Multiport Connectors
17Pages

{{requestButtons}}

Catalog excerpts

Multiport Connectors - 4

INTRODUCTION Coaxipack 2 sries has been designed in accordance with the IEC 61076-4-104 (standard 2 mm geometry system). Coaxipack 2 provides high density coaxial connectors aimed at high speed and space saving applications. Coaxipack 2 series is available in 50Q and 75Q. APPLICATIONS 50ft RANGE Telecom / Datacom (Transmission equipment, Satellite Communication Systems, Base station) 镕 Medical Networking industry Օ Instrumentation 750 RANGE High speed data network Օ Digital Broadcast System (Routers, Switching and Control Systems, Monitoring and Signal Measurement, Encoders - etc... )...

Open the catalog to page 4
Multiport Connectors - 5

INTRODUCTION MODULE Radiall offers a large range of pre-assembled modules. The term "module" is used for Coaxipack 2 connector mounting on board configuration. Օ One module combines a housing including one or more inserts. The number of inserts dpends on the required configuration, up to 6 contacts. 闕 Depending on the part number, one insert is made of one or two coaxial contacts CABLE ASSEMBLIES Radiall offers a standard kit including straight female insert and housing which fully compiles with the IEC 61076-4-104. TECHNOLOGY BREAKTHROUGH INNOVATION Interface: robust guidance and mating...

Open the catalog to page 5
Multiport Connectors - 6

CHARACTERISTICS ELECTRICAL CHARACTERISTICS Frequency range DC-3 GHz (Optimized) - (Working range up to 6 GHz) Impdance 50Q and 750 V.S.W.R mated pair for PCB modules straight female - cable assembly straight male - cable assembly DC-1 GHz < 1.08 < 1.15 < 1.13 1-3 GHz < 1.12 < 1.30 < 1.20 Insertion loss mated pair 0.2 dB typical from 0 to 3GHz RF leakage -35 dB at 3 GHz Voltage rating 500 V Dielectric withstanding voltage 750 V Insulation resistance > 5000 mft Contact resistance center contact outer contact Initial after environment test < 5 mft < 15 mft < 2.5 mft < 7.5 mft Rise time...

Open the catalog to page 6
Multiport Connectors - 8

PCB MODULES RIGHT ANGLE FEMALE PCB MODULES (500) 12.45 11.95 4 4 o--cni mWw 3 2 1 Recommended PCB thickness: 1.6 mm Insert (not sold separately] Number P ackaging □f contacts (Pi eces/tray) 2 R694 252 101 50 2 b a m R694 252 102 50 2 b a 3 R694 252 103 50 a ISήf R694 252 104 50 R694 252 105 50 b a m 3 1 R694 252 106 50 R694 252 107 50 To download data sheets and assembly instructions, visit www.radiall.com& enter the part number in the Search box. Bold part numbers represent products typically in stock & available for immediate shipment. See page 8 and 9 for packaging information.

Open the catalog to page 8
Multiport Connectors - 9

STRAIGHT MALE PCB MODULES (500) r Insert 3> imٗT ^ ' ^ 3 17.1 1 2 3 Insert [not sold separately] Recommended PCB thickness: 2 mm max B a m i R694 251 021 50 2 B a 2 R694 251 022 50 2 3» CD ttt 3 R694 251 023 50 [Si R694 251 024 50 R694 251 025 50 W R694 251 026 50 B a ta 123 R694 251 027 50 To download data sheets and assembly instructions, visit www.radiall.com& enter the part number in the Search box. Bold part numbers represent products typically in stock & available for immediate shipment. See page 8 and 9 for packaging information. www.radiall.com HADIAL1I The next connexion

