Precision Brand Products 2007 Catalog

Precision Brand Products 2007 Catalog

Product catalog summary

Overview: This document provides comprehensive specifications and descriptions for various mechanical application products, including keys, clamps, tool wraps, keystock, protective coatings, punch & die sets, wire, layout fluids, markers, blackeners, feeler gages, shim stocks, slotted shims, arbor shims, hose clamps, threaded rods, and nuts. Each product is detailed with its material quality, dimensions, and specific usage recommendations.

1. Keys and Clamps:

Plated Steel Keys: Used for pulleys and drive shaft applications.
Stainless Steel Woodruff Keys: Corrosion-resistant for similar applications.
Plastic Hose Clamps: Heat-stabilized, lightweight, and corrosion-resistant, suitable for motor applications.

2. Tool Wrap:

Made from Type 321 or 309 stainless steel, protects against scale and oxide buildup during heat treating, withstanding temperatures up to 2000°F for Type 321 and 2240°F for Type 309.

3. Keystock:

Steel Keystock: Provides driving torque between shafts and pulleys, made from high-quality steel with oversized tolerances for tight fits.
Stainless Steel Keystock: Offers corrosion resistance, suitable for food and marine applications.
Metric Keystock: Conforms to metric specifications, available in various sizes with gold dichromate plating for easy identification.

4. Protective Coatings:

Hot Melt Coating: Protects tools and metal parts from damage during storage and shipping, available in two types and multiple colors.

5. Punch & Die Sets:

TruPunch® Sets: Self-centering punch & die sets for making washers, shims, and gaskets, available in standard and metric sizes.
Punch & Die Stand: Provides support for consistent fabricating, reducing risk of injury and improving efficiency.

Wire Specifications: PRECISION BRAND offers Music Wire and Stainless Steel Wire, both spring tempered, with high tensile strength and fatigue resistance. Available in various diameters and tensile strengths, with packaging options including shrink-wrapped and bar-coded dispenser boxes.

Layout Fluid and Remover: Layout Fluid provides a uniform, deep color to prevent glare and allows for precise scribing. The Layout Fluid Remover prepares metal surfaces without harmful solvents.

Brite-Mark Medium Markers: Create permanent marks on various surfaces, with a valve action mechanism to prevent drying.

Tool Black and ABC Blackener: Tool Black provides a protective finish to ferrous metals, while ABC Blackener is designed for non-ferrous metals like aluminum, brass, and copper.

Steel Feeler Gage: Made from high carbon steel, used for precise spacing and tolerance checks, available in various lengths and thicknesses.

Shim Stocks: Detailed specifications for stainless steel, brass, steel, blue tempered, aluminum, copper, and color-coded plastic shims, including thicknesses, dimensions, and packaging options.

Slotted Shims: Designed for alignment and leveling of machinery, available in various sizes and thicknesses, with specific dimensions and tolerances.

Arbor Shim Assortment Kits: Include a variety of commonly used arbor shims made from high-quality low carbon cold rolled steel.

Hose Clamps: Various types including M-S Series All Stainless, Shielded/Lined, Micro Seal® Miniature, Heavy Duty, Collared Screw, Quick Release, and Create-A-Clamp, each designed for specific applications.

Threaded Rods: Made from high-quality low carbon steel, with options in stainless steel, high strength B-7 alloy, and left-hand threading.

Specialty Products: Include 316 Stainless Steel Hose Clamps and All Stainless Military Hose Clamps, suitable for corrosive environments and manufactured to military standards.

Conclusion: The document serves as a detailed guide for selecting appropriate products based on specific mechanical application requirements, emphasizing material quality and specific use cases.
