RAYCO
RAYCO Full Line Catalog

RAYCO Full Line Catalog

Product catalog summary

Introduction
RAYCO Manufacturing, Inc., founded in 1978, specializes in high-quality environmental equipment for the tree and landscape industry, focusing on quality engineering and advanced modeling techniques to ensure product reliability and performance.

Company Overview
Operating from a 390,000 square-foot facility in Wooster, Ohio, RAYCO is committed to innovation in environmental equipment, supported by a skilled workforce.

Product Line Overview
The document details specifications and features of RAYCO's products, including stump cutters, brush chippers, and forestry mulchers.

Mini Work-Force Stump Cutter

RG13 Series II: 13 Hp Honda engine, electric start, adjustable handlebar, lightweight for backyard stump removal.
RG25HD: 25 Hp Kohler engine, self-propelled, suitable for hard-to-reach stumps.

Self-Propelled Stump Cutters

RG1625A Super Jr & RG1635 Super Jr: Compact, powerful, hydraulic steering, variable speed; RG1635 offers 30% more power.
RG1635 Super Trac Jr: Rubber tracks, 47.5-inch cutting width, ideal for compact spaces.
RG1645: 44 hp Kubota turbo-diesel engine, 59-inch cutting width, designed for stability and efficiency.

Tow-Behind Stump Cutters

RG100DXH: 99 hp Kubota turbo-diesel engine, 96.5-inch cutting width, meets US EPA Tier III emissions standards.
RG140DXH: 140 hp John Deere engine, designed for large stumps, 99.6-inch cutting width.

Brush Chippers

RC6D & RC6DV: 6-inch capacity, VERSA-FEED automatic feed control, Kohler or Vanguard engines.
RC814: 8-inch capacity, Kubota diesel engine, hydraulic feed wheel lift and crush.
RC1220: 12-inch capacity, high performance, Kubota diesel engines, Versa-Feed control.

Safety Recommendations
RAYCO stresses safety, advising operators to wear protective gear and understand the owner’s manual before use.

Conclusion
RAYCO Manufacturing offers a comprehensive range of high-performance environmental equipment, emphasizing quality, innovation, and safety.

Additional Equipment Details

RC1220 Chipper: 20” diameter feed wheel, 12” x 20” infeed opening, maintenance-free planetary feed wheel drive motor, rugged frame, lockable engine enclosure.
RH1754 Horizontal Grinder: Compact, affordable, suitable for small contractors, towable or self-propelled, John Deere 4045HF285 engine with 140 hp.
RC1824 Chipper: Easy feeding of brush, limbs, logs, dual horizontal feed wheels, Cummins QSB4.5 engine options.
C100 Forestry Mulcher: 99.2 hp Kubota turbocharged diesel engine, 16” steel track undercarriage, RAYCO-exclusive cooling system, cab with heat and AC.
RH1754-240 Horizontal Grinder: Efficient processing of wood chips, Cummins QSB engine with 240 hp, discharge conveyor over 12 feet high.

Key Features Across Equipment

Emergency shutdown buttons, optional torque limiters, magnetic head pulleys for safety and efficiency.
Easy maintenance with swing-away fuel tanks, removable debris screens.
Available on tracks for enhanced mobility.

Catalog excerpts

RG1635 Super Trac Jr Selt-Propelied Track Stump Cutter Wright 1.660 1bfV49Ag) Longth Hrtyhl fU?cm) MMh 35* (09 cm) (V oorwl Drive SctfPropftlted HvdraiAc. ? Spwxi Engine Vantard 35 rvp (26 Gasolme urtTank 10 &(378L) Supei looth* 18 ToLd Cutter WTieel rt2$*xV(438cmx2.$cm} Culting Depth 12* (30 ^ cm) C utling HeJght 21" (!tf34cmj C utling Widih 475"<f065cm) Mien yoo need a compact stump cutter wvth thc go-anywhere traction and notation thaͯ onry tratfcs can provide» me Trac Jr is your solution Thls au oew design rrom RAYCO rarses me bar tor compact stump cutters by oflering i smal machine mat...

