Glass Conveying Chain
16Pages

TOOTH FOR THE GLASS INDUSTRY >

Inverted tooth conveyor chains offer companiesthat work with glass many benefits for hot-and- cold-end handling, as well as for precisioninspection and measuring applications. Moreover, our extensive experience working with the GlassIndustry assures the best conveying solutions. Durability . Our chains are made from through-hardened steel link plates and case hardened steel pins. Chain designs and materials are chosen tomeet the demanding conditions encountered in glass production. Long service life and minimalmaintenance helps you minimize costly downtime for conveyor chain replacement. >

Single Pin Driving Link Single Pin Guide Link Single Pin Driving LinkTwo Pin Driving Link Single Pin AssemblyTwo Pin Assembly Single Pin Assembly Single Pin (top) and Two Pin (below)Guide Links 1/2" > Pitch Line 7.3mm12.6mm 1/2" > Pitch Line 7.3mm12.6mm 1/2" > Pitch Line 6.2mm12.8mm >

Single Pin Guide LinkSingle Pin Guide Link Single Pin Driving LinkSingle Pin Driving Link Single Pin AssemblySingle Pin Assembly 1/2" > Pitch Line 5.1mm10.2mm 1" > Pitch Line 7.1mm12.5mm >

Do you need a center guide, side guide or multi-guide chain? On Ramsey ordering charts, guide type is designated as follows: ( > C ) for center, ( > S ) for side or( > M ) for multiguide. Remember that sprocket guidetype must be compatible with your chain (see Specifying A Sprocket section, p.13). > Inverted tooth conveyor chains are available in two basic build types: all-link, identified with an ( > L ) inRamsey ordering charts, and link-spacer, identifiedwith an ( > S ). Each assembly has its advantages. Some of our glassindustry customers prefer one chain build over another. When...

Side Guide ( MultiGuide ( Center Guide ( > C ) Guide links in the center of the chain align with a groove in the center of the sprocket. > S ) Guide links are on the outer edges of the chain and sprockets fit between them. > M ) Multiple guide linkson the chains outer edge surround the sprocket and provide increasedarea for chain support on a wear strip. Link-Spacer ( All-Link ( > L ) Composed entirely of links, All-Link chainprovides maximum surface area and is often preferred for transporting small glassware. All-Link chain has the greatest thermal mass and the smallest inter-link air...

C = center S =side M =multi LP =Lo-Profile > L =all-link S =link-spacer EP= Extended Pitch > (in mm) > Note that there are many chain widths and assemblies not included in this brochure. Note: The minimum amount of grinding required to clean upӔ a surface is 0.10 to 0.12 mm. The standard tolerance on grinding is 0.025mm.

Assemblies for > UL UltraLife , > ST Standard , > UL 2 UltraLife Two Pin and > LP Lo-Profile >

Assemblies for > UL UltraLife , > ST Standard , > UL 2 UltraLife Two Pin and > LP Lo-Profile >

Assemblies for > UL UltraLife , > ST Standard , > UL 2 UltraLife Two Pin and > LP Lo-Profile >

Pitch Line Width Over Heads > Width Over Links > Width Over Heads Width Over Links >

Pitch Line Width Over Heads > Width Over Links > Width Between Guides > Width Over Heads > Width Over Links > Width Between Guides >

All Ramsey conveyor chains operate on 1/2" pitchRamsey sprockets. Our sprockets are typically manufactured from C-1141 steel and are heat treated to provide hardened tooth surfaces. Sprockets can be fully machined with finished boreand setscrews, or you can ask that they be suppliedwith an unfinished bore to allow further machining. Specialized machining is available to accommodatea customers exact specifications. Materials, other than steel, are available upon request. > It is important to choose a sprocket that is compatible with your chain. You should always consider the following:For...
