Overview: The VERTIFLEX machine is a flexible machining cell that combines the productivity of a rotary transfer machine with the flexibility of a machining center. It is designed to handle parts of various shapes and materials within a 450 mm cube, allowing for five-sided machining in one setup, and can use up to eight tools simultaneously for short cycle times. The machine features CNC-controlled satellite worktables and hydraulic clamping fixtures, ensuring high precision and rigidity.

Specifications: The VERTIFLEX 300 and 450 models offer different configurations. The VERTIFLEX 300 is designed for a 300 mm cube with very short cycle times and reduced cost per piece. The VERTIFLEX 450 is for a 450 mm cube, emphasizing accuracy, power, and speed. Both models feature patented machining centers arranged around a rotary table for optimal access and space efficiency.

Options: VERTIFLEX machines can be equipped with various options, including high-pressure coolant systems, multi-spindle heads, angular heads, oil mist collectors, tool monitors, and automatic loading/unloading systems. These options can be retrofitted due to pre-designed interfaces.

Technical Data: The VERTIFLEX 300 and 450 models have specific technical parameters, such as axis travel, spindle speed, and power. The machines use linear roller guides for axis movement and offer high precision with features like HIRTH coupling for table indexing.

Design and Safety: The machines are designed with a self-supporting, monolithic frame for rigidity. Critical components are placed outside the machining area to avoid contamination and allow easy maintenance. The full enclosure with control panels ensures operator safety, and coolant tanks are designed to serve as operator platforms.

Catalog excerpts

Box tool Machining center with multi-spindle heads Kombi-Werkzeuge Bearbeitungseinheit mit Mehrspindelk켶pfen Machining centerwith angular heads Pallet changer Palettenwechsler Machining center VF 450 Hole presence checking device (Poke yoke) Robotised loading/unloading station VF 450 Bearbeitungseinheit Bearbeitungseinheitmit Winkelkpfen Bohrungs-Kontrolleinrichtung Robotergesteuerte Be- und Entladestation >

Open the catalog to page 47

~ 4450 ~ 6025 ~ 4615 Height / H켶he ~ 4050 mm Height / Hhe ~ 4050 mm Vertiflex 300/4 with 5 machining centers Vertiflex 300/5with 6 machining centers Vertiflex 300/5mit 6 Bearbeitungseinheiten Vertiflex 300/6 with 8 machining centers Vertiflex 300/4 mit 5 Bearbeitungseinheiten Vertiflex 300/6 mit 8 Bearbeitungseinheiten 300 mm cube.Very short cycle times. Reduced cost per piece. Kubus mit 300 mm Seitenlnge.Sehr kurze Taktzeiten.Reduzierung der St椼ckkosten. >

Open the catalog to page 48

~ 6650 ~ 5650 Height / H䶶he ~ 4700 mm Height / Hhe ~ 4700 mm Vertiflex 450/4 with 5 machining centers Vertiflex 450/6 with 8 machining centers Vertiflex 450/4 mit 5 Bearbeitungseinheiten Vertiflex 450/6 mit 8 Bearbeitungseinheiten 450 mm cube.Accuracy, power, speed. Reduced cost per piece. Kubus mit 450 mm Seitenlnge.Genauigkeit, Leistung, Geschwindigkeit.Reduzierung der St椼ckkosten. >

Open the catalog to page 49
