RG70, RG100 & RG100R
Product catalog summary
Introduction
This document provides technical specifications and safety recommendations for RAYCO's RG70, RG100, and RG100R stump cutter models. These machines are designed for high power and performance in backyard stump cutting.
Specifications
Features
Safety Recommendations
Additional Information
RAYCO Manufacturing reserves the right to make changes in design and specifications without notice. For more information, visit raycomfg.com or contact RAYCO Manufacturing, Inc. at their Wooster, Ohio location.
This document provides technical specifications and safety recommendations for RAYCO's RG70, RG100, and RG100R stump cutter models. These machines are designed for high power and performance in backyard stump cutting.
Specifications
- Models: RG70, RG100, RG100R
- Engine: Kubota diesel engines with 66.8 hp for RG70 and 99.2 hp for RG100 and RG100R
- Weight: Approximately 3,700 lbs (1,678 kg) for RG70 and 3,750 lbs (1,701 kg) for RG100 and RG100R
- Dimensions: Length 144 in (365.8 cm), Height 64 in (162.6 cm), Width 35 in (89 cm), Width with dual wheels 53 in (134.6 cm)
- Fuel Tank Capacity: 14 gallons (53 liters)
- Cutting Capacity: Depth 21.5 in (54.6 cm), Height 31 in (78.7 cm), Width 69 in (175.3 cm)
- Cutter Wheel: 23 x 0.75 in (58.4 x 1.9 cm)
- Controls: 4-Lever for RG70 and RG100, Joystick for RG100R with optional wireless remote
Features
- Hydrostatic cutter wheel drive and Command Cut for enhanced performance
- Swing-out control panel for operator safety
- Low center of gravity and 4-wheel drive with high and low travel speed
- Standard dual wheels for easy access through 36-inch gates
- Hydraulic backfill blade for efficient clean-up
- Optional wireless radio remote control for RG100R
Safety Recommendations
- Always wear an approved helmet with ear muffs, face shield, and proper eyewear
- Do not operate under the influence of alcohol or drugs
- Read and understand the owner's manual thoroughly
Additional Information
RAYCO Manufacturing reserves the right to make changes in design and specifications without notice. For more information, visit raycomfg.com or contact RAYCO Manufacturing, Inc. at their Wooster, Ohio location.
See more
Catalog excerpts
T ^ CALL TOLL FREE 800.392.2686 _Hs§yv\\ (USA or Canada Only) RAYCOManufacturing, Inc. 4255 E Lincoln Way Wooster, Ohio 44691-8601 USA Phone: 330.264.8699 Fax: 330.264.3697 raycomfg.com SP-801/901/901R-06/10 (replaces SP-801/901-05/10) Made and Printed in the USA Copyright © 2010 RAYCO Manufacturing, Inc., Wooster, OH 44691 RAYCO Manufacturing Inc. retains the right to make changes in design and spcifications; engineering; add or remove features; add improvements; or discontinue manufacturing at any time without notice or obligation.
