Positronic Industries
Cablized Connector Brochure

Cablized Connector Brochure

Product catalog summary

Overview: Positronic Industries specializes in high-performance connector systems, offering a range of products designed to meet various application requirements. Their offerings include power, circular, subminiature-D, rectangular, and hermetic connectors, each with unique features and specifications.

Power Connectors: These connectors feature hot plug capability, superior blind mating, and sequential mating options. They support current ratings up to 150 amperes and offer a variety of termination styles and contact variants.

Circular Connectors: Designed with composite materials, these connectors provide water and dust ingress protection up to IP67, EMI/RFI shielding, and come in two package sizes. They support various termination styles and include thermocouple contacts.

Subminiature-D Connectors: Available in six package sizes, these connectors offer standard and high-density options, with power, signal, shielded, and thermocouple contacts. They meet IEC 807-2 and 807-3 performance levels and are available in filtered and environmental versions.

Rectangular Connectors: These connectors come in multiple package sizes with contact sizes 16, 20, and 22. They offer standard and high-density options, with compliance to IEC Publication 807-1 and 807-7.

Hermetic Connectors: Designed for high vacuum applications, these connectors offer a leakage rate of 1 x 10-9 mbar.l/s and are available in signal, power, coax, and high voltage versions.

Custom Solutions: Positronic offers cablized solutions to streamline supply chains and reduce costs. They provide overmolded, environmental, and shielded cable assemblies tailored to specific application needs.

Industry Standards: Positronic collaborates with industry experts to develop standards like SAE J2496 for transit vehicle network cabling, ensuring reliable signal and power networks.

Contact Information: Positronic Industries has offices in the USA, France, and Singapore, providing global support and expertise.

Catalog excerpts

Hot plug capability? Superior blind mating ? Sequential mating options ? Integral locking system ? Current ratings to 150 amperes ? Variety of termination styles ? Multiple package sizes ? Many contact variants ? Recessed female contacts for safety > ? Hot plug capability ? Composite materials ? Water and dust ingress protection to IP67 ? EMI / RFI shielding ? Two package sizes ? Variety of contact variants ? Termination styles include crimp, straight and right angle board mount ? Rear insertion, front release contacts ? Thermocouple contacts > ? Six package sizes ? Standard and high density...

Open the catalog to page 2

Overmolded Shielded Environmental > These cable assemblies provide protection to the connector and its components while giving the assem- bly an aesthetically pleasing appear- ance. This service can be provided when environmental, durability, and cost considerations dictate. These connection systems provide EMI/RFI protection. They combine shielded cable and connectors with metal or composite cable adapters (hoods). Integral filter networks are available for printed wiring board ap- plications. These systems utilize environmen- tal circular and/or Subminiature-D connectors to protect against...

Open the catalog to page 3

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:10.00pt "Tahoma", sans-serif; } .font1 { font:17.00pt "Times New Roman", serif; } Vehicle Area Network Systems Positronic Industries worked closely with transit industry experts to develop SAE J2496, which outlines the Surface Vehicle Recommended Practice for Transport Area Network Cabling. This specification details the requirements for a system which provides a signal and power network for electronics on transit vehicles. Contact us today for more information about our SAE J2496 offerings or for development of network boxes and...

Open the catalog to page 4

Contact Sizes: 0, 8, 12, 16, 20 and 22 Contact Sizes: 8, 20 and 22 Current Ratings: Terminations: Qualifications: Crimp, wire sol-der, straight solder, right angle solder and straight press-fit MIL-DTL-24308,Goddard Space Flight 311P, MIL-C-39029, IP65, IP67 To 40 amperesnominal Current Ratings: To 150 amperes Configurations: Multiple variants in both standard and high densities Terminations: Crimp, wire solder, straight solder, right angle solder, straight press-fit and rightangle press-fit Configurations: Compliance: PICMG 2.11,PICMG 3.0, VITA 41 Multiple variantsin a variety of package sizes...

Open the catalog to page 5
