Sampling ball valve S4

Product catalog summary

General Specifications:
The Sampling Ball Valve S4 is available in two material options: PVC-U and PVDF. It features sealing materials made of EPDM or FPM and a ball seating joint of PTFE. The valve is designed with dimensions of DN6.

Connector Types:
For PVC-U, the valve includes body and hose nozzle options with BSP/NPT threads, male and female threads, and double nipple configurations. PVDF options include body and hose nozzle with BSP/NPT threads and double nipple configurations.

Operating Pressure:
The valve operates at a pressure of PN 10 for sizes DN6 1/4" and 3/8".

Technical Features:
The valve includes a lock and metering ring to prevent unwarranted opening and to adjust ball opening angles. It can be fully opened by removing the lock and metering ring. The design is compact, lightweight, corrosion-resistant, and the PVDF version is oil and silicone-free.

Dimensions:
Detailed dimensions are provided for both PVC-U and PVDF versions, with specific measurements for various thread types.

Exploded Drawing Components:
The valve consists of components such as a handle, O-rings, lock and metering ring, body, ball seating joint, ball, thrust collar, circlip, hose nozzle, double nipple, plug, and clip tie.

Additional Features:
The valve includes three metering marks for flow regulation and can be installed using a wrench (SW22 or SW24). The lock and metering ring can be stored on the valve body when not in use, and the plug can be secured with a clip tie. The locking mechanism prevents unwarranted opening or closing.

Diagrams:
The document includes flow characteristics and a pressure-temperature diagram to illustrate performance metrics.

Catalog excerpts

Technical data Sampling ball valve S4 PRAHER W PLASTICS Jr www.praherplastics.com General: • Material: • Sealing material: • Ball seating joint: • Dimensions: Connector types: PVC-U • Body • Hose nozzle Male thread • Hose nozzle Female thread • Double nipple • Plug PVDF • Body • Hose nozzle Male thread • Double nipple • Plug Operating pressure: • DN6 1/4“ 3/8“ PN 10 Technical features: • Lock and metering ring for protection of sampling ball valve from any unwarranted opening • Lock and metering ring for adjustment of ball opening angles • Sampling ball valve can be 100% opened at any time by removing the lock and metering ring • Compact design • Low weight • Corrosion resistant • PVDF Sampling ball valve is Oil & Silicone-free This document does not constitute a guarantee, it is for initial information purposes only. The product range is continually upgraded, the design and types therefore only reflect the state of the art at the time of printing. Subject to technical modifications! PVC-U / PVDF EPDM / FPM PTFE DN6 BSP/NPT BSP/NPT BSP/NPT BSP - NPT NPT - NPT BSP BSP/NPT BSP BSP/NPT BSP Praher Plastics Austria GmbH DB/EN/DEEN/15/02/324B Subject to technical modifications!

Open the catalog to page 1

Technical data Sampling ball valve S4 PRAHER PLASTICS Dimensions: Exploded drawing: 01. Handle 03. Lock and metering ring 06. Ball seating joint 11. Hose nozzle male thread 15. Hose nozzle female thread www.praherplastics.com

Open the catalog to page 2

PRAHER PLASTICS Technical data When not in use, lock and metering ring can be hanged on sampling ball valve body When not in use, plug can be fixed with the clip tie on the sampling ball valve body. In closed position, the lock and metering ring protects the valve against unwarranted opening. In open position, the locking ring protects the valve against unwarranted closing. The sampling ball valve can be installed on the pipeline with a wrench SW22 or SW24. Praher Plastics Austria GmbH DB/EN/DEEN/15/02/324B Subject to technical modifications!

Open the catalog to page 3

Technical data Sampling ball valve S4 Diagrams: Pressure-temperature-diagram Flow characteristics © Praher Plastics Austria GmbH DB/EN/DEEN/15/02/324B Subject to technical modifications! Opening angle

Open the catalog to page 4
