TEST INSTRUMENTS FOR THE METAL-PROCESSING INDUSTRY PCE Instruments Discover our new test instruments and their functions.

TEST INSTRUMENTS FROM GERMANY for the metal-processing industry The company PCE Instruments based in Meschede-Freienohl in the German Sauerland region was founded in 1999 by three engineers. With more than 120 employees and several branches around the world, the company focuses on the development, production and distribution of high-performance and innovative products from the fields of measuring instruments, control systems, weighing equipment and laboratory technology. PCE Instruments‘ wide range of products and services offers high precision and flexibility in any application as well as...

HARDNESS TESTER PCE-2000N TECHNICAL SPECIFICATIONS Meter for metallic materials The PCE-2000N hardness tester from PCE-Instruments uses the Leeb rebound method. This is a dynamic hardness test method in which a standardized test specimen, usually a hard metal ball, hits a test surface at a defined impact energy. The impact of the hard metal ball on the test surface results in a plastic deformation of the surface at the point of impact. This deformation results in an energy loss which is proportional to the hardness of the workpiece and which can be determined by means of the ratio of...

ULTRASONIC HARDNESS TESTER PCE-3500 TECHNICAL SPECIFICATIONS Non-destructive hardness measurement The UCI hardness tester PCE-3500 has been designed for the non-destructive hardness measurement of metallic components. The UCI hardness tester works on the basis of the Ultrasonic Contact Impedance test procedure. The UCI procedure works as follows: a Vickers diamond at the probe is excited at the resonant frequency. By pressing the probe onto the surface, the vibration frequency is reduced, depending on the hardness of the surface and on the modulus of elasticity of the material and of the...

CONDUCTIVITY TESTER FOR NFE METALS PCE-COM 20 TECHNICAL SPECIFICATIONS with wide measurement range of up to 112 % IACS or 65 MS/m The conductivity tester for measuring the electrical conductivity of non-ferrous metals such as aluminium or copper belongs to the group of NDT devices. The conductivity tester is used in non-destructive material testing. By means of the eddy current measuring principle which has proven for this application, the electrical conductivity of metallic materials can be determined quickly and precisely. With its operating frequency of 60 kHz, the conductivity tester...

COATING THICKNESS GAUGE PCE-CT 80 TECHNICAL SPECIFICATIONS Paint layer thickness gauge for Fe and NFe The paint layer thickness gauge PCE-CT 80 is a measuring device for the non-destructive measurement of coatings (lacquers, paints, plastics ...) on steel / iron and non-ferrous metals. Thanks to the externally connected sensor on the PCE-CT 80 paint coating thickness gauge, even difficult-to-reach measuring locations can be easily reached. The menu naviga tion of the paint thickness gauge allows easy adjustment and setting to new parameters and makes this handy paint coating thickness gauge...

WALL THICKNESS GAUGE PCE-TG 300 WITH BLUETOOTH TECHNICAL SPECIFICATIONS with a wide measurement range of up to 600 mm The PCE-TG 300 is a wall thickness gauge with special probes for various applications. In general, the wall thicknesses of all homogeneous materials can be measured with the PCE-TG 300. For damping or scattering materials such as plastic or cast iron, a special probe is available. An angled 90 ° probe also enables measurements at hard-to-reach measuring positions. The speed of sound can be set freely and thus adapted to a wide variety of materials. The measured values are...

FORCE GAUGE PCE-DFG N 500 TECHNICAL SPECIFICATIONS digital force gauge for tensile and compressive force measurement up to 500 N The PCE-DFG N 500 is a digital force gauge for tensile and compressive force measurement up to 500 N. It has a resolution of 0.1 N. The measured values are shown on a large display with backlight which is rotatable by 180 °. Therefore, reading the measured values correctly is possible in any position and at any time. The outstanding accuracy of ±0.1 % f. s. is confirmed by the factory calibration certificate that comes with the meter. In addition to the internal...

FORCE GAUGE PCE-DFG N 10K TECHNICAL SPECIFICATIONS with external measuring cell and USB interface for connection to a PC The force gauge measures both tensile and compressive forces with a very high resolution. Tensile and compressive forces are often measured in test laboratories, for example to determine the yield strength, the pull-off force and the force required to actuate a push-button or switch. The force gauge is supplied with an external measuring cell. The PCE-DFG N 10K force gauge can measure up to 10,000 N / 2,248 lbs. Models for 1,000 N / 225 lbs, 2,500 N / 562 lbs and 5,000 N...

TECHNICAL SPECIFICATIONS ROUGHNESS TESTER PCE-RT 1200 portable roughness tester for quick measurement of Ra, Rz, Rq and Rt Ra, Rz, Rq, Rt Ra, Rq: 0.005 ... 16.00 pm / 0.197 ... 629.921 pin Rz, Rt: 0.002 ... 200.0 pm / 0.079 ... 7874.016 pin 5 pm/ 196.850 pin diamond, 90 ° angled Max. recommended 4 mN (0.4 gf) 45 mm / 1.77" 15 mm / 0.59" inductive 0.25 mm / 0.8 mm / 2.5 mm 0.009" / 0.03" / 0.098" 0.135 mm/s at cut-off wavelength: 0.25 mm 0.5 mm/s at cut-off wavelength: 0.8 mm 1 mm/s at cut-off wavelength: 2.5 mm Reversing speed: 1 mm/s <±10 % <6 % OLED pm / pinch (switchable) micro USB...

VISUAL INSPECTION INDUSTRIAL BORESCOPE PCE-VE 1000 TECHNICAL SPECIFICATIONS Different cables can be attached / image and video recording The borescope PCE-VE 1000 is a versatile inspection instrument. Various camera cables with different features can be attached to the borescope. The large and high-resolution display which allows the user a good overview of the area to be inspected is a special advantage. The industrial borescope can record images and videos. The videos are saved along with an audio recording. Image resolution / format Video resolution / format Drop test Power supply 640 x...