Open the catalog to page 9
Multiport Connectors - 10

PCB MODULES RIGHT ANGLE MALE PCB MODULES (500 and 750) 5 --------- - ! jח! S uiuu Insert Recommended PCB thickness for 50Q: 1.6 mm for 75Q: 2.4 mm Insert (not sold separately] Packasin leces/tray) son Part number'11 Dimension a (mm) Extraction procשdure R694 251111 2.5 U01 25 R694 251112 2.5 U01 25 R694 251113 2.5 U01 25 R694 251114 2.5 U01 25 R694 251115 2.5 U01 25 R694 251116 2.5 U01 25 R694 251117 2.5 U01 25 Position of insert Part number'2' Dimension a (mm) Extraction procdure Packaging (pieces/tray) m R694 281 251 3.3 U01 25 b a ta 2 R694 281 252 3.3 U01 25 a|5I| R694 281 253 3.3 U01...

Open the catalog to page 10
Multiport Connectors - 11

FEEDTHROUGH MALE CABLE ASSEMBLY R694 261 906 + R199 001 203 or R199 001 223 STRAIGHT MALE HOUSING 3.5 11.95 4 4 Part number Note R694 261 906 For removable inserts (not included) 17.1 I I I 1 2 3 STRAIGHT MALE REMOVABLE INSERTS, FULL CRIMP TYPE 0C 03.5 maxi 0B 0A RG 178 2/50/S R199 001 203 ES 0.4 B 2.55 3.2 ± 0.1 U01 RG 174 2.6/50/S R199 001 223 0.6 1.8 2.92 3.2 ± 0.1 U01 7 diffrent possible configurations To download data sheets and assembly instructions, visit www.radiall.com& enter the part number in the Search box. Bold part numbers represent products typically in stock & available for...

Open the catalog to page 11
Multiport Connectors - 12

FEEDTHROUGH MALE MALE ADAPTER KITS _Panel thickness (see table) R694 261 906 + R199 001 733 FOR REMOVABLE INSERT (500) /CL B-a- 1 1 1 v ! uLi ! , 5 Fig. 1 i 1 2 3 Fig. 2 Housing R694 261 906(1) 1 Male male insert R199 001 733 2 3.2 ± 0.05 U01 FOR NON REMOVABLE INSERT (500) i i Fig. 1 Fig. 2 Fig. Dimension A (mm) Housing R694 261 076(1) 1 Non removable insert(2) R199 001 703 2 18 2 ± 0.1 R199 001 713 18.6 2.4 ± 0.2 (1) Kits including housing and inserts are available. Please consult sales. (2) Other length and PCB thickness available upon request: please consult sales. To download data...

Open the catalog to page 12
Multiport Connectors - 13

CABLE ASSEMBLY Each cable assembly consists of: one housing Օ one cover one latch Օ one or several inserts corresponding to customer's configuration inserts housing cover latch HOUSING Two types of h ousing for straight female cable assembly kit are offered: Type 1 Type 2 Available for 50O and 750 Available for 500 and 750 Type 1: HOUSING FOR FEMALE INSERTS 15.7 rt numb er R694 262 056 Straight inserts (see page 5-14) I for 50Q: R199 001 003 or R199 001 023 4 4 i ! I 3 2 1 for 75Q: R199 001 053 Type 2: HOUSING FOR FEMALE INSERTS WITH PRESS - IN FIXING STUD (for panel and PCB mounting]...

Open the catalog to page 13
Multiport Connectors - 14

waterproof for pdf table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:2.50pt "Arial", sans-serif; } .font1 { font:4.00pt "Arial", sans-serif; } .font2 { font:5.00pt "Arial", sans-serif; } .font3 { font:6.00pt "Arial", sans-serif; } .font4 { font:7.00pt "Arial", sans-serif; } .font5 { font:8.00pt "Arial", sans-serif; } .font6 { font:10.00pt "Arial", sans-serif; } .font7 { font:13.00pt "Arial", sans-serif; } .font8 { font:12.00pt "Times New Roman", serif; } .font9 { font:20.00pt "Times New Roman", serif; } .font10 { font:4.00pt "Trebuchet MS", sans-serif; } .font11...

Open the catalog to page 14
