A creep action thermal protector with a shunted type bimetal design. This lowers the current sensitivity and slows the cycle rate of the device. Shunted bimetal construction; the b imetallic element does not carry the circuit current. Creep action device; slow make/slow break switching action. Frictional differential between opening and closing varies from 2°C to 10°C from the opening temperature. Preset calibration temperature; not adjustable in the field. Case electrically alive; insulating sleeving is available. Equipped with gold diffused, fine silver contacts for use in low voltage/low current applications. CONT ACT RA TINGS Please consult our Sales Engineers for suggested CALIBRATION DIMPLE contact ratings when applied to DC type loads. CALIBRA TION  TEMPERA TURE RANGE FORM FITTING INSULATING SLEEVE (OPTIONAL) SEAMLESS DRAWN CASE (NICKEL PLATED STEEL) WELDED LEAD CONNECTIONS CUSTOMER SPECIFIED LEAD LENGTH AND INSULATING MATERIAL INK STAMP PEPI, MODEL AND DATE CODE METRIC DIMENSIONS ARE IN MM (SHOWN IN GREEN) Copyright 2006, Portage Electric Products, Incorporated, all right reserved 7700 Freedom Ave. NW, P.O. Box 2170, North Canton, Ohio 44720, U.S.A. Phone: (330) 499-2727 • 1-888-GO4-PEPI • FAX (330) 499-1853 • e-mail: [email protected] • www.pepiusa.com Available with nominal calibration temperatures from 45°C to 150°C. CURRENT DERA TING CURVE
