PUROCEPT™ INNOVATIVE MULTI-ZONE MELT BLOWN FILTER CARTRIDGES

PUROCEPT™ Innovative Multi-Zone Melt Blown Filter Cartridges PUROCEPT Series depth filter cartridges provide high performance filtration of fluids in a wide range of applications. This series of high performance filter catridges is manufactured with a proprietary microprocessor controlled process that creates a highly consistent product. The polypropylene materials of construction are chemically inert—allowing PUROCEPT cartridges to be used in a wide range of demanding applications. PUROCEPT cartridges deliver high efficiency, long service life and improved strength. Purolator’s proprietary Puro-Zone...

• Removal ratings from 0.5 to 30 ìm. • Proprietary Puro-Zone technology allows the creation of multiple filtration zones within the depth of the filter cartridge. • Continuous gradient structure provides effective prefiltration and final filtration. • Advanced microprocessor controlled manufacturing process delivers an extremely accurate and consistent product. • High-strength polypropylene center core maximizes flow and optimizes each filtration zone. • 100% polypropylene materials of construction allow use in a wide range of demanding applications. • PUROCEPT™ cartridges are binder, adhesive...

HIGH STRENGTH SUPPORT CORE • Withstands rigorous applications • Allows optimization of media for filtration ADVANCED MELT BLOWN FILTER MEDIA PURO-ZONE FILTRATION TECHNOLOGY • Continuous gradient pore structure • Binder, adhesive and surfactant free OPTIONAL O-RINGS OR GASKET SEALS • Improved cartridge-to-housing seal • Prevents fluid bypass PUROCEPT INNOVATIVE DESIGN ™ MICROGRAPHS DEPICTING THE GRADED PORE STRUCTURE OF PUROCEPT SERIES FILTERS (Magnification 200x) Outer Prefiltration Zones Intermediate Prefiltration Zones Intermediate Prefiltration Zones Final Filtration Zone

• Consistent filtration as differential pressure increases • Cartridge will not randomly unload contaminant in pulse flow conditions • High flow rates at lower differential pressures • Outside layers offer cost effective filtration of larger particles while inner layer provides precise fine contaminant retention • Chemically inert • Extensive chemical resistance • High collapse strength • Solid temperature resistance • Optimized flow distribution • Highly efficient filtration performance • Higher void volumes than competitive products • Highly consistent product • Minimal variability across lots...

MICRON RATING: 0.5, 1, 5, 10, 20, 30 ìm MAXIMUM FORWARD DIFFERENTIAL PRESSURE: 25 psid (1.7 bar) @ 150° F (66° C) 60 psid (3.4 bar) @ 86° F (30° C) RECOMMENDED CHANGE OUT DIFFERENTIAL PRESSURE: 35 PSID (2.4 bar) BIOSAFETY: All polypropylene components meet the specifications for biological safety as per the USP for Class VI-121° C plastics. FDA LISTED MATERIALS: Manufactured from material which are listed for food and beverage applications in Title 21 of the U.S. Code of Federal Regulations. NSF CERTIFICATION APPLIED FOR HIGH PURITY CONSTRUCTION: PUROCEPT Series filter cartridges are free of...

APPLICATIONS PUROCEPT filter cartridges provide superior filtration performance for a wide range of critical commercial and industrial applications such as those shown below. • Bottled water, wine pre-filtration, wine final cellar filtration, beer filtration (trap filter), fruit juice, soft drinks, spirits, sugar solutions • Process water pre-filtration, hot water heating systems, cooling water, cooling towers • Solvents, water, paint, clear coat, inks, automotive coatings, industrial coatings, lacquers • Bulk chemical filtration, acrylates, alcohols, bleach, alkalis, acids, make-up water, sodium...

Purolator Advanced Filtration • Made in USA 255 Standard Drive • Greensboro, NC 27409 Tel: 800.852.4449 or 336.668.4444 • Fax: 336.217.4352 Email: [email protected] • Web: www.purolator-afg.com 02/06 Printed in the USA Copyright by Purolator Facet, Inc. PCT 2/06 INNOVATIVE MULTI-ZONE MELT BLOWN FILTER CARTRIDGES FROM PUROLATOR ADVANCED FILTRATION
