Tungsten Electrode Sharpener & Grinder UTG1

Product catalog summary

Overview: The UTG1 Tungsten Electrode Sharpener & Grinder is designed for precise and repeatable electrode geometry, crucial for quality TIG welding. It addresses issues like unstable arcs and electrode contamination by ensuring consistent preparation.

Key Features:

Ensures precise and repeatable electrode geometry.
Stabilizes arc behavior, improving ignition, stability, and consistency.
Combines grinding, sharpening, and cutting in one device.
Improves electrode lifespan and reduces costs related to consumables and weld rework.
Operates dry, eliminating coolant maintenance.
Compact, lightweight (2.06 kg), and portable for on-site use.
Robust and flexible design with a 220V or 110V electric motor, available in battery or corded versions.

Technical Specifications:

Weight: 2.06 kg (4.41 lb)
Motor: Electric 220V or 110V, 720W power
Motor Speed: 11,000 rpm (unloaded)
Electrode Diameters: 0.04" (1mm) to 0.157" (4mm)
Sharpening Angles: 15°, 18°, 22.5°, 30°
Diamond Wheel Diameter: 50mm (1.97")
Noise Level: 85-96 dB

Options and Accessories:

Device to plug a vacuum cleaner
Machine Bench
Dust Cover
Stop/Cut to Length
Transport Case

Ordering Information:

UTG-1-1020: Electrode grinder with 220V electric drive
UTG-1-1022: Electrode grinder with 220V battery electric drive
UTG-1-1040: Electrode grinder with 110V electric drive
UG-1-1115: Diamond wheel

Catalog excerpts

Tungsten Electrode Sharpener & Grinder UTG1-1

UTG1 Tungsten Electrode Sharpener & Grinder ULTIMASTER DISTRIBUTED BY PROTEM PROTEM SAS PROTEM GmbH 215 rue de la Raye 4 A Rue des Artisans Am Hambiegel 27 E-Mail address: [email protected] E-Mail: [email protected] Website: www.protem.fr Web: www.protem-gmbh.de PROTEM USA LLC 29340 Industrial way #402 Evergreen CO 80439 | USA Phone: +1 303 955 4862 E-Mail: [email protected] Web: www.protemusa.com Pictures, drawings and technical information are not contractual

Open the catalog to page 1

Tungsten Electrode Sharpener & Grinder UTG1-2

UTG1 Tungsten Electrode Sharpener & Grinder TUNGSTENE ELECTRODE: SHARPENING ; POINTING ; CUTTING MACHINE FOR TIG WELDING The UTG1 is a TIG electrode grinder designed to ensure precise and repeatable geometry, regardless of the operator. In orbital TIG welding, the electrode is an critical component: the quality of the weld directly depends on its preparation. A poorly sharpened electrode can lead to unstable arcs, burn under high currents, or contaminate the weld pool. Thanks to its calibrated angles and guiding system, the UTG1 eliminates variations linked to manual sharpening and stabilizes...
