General Specifications
The Stereo-Heat system requires electrical isolation from grounds and non-heated piping using INSULFLANGES. Piping supports and hangers must accommodate the insulation and jacket. A temperature control system is necessary to protect the power transformer and heating circuit, utilizing resistance temperature detectors or thermocouples. These sensors must be environmentally protected and have weatherproof fittings. Status indication lights are required for power, heating, and temperature status.

Electrical Design
The system must provide 25% more power than the maximum heat loss for maintenance temperatures up to 100°F, and 40% more for temperatures above 100°F. Additional power may be required for specific heat-up times.

Transformers
The system should be energy-efficient and cost-effective, with complete thermal and mechanical designs provided by the supplier. Only vendors offering comprehensive system designs and services will be considered. The power transformer must be an isolating type, not an autotransformer, and designed for continuous operation at maximum KVA rating.

Controls
The piping is heated by applying low voltage to form a circuit. The pipe temperature is monitored and controlled via a closed-loop system.

Manufacturer Information
PERMA-PIPE, Inc., a subsidiary of MFRI, Inc., is the authorized representative. The company has over five years of experience in impedance tracing systems. Contact information is provided for further inquiries.
