Milling Catalog 2006-2007

Product catalog summary

Introduction
This document is a catalog for carbide groove milling tools by HORN, highlighting their extensive experience in grooving applications. It provides a comprehensive range of products and detailed technical specifications.

Specifications

Groove milling by circular interpolation with cutting edge diameters from 0.697" to 0.803".
Depth of groove up to 0.138" and width up to 0.315" for special orders.
Carbide shank material for vibration resistance.
Recommended torque for inserts is 35-40 lbf-in for specific types.
Dimensions available in inches and millimeters.

Procedures

Repair services for damaged milling cutter shanks are available.
Shanks can accommodate both right and left-hand inserts.

Standards and Norms

Compliance with DIN 6535 standards for various shank types.
Inserts designed for positive axial location to enhance strength and productivity.

Recommendations

Use through coolant and Weldon clamping flat for optimal performance.
Verify price and delivery for items, distinguishing between standard and semi-standard.

Spare Parts

Specifications for Torx screws and drivers for each part number.
Detailed part numbers and dimensions for milling cutter shanks and inserts.

Cutting Data and Material Specifications

Recommended feed per tooth values for different diameters and materials.
Tables with hardness values and cutting speeds for various materials.

Procedures for Milling and Drilling

Guidelines for optimizing milling and drilling operations based on machine stability and toolholder power.
Emulsion recommended as the primary coolant, with alternatives for specific operations.

Safety Precautions
Emphasizes the importance of using safety shields, wearing protective glasses, and adhering to safety standards to prevent hazards from metal cutting operations.

Standards and Certifications
References to DIN ISO 513 for cutting material groups and certifications like DIN EN ISO 9001 and DIN EN ISO 14001.

Contact Information
Contact details for HORN offices in multiple countries, including phone numbers, email addresses, and websites.

Product Applications
Covers applications such as grooving, profiling, threading, and various milling techniques.

Conclusion
HORN emphasizes safety and adherence to standards, providing a resource for optimal tool performance.
