P.V.R.
PVR General Catalogue

PVR General Catalogue

Product catalog summary

Overview: The document provides comprehensive technical specifications and descriptions of various series of vacuum pumps and compressors, focusing on their construction, functionality, and industrial applications. The main series discussed include VS/CS, EM, PVL/EU, Ox, and Ex, each offering unique features and advantages.

VS/CS Series: These dry vane vacuum pumps and compressors feature graphite vanes and a monobloc design with the rotor directly mounted on the motor shaft, reducing weight and size. Benefits include non-polluting discharged air, quiet operation, and compact dimensions, suitable for various industrial applications with easy vane replacement.

EM Series: Designed for OEM customers, these lubricated vane monobloc vacuum pumps are known for reliability and innovative design. They offer compact size, multivoltage and multifrequency motors, quiet operation, high pumping speed, and easy installation, capable of continuous operation even at low vacuum levels.

PVL/EU Series: These single-stage oil-lubricated rotary vane vacuum pumps feature an oil recirculation system, suitable for air suction even in the presence of water vapor, and continuous industrial use. They offer high pumping speed, low noise, and robust construction, with capacities ranging from 18 m³/h to 1,239 m³/h.

Ox Series: Designed for food packaging installations using oxygen, these pumps are constructed with materials compatible with the pumped gas and synthetic oils, handling high concentrations of oxygen safely and efficiently.

Ex Series: Oil-lubricated vane vacuum pumps designed for ATEX environments, ensuring safe operation in potentially explosive atmospheres.

Technical Specifications: Detailed tables provide specifications such as nominal capacity, motor power, dimensions, weight, and ultimate pressure for each series, aiding in selecting the appropriate pump for specific industrial applications.

Specifications and Certifications: The CM series pumps, equipped with canned motors, are certified according to the 94/9/EC standards for ATEX Zone 0 (internal) with a temperature class T3 (200°C) and Zone 1 (external) with a temperature class T4 (135°C), ensuring suitability for hazardous environments.

Product Overview: The document describes various vacuum pump series, including the CM, HV, and GC series. The CM series is designed for ATEX environments, the HV series includes Aerzener vacuum blowers, and the GC series offers compact vacuum groups combining high performance with reduced size.

Performance and Features: The GC series vacuum packages provide easy installation, a maximum ultimate vacuum of 0.01 mbar, and a maximum capacity of 1,700 m³/h. They are energy-efficient due to low motor power requirements and have compact dimensions, reducing operating and maintenance costs.

Central Vacuum Systems: The MEDISYSTEM series is designed for medical facilities, complying with EN ISO 7396-1 standards. These systems include a vacuum central with three pumps, a vacuum tank with switches, a touch-screen control panel, and antibacterial filters, available as turnkey systems or components for existing setups.

Customized Solutions: Customized central vacuum systems (CSZ/CDZ series) can be tailored to specific customer needs, offering options for horizontal or vertical tanks to optimize space usage.

Applications: Vacuum groups are designed for processes like degassing, heat treatments, drying, freeze-drying, and closed chamber pumping, achieving high ultimate pressures (up to 10^-5 mbar) in limited spaces.

Accessories: Air filters (Series F) made of printed steel with treated paper cartridges offer 7-micron filtration power, maintaining vacuum integrity. P.V.R. dust filters are vacuum-tight with a steel container and treated paper filter cartridge, available with a stainless steel cartridge with a 60-micron filtration grade.

Lubricants: A wide range of mineral and synthetic oils is offered, suitable for various fields from food to chemical industries.

Service Kits: P.V.R. provides service kits containing necessary spare parts for routine and major maintenance of pumps.

Oil Mist Traps: These traps effectively remove oil mist using a double filtering system, ensuring a pollution-free working environment.

Medical Filters: The CMV series antibacterial filters offer high filtration efficiency (99.999%) to prevent the spread of viruses and bacteria.

Filter Water Trap: Recommended for applications where the pump intakes small quantities of liquids.

