Mini Work-Force

Product catalog summary

Overview: RAYCO's Mini Work-Force series offers a comprehensive range of handlebar stump cutters designed for commercial-grade stump cutting needs. These machines are compact, affordable, and built with durable features such as heavy-duty frames, adjustable handlebars, and a powder coat paint finish. They are equipped with high-quality components, including Honda and Kohler gasoline engines and advanced air filtration systems. Operator controls are positioned for safety and ease of use.

Specifications:

Model RG13 Series II: Weighs 262 lb (119 kg), measures 79.75” in length, 50” in height, and 25” in width. It features a manual push ground drive, a 13 hp Honda engine, and a 1.72-gallon fuel tank. The cutter wheel is 11” x .375” with 8 Super Tooth® teeth, and it has a cutting depth of 13” and a height of 22”.
Model RG13: Weighs 420 lb (191 kg), with dimensions of 66” - 90” in length, 32” - 59” in height, and 31” in width. It also uses a 13 hp Honda engine and has a 1.72-gallon fuel tank. The cutter wheel is 14” x .375” with 12 teeth, and it offers a cutting depth of 18” and a height of 20”. Features include an electric start and an optional tow package.
Model RG25HD: Weighs 583 lb (264 kg), with dimensions of 74” - 98” in length, 34” - 58” in height, and 29” in width. It is self-propelled with a hydrostatic variable speed drive, powered by a 25 hp Kohler engine, and has a 6.5-gallon fuel tank. The cutter wheel is 14” x .375” with 12 teeth, and it offers a cutting depth of 22” and a height of 24”. Features include an electric start and self-propulsion.

Features:

Adjustable handlebars to accommodate operators of all sizes.
Compact design fits through standard gates.
2-year warranty on frame/handlebar assembly.
Durable powder coat finish.
Operator presence safety bar on all models.
Electric start available on RG13 & RG25HD models.

Safety Recommendations: Operators should wear approved helmets with ear muffs, face shields, and proper eyewear. It is advised not to operate the machinery under the influence of alcohol or drugs. Familiarity with the owner's manual is essential for safe operation.

Company Information: RAYCO Manufacturing Inc. reserves the right to make changes to design and specifications without notice. The company is based in Wooster, Ohio, USA, and offers customer support via a toll-free number for USA and Canada.