Open the catalog to page 5

RG70 RG100 RG100R with remote RG100DXH Turbo Diesel Poweredt Tow-Behind Stump Cutter Diesel Powered. Setf-Propelled Stump Cutter RAYCOs Hagship KG/0 and RG100 modcls are Ihc answer rt youre looking lot a tull leature. high powcr backyard stump cutter thse machines teature powertul 66 8 np and 99.2 hp Kubota otese engres wtfh hydrostabc cutter atiee* dnve and RAYCOs Command cm to deliver lop-notcft performance The swing oui control panel provides a good look at the cutbng action wtuie keeptng tne op诩ra*or sale from rtytng dtins The RG100R gives you the added teature or radio remote contrais, gwng...

Open the catalog to page 6

n V RG140DXH Turbo Diesel Power&d, Tow-Behlnd Stump Cutter RC6D RC6DV S-inch Capacfty Brush Chippers WetgM I 6.140 US (2785 *g> Length 200' (508 cm) Height j MT (228 6 cm) Width | 86* (218 4 cm) Su^pt nsion Tofflex*axie Engins John Dccrc 404SHF285.4 Cylindcr. 140 np (104 kW( Turtto Diesel Fuel Tank M gai (109.3 L) Super Tooth* 40 lotal Cutter wneel 28* x r (71 1 cm x ? 54 cm) Cuting Depth ?i>" (t>6 cm) Cutting Height 31" (78 7 cm) Cutting Width 1 99 6' (253 cm) longue Extension | 60' (1524 cm> For those seeing maximum horse-power and productMty in a tow be rand stump cutter. RAYCO*$ new RG140OXH...

Open the catalog to page 7

RC814 8-inch Cspaclty Brush Chipper RC1220 12-inch Capaerty Brush Chipper VMgN Lerigiri 1 f/* f44&6 cmj Hoighi 86* (224m Widlh \ n i r 11: KUBOTA V1505 44 hp (32 8 kWg .Omet Fuel Tank 11 5galf43 5fJ Chtpparw) CnfMctry fi" f703 tmJDur珙^' Inteed Opening 8* x 14* (20 J cm x 35 0 cm) Intakr Raie Dbtharge K4ghl 88*(223cmJ Rotai ion MT Fe*dWh*el Top Fw.d Whorl 9 25 " (23 5e/nJ IXamctcr Botlom 1 eed Wheel 4"(f0cmJOamefe< WeigM 5.620 Ib (2.549 2 kg) Ltngth 160* M88" (406.4 cm/477 52m) 105* f266 ?cm) Width 78* (198 cm} ngm« RC1220-70 Kubota V3600.66 8 hp (498kW),Draei RC1220-100 Kubota V38QOUI. 'j'j '2...

Open the catalog to page 8

RC1824 tB-nch Capactty Brush Chipper RH1754 HorizontalGrndt VMgN s.MO Va(4,145 83 k0 Length 18/v / 20/ *. (4/6 2!> / b2f OS an) tMght 107" (759 00 on) Std Dncharg* Wldih *&./&"'?'**>. 59 Cfflf F agira» Cummim QSIW 5 130 hp / 160 r*> {W94/f793ﯯAW .Dmel Fuel Tunk 40gal(f5M2U c.tuppncj C&pacity 1cr(4W*"cmJ [>g«nel«f Inteed Opemnq 19' x 2V {4826 cm x 60 96 cm) Intakc Rate lOfi fpm (3? nVmtn) Dcharge Height 102* (259 08 Std Chute Rotation 360* Topl-繁lWlwd Optional bottom TeedWhtel Wrien a chipper leeds betler 11 makes We casier for the operator Tnls was trie objec Hve neid by the HAYCO engineers when...

Open the catalog to page 9
