MDF-U33V

Product catalog summary

Overview: The Panasonic MDF-U33V is an ultra-low temperature freezer designed for efficient storage with improved energy consumption. It features V.I.P. (Vacuum Insulation Panel) technology to maximize storage capacity while maintaining a compact footprint.

Specifications: The freezer has an effective capacity of 333 liters (11.8 cu.ft.) and can maintain temperatures from -50˚C to -86˚C. It is equipped with a rotary and hermetic compressor system, using HFC refrigerant. The exterior dimensions are 670 x 867 x 1860 mm, and it weighs approximately 255 kg.

Features: Key features include removable inner doors for easy cleaning, enhanced security with a padlock-compatible latch, and a digital control panel. The freezer operates quietly and offers improved accessibility with a beak-style inner door latch and easily accessible condenser filter.

Safety and Reliability: The MDF-U33V includes multiple safety features such as alarm lamps and buzzers for power failure or temperature deviations, a microprocessor-controlled filter-clog check, and a Status Alert system for continuous condition monitoring.

Certifications: The Panasonic Healthcare Co., Ltd., Biomedical Business Unit is certified for ISO9001, ISO13485, and ISO14001 standards, ensuring quality and environmental management.

Options and Accessories: Available options include a circular recorder, LCO2 and LN2 backup systems, a data acquisition system, and an interface board. The freezer also comes with a set of keys and a scraper.

Energy Efficiency: The freezer achieves 12% higher energy conservation compared to previous models, thanks to its advanced refrigeration system and aerodynamically designed components.

Catalog excerpts

Ultra-Low Temperature Freezer MDF-U33V Temperature (Ambient temperature 30°C) Patented V.I. V.I.P. .I.P. (Vacuum Insulation Panel) Ultra slim, space saving Ultra-Low Freezer with Improved energy consumption • V.I.P. technology maximises storage capacity • Safe operation with Status Alert continuous condition monitoring • The inner doors are removable for cleaning and defrosting • Enhanced security • Improved accessibility • Quiet operation • Improved energy consumption • Can hold up to 216 pcs of 2-inch boxes or 144 pcs of 3-inch boxes

Open the catalog to page 1

MDF-U33V Features EVOLUTIONARY DESIGN • Panasonic V.I.P Evolution Series -86˚C . ultra-low temperature freezers use patented revolutionary vacuum insulation cabinet construction that reduces the wall thickness from 14cm to 7cm (5.5” to 2.7”) and achieves up to 30% more storage capacity than a conventionally insulated freezer without increas- ing the footprint. • The newly developed refrigeration system and the freezer structure offer a quiet experimental environment. SAFETY • Alarm lamp and buzzer offer secure warning of power failure or abnormal temperature increase. • Microprocessor-controlled...

Open the catalog to page 2
