Design & Development Designs new connectors and modifies existing connectors to meet industry requirementsՕ Continuously conducts marketing studies to identify industry needs for new products Ongoing interest in unique connector designs Tooling Օ Tooling support for all manufacturing areas within company Provides 80% of new tooling, punch press dies, molds, jigs and fixtures used at Positronic factory locations worldwide > Machining Molding Finished Stock Inventory Machining Օ Automatic screw machines produce finely crafted contacts and hardware for connector bodies Trained technicians operate...

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:10.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:18.00pt "Arial", sans-serif; } MANUFACTURING, QUALITY AND RELIABILITY Front Runner Positronic Industries connectpositronic.com Products Positronic Industries manufactures a broad line of industrial and military quality D-subminiature, rectangular, power, circular and utility connectors to international standards. Our connectors are widely utilized in telecommunications...

ront > Positronic Industriesconnectpositronic.com ■ SIZES 11 AND 19 connector diameters. ■ 16 CONTACT ARRANGEMENTS from 3 to 29 contacts. ■ EASY CONTACT SERVICING: Rear insertion/front release ofremovable contacts. ■ TWO LEVEL SEQUENTIAL MATING OF CONTACTS. ■ NON-CORRODIBLE/LIGHTWEIGHT COMPOSITE MATERIALS. ■ ENVIRONMENTALVERSION features dust and water ingress pro-tection to IEC IP67 (1 meter immersion for 30 minutes) in mated condition. ■ EMI/RFI SHIELDED VERSION, electroless nickel plated plastic . ■ THERMOCOUPLE CONTACTS. > ii DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT...

Positronic Industriesconnectpositronic.com GENERAL INFO GENERAL INFORMATION > General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1TypicalConnector Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2Contact Arrangements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 TECHNICAL INFORMATION > TECHNICAL INFO Technical Information ....

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:13.00pt "Arial", sans-serif; } .font3 { font:18.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Palatino Linotype", serif; } Front Runner gnral product information Positronic Industries connectpositronic.com O The Front Runner S驩ries offers a multiplicity of connector features which makes it a first choice to meet the high performance and high reliability require-ments of Medical, Transportation, Industrial Control, and Avionics applications....

Positronic Industriesconnectpositronic.com GENERAL INFO In-line Female Contacts,Plug Housing withCable AdapterPart Number FR11FP316K1with FC116N2 Contacts In-line Male Contacts,Plug Housing withCable AdapterPart Number FR11MP520K1with MC720NContacts Fixed Flange Mount,Male Contacts,Receptacle Housing withJam NutPart Number FR11MJ922K0with MC422N Contacts Fixed Flange Mount,Male Contactswith Receptacle HousingPart NumberFR11MF316K0with MC116NContacts In-line Female Contacts,Receptacle HousingwithCable AdapterPart Number FR11FR520K1with FC720N2 Contacts In-line Female Contacts,Plug Housingwith...

GENERAL INFO 0.063 inch [1.6 mm] Minimum Creepage for Operation at 300V RMS 0.039 inch [1.0 mm] Minimum Creepage for Operation at 200V RMS 0.028 inch [0.7 mm] Minimum Creepage for Operation at 100V RMS > 0.059 inch [1.5 mm] Minimum Creepage for Operation at 250V RMS 0.063 inch [1.6 mm] Minimum Creepage for Operation at 300V RMS 0.028 inch [0.7 mm] Minimum Creepage for Operation at 100V RMS Three(3) Size 12 Contacts0.197 inch [5.0 mm] Minimum Creepage for Operation at 600V RMS Nine (9) Size 20 Contacts0.154 inch [3.9 mm] Minimum Creepage for Operation at 600V RMSNineteen (19) Size 20 Contacts0.059...

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:14.00pt "Arial", sans-serif; } .font4 { font:15.00pt "Arial", sans-serif; } .font5 { font:18.00pt "Arial", sans-serif; } .font6 { font:11.00pt "Palatino Linotype", serif; } hnical informai O U_ _l < O o LU I- TECHNICAL CHARACTERISTICS MATERIALS AND FINISHES: Insulator Inserts: Glass-filled DAP, Type SDG-F, black color, UL 94V-0. Non-Environmental Connectors: Hot Pluggable (50 couplings per U.L. 1977,...

A 1.165 [29.59] 1.165 [29.59] A 1.165 [29.59] 1.165 [29.59] B 0.890 [22.61] 1.435 [36.45] B 0.750 [19.05] 1.260 [32.00] D Thread M15M28 C Thread M19 M32 D Thread M15 M28 踢ܽ NOTE:This connector may be ordered without the coupling nut. > DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT TO CHANGE. >

0.097 [2.46] ☛ NOTE:This connector may be ordered without the coupling nut. > DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT TO CHANGE. >

Positronic Industriesconnectpositronic.com

Positronic Industriesconnectpositronic.com DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT TO CHANGE. size="-2">

Positronic Industriesconnectpositronic.com DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT TO CHANGE. size="-2">

Positronic Industriesconnectpositronic.com Suggest И 0.114 [2.90] platedthrough hole for size 12 contact termination positions.Suggest 0.052 [1.32] platedthrough hole for size 16 contact termination positions.Suggest ؘ 0.045 [1.14] platedthrough hole for size 20 contact termination positions.Suggest 0.040 [1.02] platedthrough hole for size 22 contact termination positions.Suggest ؘ 0.1230.003 [3.12ѱ0.08]hole for mounting connector with push-on fasteners. DIMENSIONS ARE IN INCHES [MILLIMETERS].ALL DIMENSIONS ARE SUBJECT TO CHANGE. size="-2">
