Introduction
RAYCO Manufacturing, Inc., established in 1978, specializes in designing and producing high-quality environmental equipment for the tree and landscape industry. The company emphasizes quality engineering, utilizing advanced technologies like Solid Modeling and Finite Element Analysis to ensure product reliability and performance.

Facilities and Workforce
The company operates a 390,000 square-foot facility in Wooster, Ohio, which houses manufacturing, engineering, and corporate offices. RAYCO prides itself on its skilled Ohio-based workforce, committed to continuous improvement and innovation.

Product Line Overview
RAYCO offers a comprehensive range of environmental equipment, including log splitters, stump cutters, brush chippers, and the enhanced crawler line. Key products include:

LS 2526 Log Splitter
Mini Work-Force Stump Cutters
Crawler Line: C100, C140, T185, and T275 with various attachments like stump cutters and mulchers.
Brush Chippers: Ranging from 6” to 20” capacity with power options from 25 hp gas to 225 hp diesel.

C100 Super Crawler Specifications
The C100 is a specialized mulching machine designed for tough forestry environments. Key specifications include:

Weight: 11,340 lb (tractor only), 14,190 lb (with winch and mulcher)
Engine: KUBOTA V3800 DI-T, 99.2 hp turbo diesel
Hydraulic System: 39 gpm @ 5,500 psi
Attachments: PM638 Predator Mulching Head, winch, and skidder winch

C140 Super Crawler Specifications
The C140 is a versatile multi-tool carrier designed for land clearing and site preparation. Key specifications include:

Weight: 12,700 lb (tractor only), 15,500 lb (with forestry mulcher)
Engine: John Deere, 140 hp turbo diesel
Hydraulic System: 67 gpm @ 6,000 psi
Attachments: Forestry mulcher and stump cutter

T275 Turbo Diesel Site Preparation Machine
The T275 is engineered for site preparation and land clearing, featuring high horsepower and a hydrostatic drive system. Key specifications include:

Weight: 31,611 lb
Engine: John Deere, 275 hp turbo diesel
Attachments: FM7260 Mulcher, Hydra-Stumper

Innovative Features
RAYCO machines are equipped with advanced features such as:

Heat and air-conditioned cabs with clean air makeup systems
Hydraulic quick attach plates for easy attachment changes
Forestry cooling packages for extended equipment life
Steel tracks for enhanced traction and durability

Safety and Support
RAYCO emphasizes safety and provides comprehensive support through a worldwide dealer network. The company offers in-house financing and maintains a knowledgeable staff to assist customers.

Conclusion
RAYCO Manufacturing continues to lead the industry with innovative designs and a commitment to quality. Their extensive product line and dedicated support network ensure that customers receive reliable and efficient environmental equipment solutions.

Catalog excerpts

Super Crawler Full Line www.raycomfg.com >

Open the catalog to page 1

RAYCO Manufacturing, Inc. was established in 1978 by John M. Bowling and remains a family business today. Mr. Bowling identiﬁed the special needs of the tree and landscape industry and began to build equipment to meet and surpass those needs.No other manufacturer of environmental equipment places as much emphasis on quality engineering as FR FREE FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE F FREE...

Open the catalog to page 2

General Specifications:Weight Tractor Only 11,340 lb (5,144 kg) with Winch and Mulcher 14,190 lb (6,436.5 kg) Length Tractor Only 128 (326.1 cm) with Winch and Mulcher 185Ԕ (469.9 cm) Height 99 (251.5 cm) Width Tractor Only 71Ԕ (179.8 cm) with Mulcher 82 (208.2Ԕ cm) Engine KUBOTA V3800 DI-T, 4 cylinder, turbo diesel, 99.2 hp (73.97 kW) Fuel 40 gal (151.4 L) Hydraulic Tank 24 gal (90.8 L) Track Shoe 16 (40.6 cm) single grouser Rollers 6 each side Hydraulic System 39 gpm @ 5,500 psi, high flow pump (147.6 L/min @ 37,921 kPa) Ground Pressure Tractor Only 4.6 psi (31.7 kPa) with Winch and Mulcher...

Open the catalog to page 3

C140Super Crawler Weight 12,700 lb (5,761 kg) w/ Stump Cutter 14,400 lb Length 148 (375.9 cm) (6,532 kg) w/ Forestry Mulcher 15,500 lb (7,031 kg) w/ Stump Cutter 220Ԕ (558.8 cm) w/ Forestry Mulcher 195 (495.3 cm) Width 73Ԕ (185.9 cm) Height 95 (241.3 cm) Engine John Deere, turbo diesel, 140 hp (104.4 kW) Fuel 60 gal (227.1 L) Track Shoe 16Ԕ (40.6 cm) single grouser Rollers 8 each side Hydraulic System 67 gpm @ 6,000 psi (245 L/min @ 41,369 kPa) Ground Pressure 4.5 psi (31 kPa) w/ Stump Cutter, 4.9 psi (33.8 kPa) w/ Forestry Mulcher RAYCO Attachments 4 (121.9 cm) or 6Ғ (182.9 cm) Forestry MulcherStump...

Open the catalog to page 4

T275ATurbo Diesel Site Preparation MachinePRIME MOVER: Weight 31,611 lb (14,339 kg) Length 242 (614.7 cm) Height 116Ԕ (294.6 cm) Width 106 (269 cm) Frame 1.25Ԕ x 16 rails (3.2 cm x 40.6 cm) , 4-cross members Cab AC/heated Engine John Deere, turbo diesel, after cooled 275 hp (205.1 kW) Fuel Tank 110 gal (416.4 L) Track Base 108Ԕ (274.3 cm) > Track Shoe 24 (61 cm) , 2-bar, double grouser Rollers 8 each side > Track Hydrostatic drive, two-speed ranges Ground Pressure 4.7 psi (32.4 kPa) FM7260 MULCHER: Weight 8,000 lb (3,629 kg) Width 110 (279.4 cm) Cutter Teeth 46 carbide-tipped fixed tools Drive...

Open the catalog to page 5

Clean Air Makeup System: The clean air makeup system available on the T275 supplies the pressurized cab with clean ﬁltered air keeping the cabin free of dust and debris. The clean air makeup system on the C100 & C140 supplies positive pressure ﬁltered air to the operator. Flat Face Hydraulic Quick Coupler: The ﬂat face quick couplers make it easier for contractors to keep dirt from entering the hydraulic system when switching attach-ments. The ﬂat face is easily cleaned before an attachment is hooked up. > Predator PM638Mulcher Weight 2,350 lb (1,066 kg) Forestry Cooling Package: > Length 42...

Open the catalog to page 6

RAYCO Manufacturing, Inc. is recognized as the industry leader in environmental equipment. Since 1978 RAYCO > has continued to ΓSet the Industry Standard with new and innovative features and designs. Engineering is done in house by our highly trained staff of professionals using cutting edge technology. Our worldwide dealer network provides product training and support by professionals who care about you and your business. Contact us today and put our products to the test. Dedicated Sales Staff Superior Product Support Worldwide Dealer Network Knowledgeable Staff of Engineers In-house financing...

Open the catalog to page 7
