Introduction
This document provides technical specifications and safety recommendations for the RAYCO Super Jr series stump cutters, specifically the RG 1625A and RG 1635 models. These machines are designed to be compact, self-propelled, and economically priced, suitable for both professional and rental applications.

Specifications

• Models: RG 1625A and RG 1635
• Engine: RG 1625A features a 25 hp Kohler Command engine, while RG 1635 has a 35 hp Briggs & Stratton Vanguard engine.
• Weight: RG 1625A weighs 1,300 lb (590 kg) and RG 1635 weighs 1,355 lb (615 kg).
• Dimensions: Both models have a length of 105.5” (268 cm) and a width of 34.5” (88 cm), with dual wheels extending the width to 46” (117 cm).
• Cutting Capacity: Both models have a cutting depth of 11” (28 cm) and a cutting height of 26” (66 cm), with cutting widths of 38” (97 cm) for RG 1625A and 39” (99 cm) for RG 1635.
• Fuel Tank: 6.5 gallons (24.6 L) for both models.

Features

• Self-propelled hydraulic ground drive with variable speed.
• “Quick Stop” cutter wheel clutch brake for safety.
• Hydraulic steering and variable swing speed.
• Optional accessories include dual wheels, auxiliary chip retaining curtains, and a custom trailer.

Safety Recommendations
Operators are advised to wear approved safety gear, including helmets, ear muffs, face shields, and eyewear. It is crucial to read and understand the owner's manual thoroughly and avoid operating the machinery under the influence of alcohol or drugs.

Additional Information
RAYCO Manufacturing reserves the right to make changes to the design, specifications, and features of their products without prior notice. The document also provides contact information for RAYCO Manufacturing, Inc., located in Wooster, Ohio.
