Pipeline Hand Tools Catalog 2005
20Pages

{{requestButtons}}

Catalog excerpts

Pipeline Hand Tools Catalog 2005 - 1

n n Stringer Bead Brushes Stringer Bead Brushes n n Pipeliner Wheels Pipeliner Wheels n n Pipeliner Files Pipeliner Files >

Open the catalog to page 1
Pipeline Hand Tools Catalog 2005 - 2

tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 2
Pipeline Hand Tools Catalog 2005 - 3

PFERD Milwaukee Brush Co. is proud to offer a complete line of surface finishing and weld cleaning solutions specifically for the pipeline industry. The quality and scope of our product line is unsurpassed in the industry. Contact PFERD today for a single-source solution to your pipeline requirements! ADVANCE Power and Maintenance Brushes > WELDCAT > TM Stringer Bead Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5Full Cable Twist Knot Wheels . . . . . . . . . . . . . . . . . . . . . . ....

Open the catalog to page 3
Pipeline Hand Tools Catalog 2005 - 4

Superior Surface Conditioning More User (And Equipment) Friendly Brushes do not produce chemical vapors or abrasive dust, which create workplace hazards and reduce equipment life. Brushing offers ideal face preparation for oxide removal and cosmetic finishing without the problems associated with chemicals, coated and bonded abrasives. Non-loading Operation Brushes won't "load up" and lose effectiveness when used to condition, clean or finish soft materials, as occurs with coated, bonded and non-woven abrasives. Cost-effective, Durable, Long Life Construction ADVANCE brushes are built with...

Open the catalog to page 4
Pipeline Hand Tools Catalog 2005 - 6

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial", sans-serif; } Wire Wheel Brushes Encapsulated Stringer Bead, Full Cable Twist Encapsulated Stringer Bead Ideal for large diameter pipe construction. Extra heavy duty E5 grade resists deflection, fracture and crumbling, providing a shorter, more aggressive trim length. Brush Dia. (Inches) Thread Size Wire Size ECAP® Grade Trim Length...

Open the catalog to page 6
Pipeline Hand Tools Catalog 2005 - 10

PFERD grinding wheels, cut-off wheels, andPOLIFAN The product line colors - orange, silver and blue - provide initial orientation to users and facilitate the selection of the ideal abra- sive. > Orange = Universal Line PSF flap discs are marked with aneasy-to-follow color code on all product labels and packaging and in our recommen- dations for use. For general purpose use in industrial, trade and DIY use. Silver = High Performance Line SG Broadest range for professional use in industry and trades. Blue = Special / Premium Performance Line SGP Designed for special industrial applications....

Open the catalog to page 10
Pipeline Hand Tools Catalog 2005 - 11

PFERD Pipeliner wheels are designed for lightgrinding and cutting of pipeliner root pass, weld and flame cut grinding, and all facets of steel and non-ferrous metal production andfabrication. > General purpose pipeliner wheel providessmooth grinding action, fast removal rates and good service life with minimal contact pressure. In addition to providing an aggres- sive, low cost solution for conventional use, INOX-Rated Pipeliner PSF is an excellent tool for pipe fitters servicing the Nuclear and food industry. Aluminum Oxide grain Fast stock removal, good service life INOX Rated: Free of...

Open the catalog to page 11
Pipeline Hand Tools Catalog 2005 - 12

General purpose type for multipurpose, demanding grinding applications.POLIFAN Zirconia Alumina grain Fast stock removal, long service life > Free of iron, sulphur and chlorinated fillers; suitable for use on stainless steel > ή PSF-Zirkon features aggressivematerial removal performance and long service life, particularly for edge grinding applications. > Diameter Max.Grit(Inches)PFERDNo.RPMSizeUnthreadedThreaded HubA.H.EDPThreadEDP Conical (PFC - Type 29) 4-1/2PFC 115 Z PSF13,3004060 7/8 62052 105/8-11 62071 10 > High performance POLIFAN > for demandinggrinding applications on surfaces and...

Open the catalog to page 12
Pipeline Hand Tools Catalog 2005 - 13

Half Round Pipeliner Files are designed forfiling pipeline root pass and welds. 10 Spot WelderԒs Tip File features a concavesurface that is cut to dress spot welder tips. Back is safe (uncut). > 4 Mig WelderԒs File removes slag and dresses the nozzle. Flat surface is uncut to protect the top of the nozzle. FileApproximate Size CutEDPType(l x w x thickness)Number Pipeline Half Round14 x 1-3/8 x 11/32Bastard5 11155 Pipeline Half Round w/Handle14 x 1-3/8 x 11/32Bastard5 11155H Spot Welders Tip File10 x 1-1/8 x 1/8Bastard5 11160 Mig WelderҒs File4 x 3/8 x 1/8Second10 11165 PFERD file handles...

Open the catalog to page 13
Pipeline Hand Tools Catalog 2005 - 14

General purpose grinding wheel for use onall metals - steel, stainless and non-ferrous. Smooth grinding action and fast removal rates with minimal contact pressure. Aluminum Oxide grain Fast stock removal, good service life > Blended zirconia and Aluminum Oxide grinding wheel for fast and free cutting performance that outlasts Aluminum Oxide wheels 2 to 1. Aggressive removal rates on all metals from alloys and stainless to gray iron and steel. Economical performance-to- price ratio lowers overall cost. Zirconia, Aluminum Oxide blend Free cutting, fast removal and twice the life of Aluminum...

Open the catalog to page 14
Pipeline Hand Tools Catalog 2005 - 15

PFERDCones and Plugs for horizontal andstraight grinders are ideal for cleaning welds and castings. They can be used for internal grinding, blending contours, working in con-Type 16 - Curved sides and rounded tip forgrinding contours or flat surfaces. Type 17 - Tapered, straight sides and squaretip for beveling workpiece edges. Type 18 - Straight sides and blunt nose forflat surfaces and inside edges. Type 18R - Straight sides for flat surfaces andround nose for contouring. fined areas, and grinding and smoothingweld fillets and corners. High performance for grinding and snagging welds and...

Open the catalog to page 15
Pipeline Hand Tools Catalog 2005 - 16

PFERD manufactures a wide selection of highperformance thin, depressed center (Type 27) cut-off wheels. PFERD wheels cut faster than conventional wheels, leaving a cleaner cut, with minimal burr.Thin wheels achieve fast cutting perform-ance by removing less material in the cutting process. As less material is removed, less working pressure is required to make the cut. Engineering and manufacturing experi- ence by PFERD results in superior quality, consistency, and the highest performance level available. Thin cut-off wheels are ideally suited for thin gauge sheet stock, thin walled tubing...

Open the catalog to page 16
