flow monitor as standard œ Simple exchanging of modules of different capacities 3

Open the catalog to page 3
