F120A Fire Alarm Control PanelPower and flexibility combined with user-friendly operation Economical, intuitive installation and configuration Designed for medium to large projects, and projects that need complex or specialised functionality F120A Analogue Addressable Fire Alarm Control Panel Product Overview: The Pertronic F120A is a modular, expandable, intelligent fire alarm control panel, capable of monitoring more than five thousand addressable devices including up to 3,180 sensors and 1,980 input or output modules. Intuitive, versatile programmable features, and a large selection of options, ensure that the F120A is readily tailored to individual project requirements. Fire system events such as alarm signals from heat or smoke sensors and manual call points are uniquely identified on the user-friendly display. Configurable text descriptions allow users to determine the precise location of any active device. The Pertronic range of peripheral devices for the F120A include a full range of alerting products such as sounders, strobe lights, beacons, audio-visual signs, amplifiers, speakers, audible warning and evacuation systems, and internet and SMS (text-messaging) interfaces. The F120A facilitates building response features such as air handling, lift (elevator) control, sprinkler monitoring, door control and extinguishing agent release. A range of LCD and LED mimic panels provide optional remote display, control and monitoring capabilities. The F120A is fully compatible with Pertronic FireMap PC Graphics and the Pertronic Network. » Standard F120A control panel with LCD display, fire-fighter, and engineer controls » Lockable front door » Two analogue addressable loop circuits. (Expandable up to twenty loops. Refer to pages 2 & 3 for details.) » Two monitored sounder (External Bell, Warning) circuits » Monitored Ancillary Control Function (ACF) output » Fire, Fault, and Battery Fail relay outputs » Door Holder relay output » Programmable (General Purpose) relay output » Isolate controls for: Warning System, External Bell, ACF, Door Holder » Daily automatic system integrity test » Serial port for PC programming and interrogation via the user-friendly Pertronic utility application » Serial communications bus (RS 485) for networking with other fire alarm control panels and for interfacing to LCD and LED mimic panels and ancillary peripheral units » Standard cabinets, with window and manual call point on front door: 16U, 28U Slim, 28U Deep, 40U Deep, Double 40U (Note: Call point optional on 40U cabinets) » Weatherproof cabinets (window optional): 16U, 28U » Document holder fitted as standard equipment on 16U cabinet. (Optional on other cabinets, except 16U weatherproof.) » Other cabinet sizes and styles available for special orders » Assembled according to customer order » Pertronic factory engineering drawings are supplied with every F120A fire alarm control panel » Fully compliant with Australian Standard 4428.1 » Air handling controls (if fitted) comply with AS 1668

» Two-Loop Driver (F120P2LMB-A)t: Provides two analogue addressable loops. » Addressable Loop Responder (AALRES-A)t: Provides eight conventional detection zone circuits or switch input circuits and one form C relay contact. » Addressable Loop Relay (AALREL)t: Provides four programmable outputs: active loop or external powered and monitored or volt free relay contacts. Also one fault monitoring input. » AA Isolator Board (8SAAIB)t: Provides eight isolated analogue addressable loop spurs. Allows conventional fire alarm zones to be converted to analogue addressable spurs using the existing cable,...

These product codes specify white front plates. To specify grey front plates, add a suffix “-G” to the product code. For example: F120A-A16U/4A-G. Standard F120A fire alarm panels have one Two-Loop Driver, which provides two analogue addressable loops. Each additional Two-Loop Driver takes the place of one standard size internal option. Maximum number of standard options: The number of additional standard size internal options that typically fit inside the cabinet, provided that the power supply is capable of supplying the system's maximum current consumption. Popular options are described on...

Mimic Panels Multiple Pertronic Internet & Telecom Systems Fire Brigade Transmitter Intelligent Panels Addressable Detectors Inputs & Outputs Evacuation Speakers Bells & Warning Devices Fans & Air-Handling Devices Project-Specific & Ancillary Outputs Building Management Systems Conceptual diagram of a fire alarm system based on an F120A, showing the available input & output circuits and communication & networking options. Software Features: Specifications: » User definable text descriptor per point and zone » User isolation of zones and individual sensors » Sensor Pre-Alarm and Maintenance warnings »...
