® PNEUMAX FLUID CONTROL

Pneumax Fluid Control Catalogue Pneumax Fluid Control Catalogue Pneumax offers a wide range of brass and stainless steel valves and solenoid valves, suitable for use with liquid and gaseous fluids. Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice

Pneumax GroupSmart Technologies and Human Competence Founded in 1976, Pneumax S.p.A. is today one of the leading, international manufacturers of components and systems for automation. It is at the fore front of a group comprised of 26 companies, with over 850 employees worldwide. Ongoing investment in research and development has allowed Pneumax to continually expand its range of standard products and customised solutions, adding to the well-established pneumatic technology, a range of electric drive actuators and fluid control components. The desire to provide the service and specific application...

Components and systems for fluid control The Pneumax range of components designed for the control and management of liquid and gaseous fluids have been manufactured using selected materials (valve bodies: brass, stainless steel, seals: FPM, PTFE & EPDM) in order to guarentee maximum reliability in harsh enviroments. • ATEX versions available • Solutions for low temperatures (>-40 °C) or high temperatures (< + 140 °C) • Wide range of components suitable for use with oxygen • ER[certified solenoid coils Pneumatic actuated angle seat valve Servo-assisted piston and diaphragm solenoid valves Direct...

Pneumax Fluid Control Catalogue F3177 Stainless steel body and cover 3/8” ... 1” 37 FX3107 Brass body and cover 1/4” ... 3” FX3177 Stainless steel body and cover 3/8” ... 1” 4 Overall dimensions and technical information are provided solely for

Pneumax Fluid Control Catalogue Servo-assisted diaphragm solenoid valves 2/2 - Series F300 F3277 Stainless steel body and cover 3/8” ... 1” Brass body and cover 1/4” ... 3” Assisted-lift diaphragm solenoid valves 2/2 - Series F300 F3108 Brass body and cover 3/8” ... 1” Brass body and cover 3/8” ... 1” 1/2 Stainless steel body - 3/8” ... 1” Stainless steel body and cover 3/8” ... 1” 1/2 Servo-assisted piston solenoid valves 2/2 - Series F300 F3119 47 Brass body and cover 1/4” ... 1/2” Brass body and cover 3/8” ... 1/2” 48 Brass body and cover - 3/8” Solenoid coils - Series F300 52 Pneumatic actuated...

Pneumax Fluid Control Catalogue PNEUMAX FLUID CONTROL F300 series includes a vast range of solenoid valves in brass and stainless steel designed to control air, water, steam and all fluids that are compatible with the materials used for bodies and seals. The solenoid valves are 2 or 3-way, normally closed, normally open, general service, direct acting or servo-assisted, with connections available in NPT & BSP threads from G1/8” up to G3”, with a working pressure range from vacuum to 100 bar. Solenoid valves are available with coils that conform to CESI 03 ATEX 344 certification for explosive...

Pneumax Fluid Control Catalogue Servo-assisted solenoid valves Large-sized passage orifices increase the value of the static pressure which has to be overcome by the magnetic field produced by the coil. These solenoid valves are used to control high-pressure values with large diameter bores. In these models, the fluid helps in the opening or closing of the main poppet. They can be normally closed (2/2 N.C.) and have an input and a utilisation connection machined into the valve body and at rest the fluid is intercepted by the main poppet, which can be either diaphragm or a piston. In this condition,...

Pneumax Fluid Control Catalogue Series F300 Resistance to fluidsThe table below serves to general information relating to the compatibility between FPM (fluorocarbon) and a number of neutral fluids. Where there are corrosive fluids, in order to establish compatibility, it is important to be aware of all the data relating to use: temperature, concentration and composition of the fluid. Fluid 8 Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice

Direct acting poppet type solenoid valves 2/2 Pneumax Fluid Control Catalogue F3105 - 2-way solenoid valve N.C. brass body, with G connection (ISO 228) - 1/8” X N.B. For use with steam maximum admitted pressure PS is 2,5 bar (relative pressure). Example: F3105®V25© => F3105AV25MI58: 2-way solenoid valve normally closed, direct acting poppet type with G connection (ISO 228) 1/8”, FPM seals, orifice 2,5 mm, solenoid coil 230 VAC (50-60 Hz) (MI58, size 22 for more information, please refer to the section “Solenoid coils - Series F300”). Pneumatic symbol Diagram Construction characteristics Overall...

Direct acting poppet type solenoid valves 2/2 Series F300 F3106 - 2-way solenoid valve N.C. brass body, with G connection (ISO 228) - 1/8” and 1/4” N.B. For use with steam, maximum admitted pressure PS is 9 bar (relative pressure) with seals in PTFE and 2.5 bar with seals in EPDM. 2-way solenoid valve normally closed, direct acting poppet type with G connection (ISO 228) 1/4”, FPM seals, 5,2 mm orifice, solenoid coil 230 VAC (50-60 Hz) (MG58, size 30 for more information, please refer to the section “Solenoid coils - Series F300”). Pneumatic symbol Construction characteristics 10 Overall dimensions...

Direct acting poppet type solenoid valves 2/2 Pneumax Fluid Control Catalogue F3106 - 2-way solenoid valve N.C. brass body, with G connection (ISO 228) - 3/8” and 1/2” X G connection (ISO 228) ®= Connection Orifice KV (mm) (m3/h) Differential pressure (bar) Power consumption ©= Solenoid coil Max Temperature range N.B. For use with steam, maximum admitted pressure PS is 9 bar (relative pressure) with seals in PTFE and 2.5 bar with seals in EPDM. Example: F3106®V52© => F3106DV52MK5: 2-way solenoid valve normally closed, direct acting poppet type with G connection (ISO 228) 1/2”, FPM seals, 5,2...
