Goldfish Catalog

Product catalog summary

Introduction
The document introduces the Goldfish Connector Series, highlighting its precision-formed female signal contacts that offer cost efficiency and reduced mating force.

Specifications

GFSH928F-Series: Contains 18 Size 16 power contacts and 28 Size 22 signal contacts.
Materials: Insulator is glass-filled nylon, UL 94V-0 rated. Contacts are copper alloy with gold over nickel plating.
Electrical Characteristics: Size 16 contacts support up to 30 amperes; Size 22 contacts support 1 ampere. Insulator resistance is at least 5 G ohms.
Mechanical Characteristics: Features a blind mating system with 2.00 mm misalignment tolerance. Contact retention is 45 N for power and 27 N for signal contacts.
Climatic Characteristics: Operating temperature ranges from -55°C to +125°C.

Ordering Information
Specify PA688 for connectors with precision-formed signal contacts.

GG Series Overview
The GG Series offers modular power connectors with 256 versions, featuring hot plug-blind mating and safety contacts.

Technical Characteristics

Materials: Insulators are glass-filled nylon; contacts are copper alloy with gold flash over nickel.
Electrical Characteristics: Size 0 contacts support up to 200 amperes; Size 20 contacts support 5 amperes.
Mechanical Characteristics: Blind mating system with 4.50 mm misalignment tolerance. Contacts are removable with a closed entry design.
Climatic Characteristics: Operating temperature ranges from -55°C to +125°C.

Additional Features
Includes temperature rise curves, outline dimensions, and accessories, emphasizing the importance of allowing removable contacts to float for superior mating performance.

Materials and Finishes
Contacts and locking clips are copper alloy, with nylon for the male probe plug and dielectric overmold. Finish is gold flash over nickel, with silver plating available upon consultation.

Assembly Procedure for Crimp Termination

Strip cable insulation by 20mm without damaging conductor strands.
Insert conductor wire strands into the crimp barrel, ensuring visibility through the inspection hole.
Use a crimping tool to crimp the contact, keeping the cable straight and touching the contact stopper.
Examine crimp joints for satisfactory completion.
Insert the crimp contact into the insulator, align the locking clip groove, and press in the locking clip.
Ensure the locking clip is flush with the insulator.

Recommended Tools
Specific tools are recommended for different contact sizes, including adjustable hand crimp tools and contact extraction tools, with specified part numbers.

Ordering Information
Connectors are specified through steps including series, version, gender, contact type, mounting style, environmental compliance, and special options, with part number examples provided.

Contact Information
Positronic Industries provides contact details for sales offices in North America, Europe, and Asia/Pacific, including phone numbers and email addresses.

Catalog excerpts

tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 1

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:13.00pt "Arial", sans-serif; } .font5 { font:19.00pt "Arial", sans-serif; } .font6 { font:8.00pt "Microsoft Sans Serif", sans-serif; } GFSH02F4LN^^^ GoldFish Power Connectors Feature!!! Excellent Power Density Օ Blind mate - Float mounting 20, 35 and 50 ampըre power contacts Hot Plug Capability Օ AC, DC and Signal contacts in one connector Safety Agency...

Open the catalog to page 2

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:10.50pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:15.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial Black", sans-serif; } .font5 { font:9.00pt "Microsoft Sans Serif", sans-serif; } .font6 { font:4.00pt "Tahoma", sans-serif; } GOLDFISH Goldfish Power Connectors Connector versions and technical characteristics Connector Versions GFSH435: Fully popuiated connecter Number of size 12 power contacts: 4 Number of size 16 power contacts: 9 Number...

Open the catalog to page 3

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:19.00pt "Arial", sans-serif; } .font8 { font:20.00pt "Arial", sans-serif; } .font9 { font:14.00pt "Arial Black", sans-serif; } .font10 { font:9.00pt "Microsoft Sans Serif", sans-serif; } GOLDFISH Goldfish Power Connectors...

Open the catalog to page 4

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:14.00pt "Arial", sans-serif; } .font4 { font:15.00pt "Arial", sans-serif; } .font5 { font:17.00pt "Arial", sans-serif; } .font6 { font:9.00pt "Arial Black", sans-serif; } GOLDFISH Straight and Right Angle (90°) PCB Mount Connectors Baby Goldfish Versions 109 and 624 Outline Dimensions Maie Connecter Female Connector -56.00 [2.205]-47.00 [1.8501- ■56.00 [2.205]--47.00 [1.850] 12.50 [0 492] _t r 12.50...

Open the catalog to page 6

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:12.00pt "Arial", sans-serif; } .font5 { font:14.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:17.00pt "Arial", sans-serif; } .font8 { font:20.00pt "Arial", sans-serif; } .font9 { font:34.00pt "Arial", sans-serif; } .font10 { font:9.00pt "Arial Black", sans-serif; } .font11 { font:14.00pt "Arial Black", sans-serif;...

Open the catalog to page 7

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:12.00pt "Arial", sans-serif; } .font5 { font:15.00pt "Arial", sans-serif; } .font6 { font:17.00pt "Arial", sans-serif; } .font7 { font:9.00pt "Arial Black", sans-serif; } .font8 { font:14.00pt "Arial Black", sans-serif; } .font9 { font:10.00pt "Times New Roman", serif; } GOLDFISH n ,Dc-*t■ Compilant Press-Fit Terminations See Step 4 of Ordering Information...

Open the catalog to page 8

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:11.00pt "Arial", sans-serif; } .font4 { font:12.00pt "Arial", sans-serif; } .font5 { font:14.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:17.00pt "Arial", sans-serif; } .font8 { font:20.00pt "Arial", sans-serif; } .font9 { font:14.00pt "Arial Black", sans-serif; } .font10 { font:9.00pt "Franklin Gothic Medium", sans-serif; } .font11 { font:19.00pt "Georgia",...

Open the catalog to page 9

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:14.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:17.00pt "Arial", sans-serif; } .font8 { font:20.00pt "Arial", sans-serif; } GOLDFISH Contact Hole Patterns for PCB Mount Baby Goldfish 109 Straight PCB Mount 10 43 [0.413]-4.73 [0.186] 2X2.70 [0.106] 1.2B [0.050]- ■2X2.73...

Open the catalog to page 11

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:14.00pt "Arial", sans-serif; } .font3 { font:15.00pt "Arial", sans-serif; } .font4 { font:17.00pt "Arial", sans-serif; } .font5 { font:9.00pt "Arial Black", sans-serif; } GOLDFISH Connector Ordering Information Specify complte connector by following step 1 through step 5 Include step 6 for customized connectors. GFSH 02 LN XXXXX STEP 1: Basic Sries GFSH : Goldfish S詩ries STEP 6: Spcial Options Consult factory for cusEomization of Goldfish Power...

Open the catalog to page 13
