T1000 Primary Injection Test Set PONOVO POWER CO., LTD. www.ponovo.net

T1000 Primary Injection Test Set T1000 Primary Injection Test Set is designed for easy and safe test of different type of relays. The powerful 1000A current source can be used to test all kinds of current relays, including high burden relay and CT. The AC current and AC/DC voltage sources allow amplitude to be adjusted smoothly. The kit uses advanced switching power amplifier to replace the traditional transformer, thus avoiding the dangerous high voltage across the current output. Features  Relay & CT tester function, ratio, secondary impedance, polarity, etc.  Multimeter function  Easy to...

T1000 Primary Injection Test Set ① AC current output: 2A~50A and 50A~1000A, mainly applied for CT test and relay test. ② DC voltage output: 10V~300V. ③ AC/DC voltage input: 0~600V, for measurement voltage. ④ Binary Output: one pair of relay contact. ⑤ Binary input: two pairs with no polarity. It can not only receive protection acting contacts, but be applied for timer test, with single channel and double channels for options. ⑥ AC voltage output: 10V~250V. ⑦ AC current input: 0~6A (0-2000A AC with external CT), it is for measurement and CT ratio. ⑧ Auxiliary DC power supply: 20V~240V. It’s mainly...

T1000 Primary Injection Test Set Auxiliary DC  Mainly provide power supply for protection or relay.  Set the output voltage value，press the Run button to output.  The ON/OFF button on the panel can control the output voltage.  The maximum output current is 0.5A. Any test Any test  Include Manual & Meter, Shot and Linear Ramp interface. Any test - Manual & Meter  Can output high power AC voltage / current, high power DC voltage.  Can display the reading values of voltmeter and ammeter.  Can realize manual control on the amplitude variable by the step. Application examples 1 - CT secondary...

T1000 Primary Injection Test Set Application examples 2 - DC test of operating loop Any test - Shot  Can output high power AC voltage / current, high power DC voltage. Any test - Linear ramp  Can output high power AC voltage / current, high power DC voltage.  When start output, the variable will gradually increase on the step. When receives binary input signal then record action value. Relay test Relay test  Include pick up value test, trip time test, trip time + pulse length test and advanced

T1000 Primary Injection Test Set Relay test – Pick up  Can output high power AC current / voltage, high power DC voltage.  Use the rotary knob adjust the output current / voltage value manually, can test pick up value, drop off value and calculated ratio automatically. Application examples - Trip value test Relay test – Trip time  Can output high power AC current / voltage, high power DC voltage.  When the tester receives the binary input of protection acting signal, the tester will record the action time. Relay test – Trip time + Pulse length  Can output high power AC current / voltage,...

T1000 Primary Injection Test Set Relay test – Advanced  Include reclosing test and motor overload test. Relay test – Advanced – Reclosing  Can set 6 times of faults at most and record 6 times of reclosing time.  Can output high power AC current.  Pick up denotes the time of first-time tripping. Reclosing denotes the time between binary input a and b after each fault. Application example - Reclosing test Relay test – Advanced – Motor overload  Can test trip time of motor.  There are two ways to record the action time. Firstly, as soon as the tester receives a binary input from the relay...

T1000 Primary Injection Test Set CT test CT test - Ratio  Can test CT ratio.  Connect I1 output to the CT primary side and CT secondary side to the current measuring terminal.  The tester will display the current it has measured and the ratio that has been calculated. Application example – CT ratio test Timer Timer  Set single channel and/or double channels.  The action time will be measured automatically before the test has ended. Double channels test Single channel test Report view can be view on local equipment and PC Local view report Word Format

T1000 Primary Injection Test Set T1000 Primary Injection Test Set Specification High power AC current output (I1) Binary inputs Accuracy Output voltage Max Power Load time Input characteristic ±30-±250VDC or potential free Time resolution 1ms (0.001-1 s) ±0.1% (1 -9999.999s) Max. measuring time 9999.999s Binary output High power AC voltage output (U1) Power Load time Type Potential free relay contact Break capacity AC Vmax 250V AC/ lmax 8A / Pmax 2000VA Break capacity DC Vmax 250V DC / lmax 8A / Pmax 150W High power DC voltage output (Udc) Power supply Nominal input voltage Permissible input...
