AIR COMPRESSORS VACUUM PUMPS AIR TREATMENT AIR SYSTEM AUDITING Performance You Demand. Reliability You Trust.

In 1924, Quincy Compressor introduced a line of air compressors that defined the industry standard for reliability. Today this same standard is renowned worldwide. Our full line of reciprocating and rotary screw compressors, integrated components, climate control systems, and vacuum pumps have been engineered for optimum efficiency and maximum productivity. And while our customers rely on this kind of cost-effective innovation, the future of compressed air demands it. Expanding on Quincy’s forward-thinking foundation requires a vision that is more than just a glimpse into the future. It requires...

3 A PERFORMANCE AND FINANCIAL ANALYSIS Industry Compressor kWh Examples per Industry Metrics Aluminum Can Manufacturing 258 kWh per 100,000 cans Foam/Plastic Cup Manufacturing 290 kWh per thousand cups Pulp and Paper Mill w/Woodyard 115 kWh per ton of paper Corrugated Box Plant 640 kWh per million sq. ft. Rubber Products Manufacturing 1088 kWh per 1000 tires BEST PRACTICE STANDARDS COST SAVINGS OPPORTUNITY EQ 50 hp 100 hp 500 hp Rating system system system 85% $ 3,552 $ 7,103 $ 35,516 75% $ 5,327 $ 10,655 $ 53,274 65% $ 7,991 $ 15,982 $ 79,911 Note: Calculated @$0.05 /kWh. QUINCY’S COMMITMENT...

RECIPROCATING COMPRESSORS The founders of Quincy Compressor were entrepreneurs and innovators. Propelled by the success of a unique reciprocating vacuum pump in the early 1920s, Quincy Compressor advanced the industry to meet changing customer demands. From vacuum pumps to single-stage compressors to splash-lubricated two-stage compressors, Quincy developed new products to meet the industry’s demand for more air at higher pressures. In 1939, Quincy Compressor introduced the Quincy QR-25 reciprocating compressor. Today, with more than 70 years of proven performance, the Quincy QR-25 stands as...

5 QUINCY QRDS™ QUINCY QRDT™ • QRDS - 2 to 30 horsepower • QRDT - 5 to 30 horsepower • QRDS - Single-stage, up to 100 psig cut out full load pressure • QRDT - Two-stage, up to 150 psig cut out full load pressure • Oil-less design based on Teflon™ industrial technology • Cast-iron crankcase and main bearing carrier • Permanent mold aluminum pistons and cylinders • High air temperature shutdown protection • Patented free-floating piston pin A CFM Model HP @100 PSIG* QRDS-2 2 6.1 QRDS-3 3 10.1 QRDS-5 5 17.2 QRDS-7.5 7.5 28.5 QRDS-10 10 36.3 QRDS-15 15 51.0 QRDS-20 20 65.1 QRDS-30 25-30 95.5/103.0...

ROTARY SCREW COMPRESSORS QuincyCompressor.com | Made in the U.S.A. | Performance You Demand. Reliability You Trust. 6 QUINCY QGV® • 20 –200 horsepower • Variable speed control to as low as 15% capacity • 75 – 150 psig full load operation • Maintains maximum efficiency across the broadest operating range • Available downstream pressure signal • Low Demand mode eliminates unloaded power losses • Speed Optimizer maxi- mizes performance and up time • Standard Royal Blue Warranty Model HP ACFM @ 1 00 PSIG* QGV-20 20 82 QGV-25 25 116 QGV-30 30 136 QGV-40 40 180 QGV-50 50 226 QGV-60 60 291 QGV-75 75...

7 QUINCY QGD™ Model HP ACFM @ 1 00 PSIG* QGD-20 20 90 QGD-25 25 118 QGD-30 30 139 QGD-40 40 189 QGD-50 50 226 • 20 – 50 horsepower • 100 – 150 psig full load capacity • Direct drive, 3600 RPM • Microprocessor control for easy networking • Low sound enclosure standard. 67-69 dBA • Standard C-Face mounted motor • Easy access to components for quick and simple maintenance • Optional integrated dryer saves installation costs • Tank-mount option available on 20, 25 & 30 horsepower units • Standard Royal Blue Warranty 10-Year Airend Warranty / 5-Year Major Component Warranty Everyone says they have...

CLIMATE CONTROL & MEDICAL SYSTEMS QuincyCompressor.com | Made in the U.S.A. | Performance You Demand. Reliability You Trust. 8 The Quincy Compressor climate control and medical air system compressors provide precise compressed air quality, combined with the reliability and low cost of ownership for which Quincy Compressor is known for. Every Quincy Climate Control System or Medical Air System is built for performance and bottom-line expectations. Also built into each system is a pedigree going back over a decade, with years of reliable, trouble free service. COMPLETE CONFIDENCE • 0.5 – 15 horsepower...

9 VACUUM PUMPS & NATURAL GAS With our compressor manufacturing and engineering expertise, we’ve created a complete vacuum system with all of the features of our rotary screw compressors. Quincy’s unique modulation valve delivers full flow from zero to ultimate vacuum. Quincy Compressor is your most reliable source for vacuum solutions. THE LEADER IN INDUSTRIAL VACUUM TECHNOLOGY Model HP ACFM FAD QSV 25 25 365 QSV 40 40 550 • 7.5 – 25 horsepower • Belt drive • Pumping speeds from 155 to 371 acfm • Attain a base vacuum of 29.9” (0.5 torr) • Positive lubrication fluid pump • Modulating inlet valve...

QuincyCompressor.com | Made in the U.S.A. | Performance You Demand. Reliability You Trust. 10 AIR TREATMENT PRODUCTS & FLUIDS While Quincy Compressor continues to define the future of reliability, we understand the importance of our environment and know that our future is dependent on how we utilize our resources today. This is why we introduced our complete line of Quincy Air Treatment products. Engineered to maximize the efficiency of your compressed air system, Quincy Air Treatment products help you meet production demand cleanly and efficiently. Quincy Filters remove solid contamination from...

11 • Particulate • Coalescers • Absorbers • Moisture Separators • High temperature design available • High pressure design available • 5 micron to 0.01 micron particulate removed • 5 ppm to 0.003 ppm liquid carryover • 1/4” to 3” NPT aluminum housings • 3” to 12” flanged steel housings • Delta P gauge • Auto drain • Color-coded glass filled nylon end caps • Push-to-fit element design • Low pressure drop/high efficiency • 10-year housing warranty QUINCY FILTERS QUINCY DRAINS QMAT - Electronic No Loss Drains • Reliable • Robust • Save energy • Low maintenance • Flexible ETD - Electronic Timer Drains...
