Product catalog summary

About Positronic Industries: Positronic Industries, established in 1966, is renowned for manufacturing high-quality interconnect products. The company emphasizes a service-oriented approach and rapid market response, maintaining its reputation through a 'Complete Capability' concept that encompasses design, tooling, machining, molding, plating, and quality assurance.

Complete Capability:

Design & Development: Focuses on creating and modifying connectors to meet industry standards.
Tooling: Produces 80% of new tooling in-house, offering extensive support.
Machining: Uses automatic screw machines for precision crafting.
Molding: Capable of molding all plastic components with overmold options.
Plating: Provides gold and other finishes conforming to military specifications.
Quality Assurance: Certified to ISO 9001:2000, AS9100 Rev.B 2004, and ISO 14001, with a strong TQM program.

Product Features:

High current in compact packages.
Three-level sequential mating.
AC/DC input, output, and power management.
Efficient current distribution with multiple power contacts.
Superior blind mating capabilities.

Compliance and Standards: Products are RoHS compliant and ITAR registered, meeting various international standards for reliability and safety.

Connector Customization: Offers customization options, including contact loading and PCB terminations, with competitive pricing for new designs.

Sales and Service: Global customer support with facilities in the USA, France, India, Puerto Rico, and Singapore.

Connector Specifications and Types: Includes male and female connectors with various mounting options, each assigned specific codes for configurations and applications.

Ordering and Crimping Information: Detailed ordering information for different series and crimping instructions for removable contacts.

Current Rating and Testing: Explains test methods for current ratings, emphasizing the importance of understanding test conditions.

Temperature Rise Curves: Shows the relationship between temperature rise and current levels, crucial for understanding heat generation and current capacity.

AC/DC Input Keying: Discusses mechanical keying systems to prevent incorrect mating of connectors.

Large Surface Area Contact System: Highlights superior performance with low contact resistance and uniform forces.

Press-Fit Technology: Describes the evolution to compliant press-fit technology to reduce board damage risks.

Bi-Spring Power Press-Fit and Omega Signal Level Compliant Terminations: Reduces insertion and extraction forces, minimizing P.C. board damage risks.

Specifications: Complies with IEC60352-5 standards, with average insertion and extraction forces of 22N per contact.

Procedures and Standards: References Bellcore GR1217 and PICMG® 2.11 for mounting and power use standards.

Connector Variants and Options: Includes PCIH series connectors for CompactPCI® systems with various termination types.

Electrical and Mechanical Characteristics: Details current ratings, contact resistance, and mechanical features like blind mating systems.

Climatic Characteristics: Operates within -55˚C to +125˚C, recognized by UL, CSA, and TUV.

Conclusion: Positronic Industries' connectors offer reliable, customizable solutions for power and signal connections.

PCIA Series Overview: Designed for high current capacity and reliability, suitable for telecom and industrial applications.

Specifications: Includes materials, mechanical, electrical, and climatic characteristics, with RoHS compliance.

Ordering Information: Step-by-step code system for selecting connector configurations.

PCIM Series Overview: Compact and reliable connectors for telecom and industrial applications.

Specifications: Includes various models with different power and signal contact configurations.

Electrical and Mechanical Characteristics: Specific current ratings and mechanical features like blind mating systems.

PCIB and PCIC Series Overview: Detailed specifications and guidelines for compact power connectors.

Specifications: Includes dimensions, contact types, and installation instructions.

Procedures: Crimp contacts must be ordered separately, with suggested printed board hole sizes provided.

Standards and Compliance: Options for RoHS compliance and detailed electrical characteristics.

Recommendations: Contact plating options and sequential contact mating for proper connection sequencing.

Crimping and Installation Procedures: Guidelines for wire stripping, crimping, and using specific tools for optimal results.

Tools and Accessories: Lists various crimping tools and accessories, with cross-reference charts for tool selection.

Press-Fit Connectors: Installation instructions and suggested printed board hole sizes for compliant press-fit connectors.

Recommendations: Use indicated Positronic tools for best results in crimping and installation.
