QUIRI HYDROMECANIQUE WHOAREWE? www.quiri.com QUIFU Hydromécanique is specialized in designing and manufacturing of components and mechanical installations that use high-pressure fluids for process plant applications. We apply our know-how and experience to smal~and medium-scale manufacturing of products with high technical added-value. and to installations specifically adapted to our client's needs. To provide our clients with complete solutions. QUIRI Hydromécanique retains control over an the specialist skills involved in hydraulic engineering (electronic and mechanical engineering....

GENERAL TABLE OF CONTENT QUIRI 500 LIGHT ALLOY CYLINDERS QUIRI 700 STEEL CYLINDERS BOTTLE JACKS - SPECIAL CYLINDERS HAND PUMPS & AIR HYDRAULIC PUMPS HYDRAULIC PUMPS VALVES & FITTINGS HYDRAULIC PRESSES & PULLERS RERAILING EQUIPMENT

HYDRAULIC LIFTING & TOOLING EQUIPMENT ders Steel cylin ps lic pum Hydrau ight alloy Hand pumps & And also ... QUIRI reserves the right to change all information without prior notice due to products improvements - Non-contractual pictures and drawings

How to define your hydraulic equipment For higher security, efficiency and reliability, we recommend keeping a reserve of 20% or 30% when you choose your force, stroke, and tank oil capacity. Hydraulic equipment maintenance recommendations: • Maintain regularly your hydraulic equipment. Keep it away from dust and corrosive or dry atmosphere. • The equipment is warranted 1 year against manufacturing defects. Abusive or unsuitable use, modification of equipment and use of improper oil are not covered by the warranty. • Hydraulic equipments must be only repaired by a qualified hydraulic...

BASIC HYDRAULIC FORMULAS Definitions - Formulas - Units Force : The force developed by a cylinder corresponds to hydraulic pressure times its effective area. Units : F : Force in kN or in Ton P : Pressure in bar (kg/cm2) S : Effective area in cm2 Cylinder oil capacity : The volume required by a cylinder corresponds to its effective area times its stroke. Units : Vu : Cylinder oil capacity in cm3 S : Effective area in cm2 C : Stroke in cm If your equipment is composed by several cylinders, you have to add oil capacity of each cylinder to get total oil capacity of the equipment. Oil flow :...

CONVERSION TABLES Units of measurements - US threadings Conversion formulas : 1 kgf (kg force) = 9,81 Newton 1 N (Newton) = 0,1019 kgf 1 kN = 1000 N = 101,9 kgf Threading equivalences :

BASIC HYDRAULIC CONFIGURATIONS QUIRI 700 Range - Steel One single acting cylinder basic configuration Made of : • 1 hand pump : PMS710 • 1 pressure gauge adaptor : AM135 • 1 pressure gauge : MG700 • 1 hose hose 2m length : FC032 • 1 single acting cylinder : SEG545 Two single acting cylinders basic configuration Made of : • 1 hand pump : PMS733 • 1 pressure gauge adaptor : AM135 • 1 pressure gauge : MG700 • 1 hose 0,5m length : F030 • 1 manifold block : MF12 • 2 fittings : A31038 • 2 shut-off valves : VM38 • 2 hoses 2m length : FC032 • 2 single acting cylinders : SER2325 One double acting...

TABLE OF CONTENT QUIRI 500 LIGHT ALLOY CYLINDERS Single acting cylinders, spring return Hollow piston single acting cylinders, load return Hollow piston single acting cylinders, spring return Lock nut cylinders, spring return Step cylinders, spring return Telescopic cylinders Hollow piston double acting cylinders, hydraulic return Double acting cylinders, hydraulic return Couplers fitted on single acting cylinders Couplers fitted on double acting cylinders Single acting cylinders, load return Cylinders saddles QUIRI 500 CYLINDERS DESIGN • Corrosion resistant light alloy body. • Working...

SINGLE ACTING CYLINDERS - QUIRI 500 Single acting, load return Maximum pressure : 600 bar (stroke to be limited at 80% of the whole stroke) Corrosion resistant light alloy body (except 6T model in steel) Chrome plated piston rod Wiper seal Delivered in standard without coupler Options F : 4 base threaded mounting holes T : Threading of the hole ø16mm on SLS 6/20 Cylinders category Effective area CARRYING HANDLES Hand pumps and air hydraulic pumps : p 46 to 60

SINGLE ACTING CYLINDERS - QUIRI 500 Single acting, spring return Maximum pressure 600 bar (stroke to be limited at 80% of the whole stroke) Corrosion resistant light alloy body Chrome plated piston rod for cylinders 6, 10, 20T Corrosion resistant light alloy piston rod for cylinders 45, 75, 110T Wiper seal Delivered in standard without coupler Options A+B : Body collar thread with rubber protection F : 4 base threaded mounting holes T : Threading of the dz hole OPTION F Oil port Models 45, 75, 110 T Steel screwed saddles Cylinder category Effective area For 45T and 110T cylinders with...

LOCK NUT CYLINDERS - QUIRI 500 Single acting, spring return Maximum pressure 600 bar (stroke to be limited at 80% of the whole stroke) Corrosion resistant light alloy body Steel (zinc plate and chromate) piston rod for cylinders 10, 20 T Corrosion resistant light alloy piston rod for cylinders 45, 75, 110 T Delivered in standard without coupler Options A+B : Body collar thread with rubber protection F : 4 base threaded mounting holes T : Threading of the dz hole For screwed saddle Note : saddle must be always completely screwed Models 45, 75, 110 T Steel screwed saddle Oil port Cylinder...

STEP CYLINDERS - QUIRI 500 Single acting, spring return Corrosion resistant light alloy body and piston rod Fitted with : - Light alloy support frame - Strap carrying handles - Specially fitted with RM 518 coupler These cylinders can also be made with hydraulic return, please contact us Cylinder category Tons Support blocks, standard height 150 mm Under support frame Cylinder category Tons Effective area Hand pumps and air hydraulic pumps : p 46 to 60

TELESCOPIC CYLINDERS - QUIRI 500 Single acting, load return Spring return for piston N°2 (SLT 20/400) Corrosion resistant light alloy body Chrome plated or corrosion resistant light alloy piston rod Wiper seals Delivered in standard without coupler Options F : 4 base threaded mounting holes Models without saddle Models with integrated saddle Oil port Option dimensions: please see page 13 Other dimensions, see page 13 Piston n°1 Cylinder category Stroke Total Hand pumps and air hydraulic pumps : p 46 to 60 CYLINDERS SADDLES CARRYING HANDLES