Customer Service: The technical and sales departments offer comprehensive advice on vacuum pump applications and maintenance. A wide network of distributors ensures availability and efficient after-sales service worldwide.

Catalog excerpts

Catalogo Generale • General Catalogue • Allgemeiner Katalog • Catálogo General www.pvr.it

Open the catalog to page 1

PVR S.r.l. L’Azienda The Company Die Firma La Empresa È iniziata nei primi anni 60 la produzione delle pompe per vuoto “Rotant”. L’esperienza acquisita in questi anni, la continua ricerca e sviluppo, la modernità dei macchinari e la corretta preparazione del personale ci consentono di offrire un prodotto di elevata qualità ed affidabilità. Il nostro ufficio tecnico-commerciale assicura una consulenza completa per la scelta delle nostre pompe per vuoto. Il nostro Servizio Post-Vendita assiste i clienti per l’utilizzo e la manutenzione dei nostri prodotti. Il nostro magazzino garantisce una rapida...

Open the catalog to page 2

1 Pompe per vuoto e compressori a membrana Diaphragm vacuum pumps and compressors Membranvakuumpumpen und Kompressoren Bombas de vacío y compresores de membrana 2-3 Pompe per vuoto e compressori a pistone Piston vacuum pumps and compressors Kolbenvakuumpumpen und Kolbenkompressoren Bombas de vacío y compresores de pistón 4 Pompe per vuoto a palette Vane vacuum pumps Drehschiebervakuumpumpen Bombas de vacío de paletas 5 Pompe per vuoto e compressori a secco a palette Dry vane vacuum pumps and compressors Trockelaufende Drehschieber-Vakuumpumpen und Kompressoren Bombas de vacío y compresores en...

Open the catalog to page 3

2 Portata nominale Nominal capacity Nennsaugvermögen Caudal nominal Pressione Pressure Druck Presión Vuoto (Assoluto) Vacuum (Abs) Vakuum (Abs) Vacío (Absoluto) Tensione* Voltage* Spannung* Tensión* Dimensioni Dimensions Abmessungen Dimensiones Peso Weight Gewicht Peso M41 S A.C. 03 M41 S D.C. 52 8 9,5 2 200 110/230 A.C. 140x74x104 1,310 l/min bar mbar volt mm Kg 8,5 2,5 200 12/24/110/220 D.C. 131x60x104 0,620 50 Hz 60 Hz M41 BX A.C. 04 M41 BX D.C. 53 16 8 19 9,5 Parallello / Parallel Serie / Series Parallello / Parallel Serie / Series 17 8,5 Parallello / Parallel Serie / Series 200 40 200 40...

Open the catalog to page 4

3 Portata nominale Nominal capacity Nennsaugvermögen Caudal nominal M71 S A.C. 05 M71 S D.C. 54 M71 BX A.C. 08 M71 BX D.C. 55 56 30 68 36 Parallello / Parallel Serie / Series Parallello / Parallel Serie / Series 33 0,7 100 12/24 D.C. 177x90x130 1,90 30 36 0,7 100 110/230 A.C. 169x81x130 2,13 Parallello / Parallel Serie / Series Parallello / Parallel Serie / Series Parallello / Parallel Serie / Series 62 33 110/230 A.C. 194x153x94 3,20 0,7 1,3 100 15 Parallello / Parallel Serie / Series Parallello / Parallel Serie / Series 0,7 1,3 100 15 12/24 D.C. 230x153x94 2,70 Serie M Pompe per vuoto e compressori...

Open the catalog to page 5

4 Serie P Pompe per vuoto e compressori a pistone Piston vacuum pumps and compressors Kolbenvakuumpumpen und Kolbenkompressoren Bombas de vacío y compresores de pistón I compressori a pistone hanno il cilindro in acciaio speciale, il pistone, la biella, i supporti e la testata in nylon caricato. Vengono forniti completi di motore alimentato in corrente alternata monofase oppure in corrente continua. Sono disponibili in versione con singolo o doppio pistone per l’impiego in parallelo ed in serie. Sono completamente oil free, privi di manutenzione, ed oltre che per generare pressione possono essere...

