Peer Tappered Catalog
210Pages

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

SERIESISO CLASS BEARINGS

Basic Features and Design Four basic components are combined in the design of a tapered rollerthe load, while the cage is only intended to retain and space the rollers.bearing. Shown in figure 1 is the cup (outer ring), inner ring, tapered rollersand a cage (rolling element retainer). The inner ring, rollers and cage are referred to as the cone assembly. The rings and rollers are designed to carry Figure 1. The parts of a Peer tapered roller bearing. > Cone Assembly CageInner RingRollersCup Bearing Arrangement Tapered roller bearings are usually mounted in pairs in either a direct...

carry. The arrangement and spacing must be considered when resolving theforces for each pair of bearing sets. > aa Spread Direct Mounting > aa Spread Indirect Mounting Alignment A perfectly aligned bearing is ideal for maximum life and performance.The angle of misalignment for a tapered roller bearing is the difference between the axis of rotation of the cone assembly and the cup axis. Roller Guidance Tolerance Class When loads are acting through the individual components of a tapered rollerbearing, most of them are transferred through the contact between the rolling surfaces of the cup...

metric JӔ prefix, the classes are K and N. For bearings of the ISO metricdesign, the classes are Normal and 6X. DesignPrecision Class Inch42ISO metricNormal6XJӔ PrefixKNA higher precision class may be required for applications requiring a greaterdegree of running accuracy. High Speed Effects The speed limitations of tapered roller bearings are dependent upon thepermissible operating temperatures of the application and the capability of the lubrication system to effectively remove enough heat throughout its life. Other effects such as moments and centrifugal forces can reduce fatigue life at...

Static Equivalent Radial Load The static equivalent radial load represents a static radial load, whichproduces a contact stress at the center of rolling element contact equal to that which would occur in combined axial and radial loading. Plastic Deformation Plastic deformation may occur at the rolling element contact area in caseswhere the dynamic or static equivalent radial loads exceed the static radial load rating of the bearing. The extent to which permanent deformation affects the function of the bearing is dependant upon the application and the requirements for quiet operation and...

, required minimum operatingoil viscosity in cSt (centistokes). 1 V

Canada Calgary, Alberta Montreal, Quebec California: CeritosFlorida: Clearmont, Tampa Georgia: Atlanta Illinois: Moline, Waukegan, Cary Indiana: Fishers Kansas: Olathe Kentucky: Louisville, Taylor Mills Louisiana: Natchitoches, Alabaster Michigan: Plymouth Missouri: Columbia New Hampshire: Manchester New York: Burnt Hills, Schoharie North Carolina: Charlotte Ohio: Pickerington, Chagrin Falls Oregon: Gresham Texas: Spring, Deer Park, Brownsville, Harlingen Virginia: Glen Allen, Vinton Wisconsin: St.Croix Falls Argentina Mexico PEER Bearing S.A. Coronel Larrabure 2260 ( Ruta 9 - Km 562 ) (...
