This document provides comprehensive information on accessories for vacuum systems, emphasizing monitoring and control units. It highlights key aspects such as reliability, energy consumption, and precise control/monitoring.
The document includes a list of accessories like vacuum switches, valves, Vactrap™, vacuum filters, silencers, vacuum gauges, connection kits, and regulators.
Effective supervision and control of compressed air and vacuum flow are essential for optimal performance and efficiency in vacuum systems.
These switches convert vacuum signals to electric or pneumatic signals, used in applications like safety signals and energy-saving systems. They feature varying hysteresis levels affecting ON and OFF levels.
Specifications for vacuum switches include pressure limits, material composition, temperature range, weight, connection type, hysteresis, supply voltage, safety classification, and current output.
Details for ordering various vacuum switches, including part numbers and descriptions for different types and configurations, are provided.
This section describes the solenoid valve DS 23, a 3/2 valve suitable for compressed air, with specific technical data such as feed pressure, material, working temperature, and electrical connection.
The Vacustat is a vacuum-controlled 2/2 NO valve with adjustable vacuum levels, available in two variations with different hysteresis levels to minimize compressed air consumption.
- Vacuum Pump Requirements: Must include a non-return valve. Recommended use of Vacustat for sealed systems. Compatible with PIAB vacuum pump sizes 5–120.
- Technical Data: Feed pressure ranges from 0.4–0.7 MPa, temperature range from 0–60°C, and a weight of 90g. Connections include 2 x M5 for vacuum and 2 x 1/8" NPSF for compressed air. Signal range is -15 to -99 kPa.
- Vacuum-Controlled Valve Function: Shuts off compressed air flow to the pump when a pre-set vacuum level is reached. The vacuum level is adjustable via a knob, and the system restarts when the vacuum level drops due to minor leakage.
- Vacustat: Available with small or large hysteresis. Connection kits are available for different pump sizes.
- Electrically Controlled Valves: DIP 55 series with on/off functionality, suitable for PIAB vacuum pumps. Includes electrical connections and manual override.
- Vactrap™: Check valve that maintains vacuum pressure in sealed systems, equipped with a blow-off valve for quick release.
- Vacuum Filters: Designed to filter dust and particles, reducing the risk of pump operation breakdown. Available with replaceable filter elements and increased filter area options.
- Silencers: Reduce noise from exhaust with a flow-through design to prevent performance impairment.
- Vacuum Gauge and Manometers: Analogue indicators with installation nuts for panel mounting.
- Connection Kits: Include push-in connectors and corrosion-resistant materials, compatible with various pump models.
- Pilot Regulator: Pressure regulator with secondary pressure relief and flow compensation, suitable for remote control.
- Compressed Air Filter Regulator: Separates particles and condensate from compressed air, includes a manometer.
- Ensure compatibility of components with specific vacuum pump models.
- Regularly replace filter elements to maintain optimal performance.
- Utilize silencers to reduce operational noise levels.
Catalog excerpts
VACUUM SWITCHES A vacuum switch can be used for many different applications. Converts a vacuum signal to an electric or pneumatic signal Actuates at a pre-set vacuum level Sequence signal in vacuum systems Safety signal for low vacuum level Signal at correct vacuum level Energy-saving systems HYSTERESIS Vacuum switches have different hysteresis. The hysteresis is the difference between the ON and the OFF levels.The need or demand for small or large hysteresis is different depending on application.When you want a fixed vacuum level, a small hysteresis is good, but if you want to use the switch...
Open the catalog to page 3
PNP/NPN OUTPUT, WHAT DOES IT MEAN? A PNP transistor is generally connected to thepositive rail and is sourcing the load.The NPN is sinking the load and is generallyconnected to the ground.If a load is higher than the output can handle, anextra transistor or relay can be used.See example below. PNP/NPN OHMS LAW > PNP NPN Equivalent circuit Equivalent circuit UNITS OhmҒs Law can be described to be the basic lawwithin electronics.It defines the relation between voltage, current andresistance.The current is directly proportional to the voltagedrop over a resistance.Example: One volt over a one ohm...
Open the catalog to page 4
Description Unit Value Pressure, maxMPa0.6 Material PBTP, PVC, PA SS NBR, POM Al, CuZnTemperature range C-25Ж80 Weight g 5065Connection VacuumM5 Hysteresis kPa 2Cable2 x 0.14 mm > 2 x 2m Supply voltage VDC 24 (5֖36)Safety classificationIP67 Current Output, max mA 200Voltage drop, maxVDC4.6 Description Unit Value 3116064 3116089 3116090 3116091 Signal range-kPa109510ֱ130370ѱ5 > Specifications subject to change without notice. >
Open the catalog to page 5
Description Art. No. AVacuum switch, inductive universal, adjustable with knob3116064 B Vacuum switch, inductive universal, pre-set (Signal range 10 -kPa) 3116089BVacuum switch, inductive universal, pre-set (Signal range 30 -kPa)3116090 B Vacuum switch, inductive universal, pre-set (Signal range 70 -kPa) 3116091CVacuum switch, adjustable with knob0104350 AB C Description Art. No. Connection set for vacuum switch0100488 Contents: Barrel nipple G1/8 M5 long, hose connector 4/2 M5. Material: Nickel-plated brass, SS, PA66, NBR, PA6. Fits: All pre-set and adjustable vacuum switches. > Accessories...
