PROEX TECHNOLOGY Explosion-proof Local Control Station PROEX TECHNOLOGY Explosion-proof Local Control Station Technical Parameters Number of control switch Control switch (optional) Number of indicator Indicator (optional) Number of ammeter/voltmeter Ammeter/oltmeter (optional) Number of push button Push button (optional) Dimension drawings (all dimensions in mm)- subject to alteration For Ex d llB Aluminum Alloy ◇ Explosion-proof mark： For Ex e type enclosure Global(IECEX):Ex d e IIC T6 Gb Europe(ATEX): II 2 G Ex d e IIC T6 Gb、 II 2 D Ex tb IIIC T80℃ Db IP65 For Ex d type enclosure Global(IECEX): Ex db IIB+H2 T6 Gb, Ex tb IIIC T80℃ Db IP66 Europe(ATEX): II 2 G Ex db IIB+H T6 Gb、 II 2 D Ex tb IIIC T80℃ Db IP66 ◇ Certificates：IECEX, ATEX, CNEX. ◇ Conformity to standards: EN 60079-0,EN 60079-1.EN 60079-7.EN 60079-31 IEC 60079-0,IEC 60079-1,IEC 60079-7.IEC 60079-31 ◇ Protection grade：IP66 ◇ Enclosure Material: GRP、Copper-free Aluminium Alloy、Stainless Steel ◇ Exposed Fastener: Stainless Steel ◇ Max working voltage: 415V AC ◇ Rated voltage: 10A ◇ Ambient temperature: -60℃~+55℃(Ex db IIB Aluminum Alloy enclosure) -20℃~+55℃(Ex e IIC Aluminum Alloy&Stainless steel enclosure) ◇ Mounting：Surface type Explosion-proof control stations Applications ◇ Explosion protection to CENELEC、EC、NEC. ◇ Can be used in Zone 1 and Zone 2 Zone 21 and Zone 22 Class l, Zone 1 and Zone 2 Class l, Division 2, Groups A, B, C, D ◇ Stainless steel、Copper-free Aluminum Alloy enclosure ◇ Several types of en

PROEX TECHNOLOGY (ProEx) PROEX TECHNOLOGY BZC Series Explosion-proof Local Control Station Explosion-proof Local Control Station Dimension drawings (all dimensions in mm)- subject to alteration Dimension drawings (all dimensions in mm)- subject to alteratio
