Hand- and foot operated workshop presses

Product catalog summary

Specifications:
The document provides specifications for three models of the PROFI PRESS® manual workshop presses: 15 TON HF2, 30 TON HF2, and 50 TON HF2. Key specifications include:

Pressure force: 147.15 kN, 294.3 kN, and 490.5 kN respectively.
Maximum pressure: 382.2 bar, 374.6 bar, and 399.5 bar respectively.
Piston stroke: 160 mm for all models.
Oil tank capacity: 1.65 dm³ for 15 and 30 TON HF2, 2.5 dm³ for 50 TON HF2.
Working width: 560 mm, 565 mm, and 750 mm respectively.
Weight: 117 kg, 165 kg, and 340 kg respectively.

Features:
The presses are hand and foot operated, made in Europe, and suitable for assembly, straightening, and testing work. They are made from quality steel and include features such as:

Movable cylinders for 30 and 50 TON HF2 models.
Integrated pressure manometer and chrome piston with automatic return.
Adjustable work table height.
Optional mandrel set for the 50 TON HF2 model.

Compliance and Availability:
The presses comply with CE regulations and are available for immediate delivery with a one-year warranty.

Catalog excerpts

Hand- and foot operated workshop presses-1

RHTC PROFI PRESS Metal working machines Photos may differ from actual products. Abbildungen konnen von der Wirklichkeit abweichen. MANUAL WORKSHOP PRESSES 3 Hand and foot pump with double operation Hand- und FuBpumpe mit Doppel-Betrieb is et of V-blocks / V-Block-Satz integrated manometer / Integrierter Manometer ^Movable cylinder (left-right) / Verschiebbarer Zylinder (links-rechts) ilable adjustment by using winch (only for the 50 ton HF2) Tischverstellung mit Winde (nur fur die 50 ton HF2) SPECIFICATIONS / TECHNISCHE DATEN

Open the catalog to page 1

Hand- and foot operated workshop presses-2

Because the job always needs to be done. Whenever. Wherever.HAND- UND FUBBETRIEBENE WERKSTATTPRESSEN • The manual hydraulic workshop presses from RHTC are made in Europe and suitable for general assembly and straightening work or testing work pieces. • These Profi Presses can be operated by hand and by foot (the hand pump is interchangeable to a foot pump) and the 30 HF2 and 50 HF2 presses have a movable cylinder. • They provide highly precise press work and are a must for any workshop / garage. • Made out of quality steel. • The height of the work table is very easy to adjust. • Equipped with...

Open the catalog to page 2