Open the catalog to page 6
Description Unit Value Pressure, maxMPa0.6 Material PBTP, PVC, PA, SS, NBR, POM,Al, CuZnTemperature range C-20Ж80 Weight g 5062Connection vacuumM5 Function output NO/NCHysteresiskPa10 Cable 3 x 0.75 mm > 2 x 0.5 mVoltage supply, max.VAC/VDC250/30 Safety classification IP67Current output, maxmA5000 Description Unit Value 3116068 3116061 3116095 3116096 Signal range-kPa15֖95159525ֱ56510 > Specifications subject to change without notice. >
Open the catalog to page 7
Description Art. No. AVacuum switch, electro-mechanical, adjustable with knob3116068 B Vacuum switch, electro-mechanical, adjustable with screw 3116061CVacuum switch, electro-mechanical, pre-set (Signal range 25 -kPa)3116095 C Vacuum switch, electro-mechanical, pre-set (Signal range 65 -kPa) 3116096 AB C Description Art. No. Connection set for vacuum switch0100488 Contents: Barrel nipple G1/8 M5 long, hose connector 4/2 M5. Material: Nickel-plated brass, SS, PA66, NBR, PA6. Fits: All pre-set and adjustable vacuum switches. > Accessories Specifications subject to change without notice. >
Open the catalog to page 8
Description Art. No. AVacuum switch, pneumatic, adjustable with screw (NO)3116062 A Vacuum switch, pneumatic, adjustable with screw (NC) 3116063BVacuum switch, pneumatic, adjustable with knob (NO)3116069 B Vacuum switch, pneumatic, adjustable with knob (NC) 3116070CVacuum switch, pneumatic, preset (NO 10 -kPa)3116083 C Vacuum switch, pneumatic, preset (NO 25 -kPa) 3116084CVacuum switch, pneumatic, preset (NO65 -kPa)3116085 C Vacuum switch, pneumatic, preset (NC 30 -kPa) 3116087CVacuum switch, pneumatic, preset (NC 70 -kPa)3116088 AB C Description Art. No. Connection set for vacuum switch0100488...
Open the catalog to page 10
Description Unit Value Pressure, maxMPa0.2 Material PA, TPU, SS, CuZn(Au)Temperature rangeC-25 ږ +85 Weight g 5Signal range-kPa30, 50 or 70+5/-3 Function PNP NO/NC, NPN NO/NCHysteresiskPa6 1 Voltage VDC 24 (12-30)Safety classificationIP40 Current max mA 100 inductive/400 resistiveVoltage drop, max (100mA/24V inductive load)VDC0.055 Response time ms 4DisplayRed LED Electric connection M8 3-pin male Description Art. No. AVacuum switch VS4015, ј6, 30 -kPa0110245 A Vacuum switch VS4015, 6, 50 -kPa 0110246AVacuum switch VS4015, ؘ6, 70 -kPa0110247 B Vacuum switch VS4016, G1/8" male, 30 -kPa 0110248BVacuum...
Open the catalog to page 11
Description Unit Value Pressure, maxMPa0.2 Vacuum range -kPa 0100MaterialPC, POM, NBR, SS Temperature range ֺC -2070Weightg50 Connection vacuum D=6/M5FunctionNO, NPN/PNP Hysteresis % 1֖15Supply voltageVDC10.830 Voltage output VDC 1֖5Safety classificationIP40 Analogue output, current max. (load resistance min. 5k Ω ) mA 1Humidity% RH3585 Response time ms 2Accuracyat 25 ְ C3% F.S. Current consumption, max mA 17High-voltage resistantVAC500 Insulationat 500 VDC MOhm 100Vibration resistance, 1,5 mm, XYZ, 2 hHz10і500 Electric connection M8 4 pinmaleCurrent output, maxmA80 > Description Art. No. Vacuum...
Open the catalog to page 12
Description Unit Value Pressure, maxMPa0.2 Vacuum range -kPa 0100MaterialPC, POM, NBR, Al Temperature range ֺC -1060Weightg52 Connection vacuum D=6/M5FunctionNO, NPN/PNP Hysteresis kPa 2Voltage supplyVDC12֖24 Voltage output VDC 15Dielectric strength, 1 minVAC500 Safety classification IP40Analogue output, currentmax. (load resistance min. 5k ֢Ħ )mA1 Humidity %RH 3585Response timems2 Accuracy at 25 ְ C 3% F.SCurrent consumption, maximummA35 Insulation resistance, at 500 VDC MO/MW 100Display2-digits LED Current output, max mA 80 > Description Art. No. Vacuum switch, adjustable, PNP NO DM80107732...
Open the catalog to page 13
Description Unit Value Pressure, max.MPa0.2 Vacuum range -kPa 0100MaterialPC, Al Temperature range ְ C -1060Weightg6 Connection vacuum D=6/M5Hysteresisֱ2% F.S. Voltage supply VDC 10.830Safety classificationIP40 Humidity %RH 35֖85Response time, approx.ms1 Accuracy, at 25 C б3% F.S.Current consumption, maxmA20 High-voltage resistance VDC 500Insulation at500 VDCMOhm100 Vibration resistance, 1.5 mm, XYZ, 2 h Hz 1055Current output, maxmA80 > Description Art. No. Vacuum switch, adjustable, PNP NO LM80107731 > Accessories Specifications subject to change without notice. >
