Introduction to Plus Opto
Plus Opto, founded in 1994, specializes in optoelectronic solutions with a focus on LED technology for applications such as public information systems, automotive, and architectural lighting. The company emphasizes high-performance LED light sources supported by IC Drivers from Macroblock to enhance circuit performance. They also offer LCD products and custom display solutions.

LED Technology Benefits
LEDs provide advantages such as safe low voltage operation, long lifespan (50,000 to 100,000 hours), maintenance-free operation, energy efficiency, cool running, durability, true color range, temperature resistance, and flexible drive capabilities.

High Power LED Assemblies and Modules
Includes series like SFNMP, SFNMC, and SFNMB, emphasizing thermal management for reliable operation and efficient lumen maintenance.

High Power Modules
Various series such as SYKM23, SFNMP-4W-O, PA82-6W-O, PA94-12-O, and PA82-9W-O, each offering different lumen outputs and requiring constant current drivers and heat sinking.

White LEDs
Includes 5.0mm and 3.0mm through-hole options, SBZ-ZB Series, NS6W Series, NCCW Series, SH24 Super Vega 120, and XRE Lamp®.

Surface Mount Products
Includes SC21 and SC41 Series, Chip LEDs, and SSSM Super Small Side View.

Full Colour RGB
Includes SFNERTB, 5.0mm Discrete RGB, and LGXRGB-501E.

LED Indicators
Includes Single Way PCB Indicators and various panel mount indicators.

Light Bars and General Purpose LEDs
Light bars for legend illumination and general-purpose LEDs with various lens options.

Bargraph Arrays
Solutions for solid-state metering with flexible formats and high contrast ratios.

Infrared Products
Includes interrupter switches, emitters, detectors, reflective assemblies, and optocouplers.

Support Hardware and Optics
Includes light pipes, spacers, bezels, and optics for LED emitters.

Numeric and Custom LED Displays
Includes numeric displays and custom dot matrix formats.

Liquid Crystal Display Modules
Custom LCD glass options with numeric displays and LED backlights.

Character Modules
Compatible with HD44780 controllers, available in various font options.

RGB Backlight Modules
Use RGB LEDs to generate seven colors, requiring independent driving of RGB channels.

Graphic Modules
Support custom graphics and symbols, some with touchscreens.

PLED & OLED
Offer faster response, lower power consumption, and higher brightness.

Custom LCD Modules
Custom solutions using COB, COG, and TAB assembly.

TFT Solutions
Range of TFT displays with complementary components.

Colour STN (C-STN)
High brightness and improved color saturation displays.

Vacuum Fluorescent Displays (VFD)
High brightness and excellent viewing angles.

Inverters
For driving CCFL and EL backlights with dimming options.

Cables & Connectors
Customizable solutions for specific applications.

Linear LED Strips
Various series with customizable configurations and colors.

LED Clusters
High intensity clusters for lighting and signal applications.

Signage & Highlighting
Products like MicoLite and FlexiLite for channel letter illumination.

Recessed Marker Lights
LDR series with high power LED emitters for indoor or outdoor use.

Product Specifications

• High Power LED Emitters: Models like LDR35, LDR50, and MR16 series for indoor and outdoor use.
• LED Drivers: Models like MBI1801, MBI5030, MBI6010, MBI5171, and MBI6650 for specific applications.
• System 1 LDS7 Splitter Box: For series connection of multiple 1W LED fittings.
• Switched Mode Power Supplies: Range from 6W to 220W for LED arrays and fittings.

Lamp Replacement Options

• MR16 Series: Compatible with existing MR16 GU5.3 fittings.
• P19 Light Bulb: For decorative and low ambient lighting.

Controllers

• Colour Bus 200 and 400: Pre-programmed color options and cycle speed control.
• DigiLED: Manual static color setting and cycle time flexibility.
• Basic DLD: 3-channel RGB controller with pre-programmed color cycles.

Contact Information
Plus Opto Ltd, Derwent Court, William Way, Moss Industrial Estate, Leigh, Lancs WN7 3PT. Phone: +44 (0) 1942 671122, Fax: +44 (0) 1942 671133, Website: www.plusopto.co.uk, Email: [email protected]
