S P E C I A L I S T S IN OVERHEAD CONVEYORS MONORAIL SYSTEMS

• • • • • • • • • • • • • • • • • • • • • • • • Flowcoat • • • • • • • • • • • • • • • • • • • • • • • • Bridge Crane

INDEX Bridge Cranes 44 46 Track Load Diagram Practical Values Monorail Bends Switches Turntables Switch Combinations Loadbar Brackets Monorail Interrupter Expansion Devices End Caps And Stopper Electric Lift-Lower Device End Lift-Lower Device Coupling Bridge Crane Semi Automated Systems Transfers 2 5 6 7 8 10 17 18 20 21 23 25 26 36 40 42 43 Cable Guidance 49 Our Devisions 50 • • • • • • • • • • • • • • • • • • • • • • • • Monorail

4 TRACKS The special cold rolled monorail tracks are available in 4 sizes, each is indicated by 6 figures: 230.000, 240.000, 250.000 and 260.000 . The standard lengths are 6 m. Intermediate lengths are also available. In a monorail project all tracks are cut to the exact dimensions. Type The tracks can be supplied in three different finishes: 1. The track is painted and not drilled. In this case the second series of 3 figures is indicated by: ...000... 2. The track is painted, drilled and tapped (at both sides) for a jointing bracket. In this case the second series of 3 figures is indicated...

6 PRACTICAL VALUES Distance between brackets = Xs 230.000 240.000 250.000 F Q F Q F Q 500 660 750 1000 1200 1500 2000 2500 3000 3500 4000 4500 – – – 250 220 150 75 40 20 12 7 – – – – 250 210 160 100 65 40 25 15 – – – – 500 440 300 150 80 40 25 15 8 – – – 500 420 320 200 130 90 60 40 25 1800 1400 1200 1000 900 625 340 200 110 60 40 25 1800 1400 1200 1000 850 700 500 300 200 140 100 70 In the table are some practical values of the maximum carrying capacity F in kg and for the equally divided load Q in kg/m as a function of the distance between brackets Xs in mm. These values apply for...

8 BENDS r + 100 r 90° r + 100 450 450 310 330 330 45° 560 560 900 45° 45° The standard track bends in a monorail system are supplied with a radius from 310 mm up to 1200 mm. On request the track bends can be manufactured with an other radius. The standard track bends are provided at both ends with a straight piece of track in order to ensure a perfect joining to the following straight track. We have various vertical bends available in our program as well. Angle Radius in mm Series 230.000 Series 240.000 Series 250.000 Series 260.000 90° 310 230.010 240.010 250.010 260.010 400 500 600 700...

MONORAIL 9 General The track bends with a radius up to and including 600 mm are provided with a vertical and drilled suspension plate. The track curves with a radius larger than 600 mm are fastened with clamps and standard brackets to an l-girder of the support steelwork. Suspension Piece Type A 320 The suspension piece type A is welded to the support steelwork and is applicable for track curves with a radius up to and including 600 mm. R 310 400/500/600 Reference 250.010.7 250.030.7 Suspension Piece Type B R 310 500 Reference 250.010.7 250.030.7 600 250.040.7 The suspension piece type B is...

14 SWITCHES 560 750 560 750 270 830 Composed T-Switches Composed T-switches (standard execution) Composed T-switches (shortened execution) pull chain “Y” right pull chain “Y” left 230.691/002 230.691/002 240.691/002 240.691/002 250.691/002 250.691/002 260.691/002 260.691/002 270 580 400 400 pull chain “Y” right pull chain “Y” left 230.781/002 230.781/002 240.781/002 240.781/002 250.781/002 250.781/002 260.781/002 260.781/002

TRACK SWITCHES 15 a b The load carrying direction tongue of this two way switch is held in a predetermined position by a spring mechanism. The spring mechanism is easy to reverse which makes it possible to choose between the running a or b (see figure) Code .../007 Ex. 250.520/007 Is used when the load is always transfered in the direction of the indicated arrows ( s e e f i g u r e ) Codification ...003 E.g. 250.520/003 Switch without operation (... .../003) Spring operated switch (... .../007) The pull mechanism of these 2 way switches is replaced by a specially adapted mechanism. As the...

16 TRACK SWITCHES Switch Combinations

TURNTABLES 17 Turntable The operation of a turntable can be either pneumatic or electric (Please contact our engineering department for the latter case). For pneumatic operation, the number of the operating valve is 230.500/029 (5/2). The turntable can only be operated without a trolley in the turntable. 230.731 240.731 250.731 4 2 3 5 220 380 220 380

18 SWITCH COMBINATIONS Switch/Turntable Combination A turntable is commonly used in combination with switches. In order to ease the mounting of these combinations, the use of the switches as follows on is strongly recommended, because of their specially adapted overall dimensions. 750 560 560 750 2*0.547/... 2*0.537/... 560 750 560 750 560 830 2*0.537/... 2*0.687/... 2*0.730/... 2*0.547/... 396 190 590 45° 45° 670 270 45° 396 2*0.537 2*0.547 right left 2*0.687

TRACK SWITCHES 19 Track switch operating devices Description of the switches with standard overall dimensions code - Y-switch - pull chain at the left ... .../001 - Switch with pull chain sidewards to the track curve ... .../002 - Y-switch with pull chain at the right ... .../002 - Switch without operation ... .../003 - Automatic switch for 2-wheeled trolley ... .../004 - Switch with lengthened pull chain ... .../005 - Y-switch with lengthened pull chain at the left ... .../005 - Switch with lengthened pull chain sidewards to the track curve ... .../006 - Y-switch with lengthened pull chain...