Open the catalog to page 6

5 l w h Die Drehschiebervakuumpumpen haben das Pumpengehäuse mit Stator und Deckeln aus gesintertem Material, gesinterten Rotor aus Messing, und Schieber aus gehärtetem Stahl. Pumpen sind mit einem einphasigen Wechselstrommotor oder mit einem zweiphasigen Gleichstrommotor ausgerüstet. Die Drehschiebervakuumpumpen werden sowohl zur Vakuumerzeugung, als auch zur Luftverdichtung eingesetzt. Die Pumpen können mit einfachem oder doppeltem Gehäuse hergestellt werden. Die Ausführung mit doppeltem Gehäuse erlaubt die Parallelschaltung der beiden Gehäuse oder den Einsatz in Serie. Drehschiebervakuumpumpen...

Open the catalog to page 7

6 Serie VS/CS Pompe per vuoto e compressori a secco a palette Dry vane vacuum pumps and compressors Trockelaufende Drehschieber-Vakuumpumpen und Kompressoren Bombas de vacío y compresores en seco de paletas Le pompe per vuoto della serie VS con i compressori della serie CS funzionano a secco con palette in grafite. Sono in forma costruttiva monoblocco con il rotore montato direttamente sull’albero del motore riducendo così peso ed ingombri. I principali vantaggi sono: - Aria allo scarico non inquinante priva di vapori d’olio ed assolutamente secca - Funzionamento molto silenzioso - Dimensioni...

Open the catalog to page 8

7 Le pompe per vuoto della serie EM sono state progettate per soddisfare le esigenze dei clienti costruttori di macchine ed impianti nei molteplici settori industriali. La serie EM, innovativa nel design e dalle ottime caratteristiche di funzionamento, si posiziona, per la sua affidabilità, ai vertici del mercato. Principali caratteristiche: Peso ed ingombri molto ridotti - Gas ballast (escluso EM 4) - Valvola di non ritorno (escluso EM 4) - Motori multi-tensione e multi-frequenza - Funzionamento silenzioso - Alta velocità di pompaggio - Semplice installazione - Funzionamento continuo anche a...

Open the catalog to page 9

9 Serie PVL/EU Pompe per vuoto lubrificate a palette Lubricated vane vacuum pumps Drehschiebervakuumpumpen mit Umlaufschmierung Bombas de vacío de paletas lubrificadas Con l’adozione di una tecnica costruttiva d’avanguardia e l’impiego durante la fase di lavorazione di moderni centri di lavoro a controllo numerico, le pompe per vuoto PVR riuniscono ad elevati standard di qualità e rendimento, caratteristiche di economicità d’impiego quali: Alta velocità di pompaggio nel campo di pressione assoluta compresa tra 850 mbar e 0,5 mbar - Rumorosità estremamente contenuta - Assenza di inquinamento -...

Open the catalog to page 11

10 Serie Ox Pompe lubrificate a palette per impiego con ossigeno Oil lubricated vane vacuum pumps Ölgeschmierte Drehschieber-Vakuumpumpen zum Ansaugen von Sauerstoff Bombas de paletas lubrificadas mpiego mps for pumping oxygen kuumpumpen p p p g yg para aspiración de oxígeno PVL 15 Ox PVL 35 Ox 50 Hz 60 Hz 50 Hz 60 Hz EU 45 Ox 50 Hz 60 Hz EU 65 Ox 50 Hz 60 Hz EU 105 Ox 50 Hz 60 Hz EU 160 Ox 50 Hz 60 Hz 50 Hz 60 Hz EU 205 Ox 50 Hz 60 Hz EU 300 Ox PVL 401 Ox 50 Hz 60 Hz PVL 541 Ox 50 Hz 60 Hz EU 650 H Ox 50 Hz 60 Hz 50 Hz 60 Hz EU 750 Ox 50 Hz 60 Hz Portata nominale Nominal capacity Nennsaugvermögen...

Open the catalog to page 12
