pieces can then be cut into uniform granules by the toothed cutting wheels. The crusher blades come in two sizes. An optional automatic reversing system is available that reverses the rotation of the rotor for a short while to clear any material obstruction. The granule size is uniform at 5 mm. The common backbone of all Rapid granulators is a cutterhouse incorporating rotating and fi xed knives together with screen with a hole diameter that determines the size of regrind. This has proved to be the best solution for virtually all the granulation applications we have encountered. However,...

All dimensions in mm. The granulator can be opened easily without tools to give access to all com-ponents to facilitate granulator cleaning and maintenance. C 766 A 384 150 As waste feeds into the cutting wheels, the teeth cut the pieces cleanly into high-quality granules of uni- fotrm size. The reinforced teeth and powerful slow- speed cutting action easily slice through the hardest materials. 700 1372 522 B 510758 A B C 1022 290 610 220x1601034 410 685 340x160 1046 530 780 460x160 Cutterhouse opening, mm 223 241 343 241 464 ח 241Crusher blades 1 2 3 Motor, kW standard 0.75 1.8 1.8...

Designed for winners > Rapid 150 Series Injection moulding size="-2">

Being good just isnt good enough when it comes to winning in todayҒs highly competitive world. Even small improvements mean the difference between being the leader or being forgotten. Its the same with granulators. Our installed base of more than 20,000 units confi rms that the Rapid 15 Series is the leading low-speed granulator range in the world.But thatҒs not good enough for Rapid. Were innova-tors and we accept no compromises. ThatҒs why we have developed a new generation of small-sized granu- lators with a unique design concept, more options, and a technical superiority that put us way...

Rapid is dedicated to partnering with its customers and taking good care of them. We have the techno- logical leadership needed to carry out the continuous improvements in design and performance that drive granulator evolution. Only the highest-quality mate- rials are used to ensure you get the most rugged and most dependable granulators available. This is why we proudly state that Rapid is the most trusted name in granulators: ֕ a 5-year warranty program world leader in granulator solutions Օ more than 60,000 Rapid granulators delivered over 40 years 24/48-hour spare parts service Օ...

CleanGrind Cutting TechnologyՕ Constant cutting circle Rotating shaft endplates Օ Oversized bearings with high load factors are stan-dard to help eliminate bearing failure particularly important when granulating thick, hard, fi lled and/or abrasive materials.֕ Flyback trap to prevent plastic waste from bouncing out of the infeed hopper. Low noise level in general and with soundproofi ng hood in particular. > Օ CleanGrind Cutting Technology Dust-sealed granule bin Օ Improved sealing between the hopper frame and the cutterhouse > Rotor bearing with higher load factor Օ Bearing housings with...

The under-the-press Rapid Auger 150-21 forces even big and bulky sprues into the cutterhouse. The Rapid solution for dust-generating materials and demanding processes in general, guarantees that regrind is always dust-free.Super-low solution connected to the injection moulding machine. The docking function maintains safety. Brake motor as standard. The Rapid solutions for handling band conveyor feeding and high sprue picker/robot drop. >

The new Rapid 20 Series of granulators is ideal for the direct recycling of plastic waste and rejects primarily from injection moulding and blow moulding processes. No matter what your requirements, a standard model is available to suit your exact needs for capacities up to 190 kg/h. > The number of standard alternatives, like cutterhouse width, rotor confi guration, rotor speed, dis charge systems, etc., allow you to select the granulator best suited to your type of plastic waste, throughput vo lume, granule size and direct recycling require-ments. > The ability to select standardized...

The confi guration of the rotor blades and low rotation speed combine to minimize energy consumption. > A consistently smooth and clean cutting action contri- butes to high quality regrind. Because of its bolted construc-tion, it is easy to remove and replace worn parts in the cut- terhouse. > The small granulator foot-print saves valuable fl oor-space and castors allow units to be moved easily to other locations as required. The tangential feed of the cut-terhouse reduces fl yback of waste and enables fi rm feed ing of lightweight material to increase grinding capacity. The constant...

Non-soundproofed models are just one of the many standard alternatives of the Rapid 20 Series. Easy cleaning and maintenance Cleaning machine parts in response to a change in plastic type and/or colour is facilitated by rapid access to all components. No tools are required to open or close panels and covers. 200 B 240 1870 1480 1150260 The staggered rotor confi - guration suits more universal and tougher applications. The open rotor is best suited to fi lm and bulky lightweight items such as bottles. Either 2 or 3 fi xed knives can be used. The extra knife enables tougher granulation. A 210...

Decision Maker Always the right choice! > An extensive selection of alternatives for 8 dif-ferent machine features gives you the amazing choice of 3840 standard models for the 20 Series of granulators! You can therefore pick the combination of features that best suit your particular application needs when you order a granulator, and rest assured that its the right choice even before the unit is delivered.

One granulator Multiple solutions > Rapid 60 Series size="-1">

The worlds biggest is also >

With a cutterhouse opening of 600 900 mm, the Rapid 60 Series is the worldגs biggest granulator that can be supplied as a soundproofed model. It can recycle a wide variety of plastic waste with equal ease, including pipes, bulky parts like petrol tanks, thick and thin sheets, purgings and diverse containers, bottles, fi lms and profi les. A choice of different models and a wide range of options mean that you can tailor the 60 Series to match your exact needs for numerous applications involving: Central granulationՕ Beside-the-press applications Special above-fl oor or below-fl oor...
