ASSEMBLY TOOLS
73Pages

ASSEMBLY TOOLS High Speed Production | High Quality Tightening

TORQUE WRENCHES ASSEMBLY TOOLS Rami Yokota is a family owned trading business from the Netherlands, founded in 1896 and is now managed by the fourth generation. From selling bicycles, sewing machines and later on automotive and motor parts in the early 1900’s, the company moved on to importing high quality air tools from Japan in the early 60’s. Through continuous development, innovation and attention to service and building of technical skills, Rami Yokota grew to become a highly valued air tool supplier in Western Europe. Today the focus also includes Eastern Europe as well as...

BRANDS PRODUCTIVITY & ERGONOMICS Yokota industrial and Yokota assembly tools are of the highest quality standards imaginable. Yokota's tools are manufactured to last a lifetime with a specific focus on high productivity and ergonomics. Yokota impulse wrenches are used all over the world for tightening applications where accuracy, quality and speed are required. Yokota offers its impulse tools in air, battery and electric versions. A connection to all varieties of communication protocolls is also available. INDUSTRIAL TOOLS Red Rooster industrial tools, recognizable by a black logo, have...

ASSEMBLY TOOLS ASSEMBLY TOOLS SELECTION GUIDE SELECTION GUIDEGuideline Values for Tightening Torques Why bolt Connections? VDI 2862 1-2 A commonly used tool for choosing the right tool is VDI 2862-1 and part 2. This is a guideline drafted by the Verein Deutscher Ingenieure (Association of German Engineers). Part 1 is aimed at the automotive industry and Part 2 at general industry. This guideline has classified bolted connections into an A / B / C class. IN CASE OF A LOOSE BOLT CONNECTION: Tool malfunction: danger to life and limb Functional failure without direct consequences. The below...

ASSEMBLY TOOLS ASSEMBLY TOOLS SELECTION GUIDE SELECTION GUIDE Guideline Values for Tightening Torques Guideline Values for Tightening Torques VDI Yokota air impulse wrenches shut-off Yokota Air impulse wrenches non shut-off Yokota Air impulse wrenches Poka Yoke+ Yokota Cordless impulse wrench shut-off Yokota Cordless impulse wrench non shut-off Yokota Cordless system wrench torque control angle monitoring Yokota Electric system wrench torque control angle monitoring Yokota Air system wrench torque control Yokota Air system wrench torque control angle monitoring Red Rooster Air impulse...

ASSEMBLY TOOLS ASSEMBLY TOOLS SELECTION GUIDE SELECTION GUIDE Specified Torque Ranges Specified Torque Ranges With an impulse wrench, you bring optimal clamp force into the bolt connection which helps to reduce assembly time to a minimum. When it comes to accurate and fast assembly to the highest ergonomic standards, impulse technology is indispensable in the automotive industry, in the production of transport equipment and mechanical and plant engineering. The tools are quiet, lightweight and no kick-back. Impulse Wrenches with and without Shut-Off Nm Hard joint and soft joint Nm Ideal...

YOKOTA ASSEMBLY TOOLS ASSEMBLY TOOLS

ASSEMBLY TOOLS ASSEMBLY TOOLS YOKOTA IMPULSE WRENCHES YOKOTA IMPULSE WRENCHES Speed · Precision · Quality Intelligent Assembly Solutions Yokota International is a leading manufacturer of impulse based assembly tools for high-end production facilities. Yokota developed the first impulse air tools over 45 years ago and the benefits of impulse based assembly tools are wellknown all over the world these days: fast, light and with the highest clamping force, free from reaction forces. As an expert in the development, design and manufacturing of assembly tools, Yokota also embraces the...

ASSEMBLY TOOLS ASSEMBLY TOOLS SYSTEM WRENCHESControl Units Pneumatic system wrenches SYSTEM WRENCHESTKA Series: Electronic Torque Control & Angle Monitoring Pneumatic system wrenches Yokota developed its first system wrench more than 30 years ago. The purpose being the tightening of threaded fasteners at a high speed and accuracy, with the possibility of counting bolts in a group, detecting errors during tightening and interacting with the production line control systems, including the exchange of tightening data for traceability purposes. The latest developments are not only with a torque...

ASSEMBLY TOOLS ASSEMBLY TOOLS Pneumatic system wrenches SYSTEM WRENCHESTKA/YED Series: Torque ControlledSYSTEM WRENCHES Pneumatic system wrenches YEX Series: Torque ControlledPistol Type Pistol Type YEX-120A * Torque specifications: All specified torques are measured on the Yokota testers, Series YET, at a dynamic airpressure of 0.63MPa. The Yokota testers have a static transducer, the specified torques are therefore to be used as a guidance only. In general the torque range will be lower in case of using lower airpressure, extension bars, torx or hexagon inset sockets, soft joints, etc....

ASSEMBLY TOOLS ASSEMBLY TOOLS SYSTEM WRENCHES E-M Series, Electric Electric system wrenches SYSTEM WRENCHES YETC-500 Controller Electric system wrenches The Yokota electric system wrenches with integrated torque transducer and angle sensor offer a large reduction of energy consumption, a high degree of speed, accuracy and fantastic work efficiency. ELECTRIC DRIVE • Reduction of energy consumption Lean and Green. • No need for pneumatic installation with compressor, air piping, hose and solenoid valves. • No need for lubrication of the tool. Good for the working environment, especially near...

ASSEMBLY TOOLS ASSEMBLY TOOLS SYSTEM WRENCHESYS-E Series: Cordless YS-E Series: Cordless Yokota cordless impulse wrenches are powerful, very accurate and have no kick-back. With a battery power source the tool allows for the highest operational flexibility. This cordless impulse wrench has a built-in torque transducer and angle-sensor on the main shaft and a wireless connection to its controller. Each controller can connect with up to 4 operating cordless system wrenches. The Yokota cordless system wrench is the perfect solution for applications where cables or hoses are disruptive yet...
