product overview TRANSPORT

www.partex.nu English September, 2010

PARTEX develops manufactures and markets marking systems for cables, wires, pipes, hoses and electric components. These systems are characterised by versatility, usefulness and quality. 70% of PARTEX products are exported and the company is represented in about 70 countries, either company subsidiaries or distributors. The PARTEX MARKING SYSTEMS are used in the electrical industry. Marking is as common in OEM, end-user and installation industries. Correctly carried out marking reduces costs of service and maintenance, reconstruction and extension, as well as loss of production. PARTEX marking...

- 2 - The demand for halogen free products started Every year more and more companies upgrade their installations with products that are halogen free. We at PARTEX aim to give you a halogen free alternative (ZEREX) to all our products. 17 of the periodic table. The term ”halogen” means ”saltformer” and compounds containing halogens are called ”salts”. All halogens have 7 electrons in their outer shells, giving them an oxidation number of -1. The halogens exist, at room temperature, in all three states of matter: State Halogen Solid Iodine, Astatine Liquid Bromine Gas Fluorine, Chlorine With halogen...

- 3 - PAZ is a closed wire marker that is available in different sizes. The different sleeves available as both single and multi character marking. The characters are printed with black etching ink with high resolution. The standard colours for PAZ are yellow and white, but other colours on request. PKZ is a cable marker that is available as both single and multi character marking. Single characters can be combined on a holder and mounted on the wire with cable ties. Multi character marker can be mounted on a holder, but can also be punched so that you can tread a cable tie through the marker....

- 4 - standards, many train manufacturers use PARTEX halogen free wire markers for their projects. They send us their wiring lists by email and in a matter of days they will receive the complete sets of pre-printed markers at their production site The markers are sorted and packed according to their requirements, making the application procedure quick, fail-safe and cost effective. users are seeing the value of marking. Contractors and installers see that they can add value to their services by including marking. The amount of time saved when a technician troubleshoot a properly administered...

• PA+ with unique patented grooves for readability. • Multi-character marking on one single sleeve. + Availible in PVC (PA+) or halogen free (PAZ) material. + Diameter range from 1.3 mm up to 16.0 mm + Can be printed on site with PARTEX printers or ordered customized with the marker information you want. (M2) PA+ / PAZ - WIRE MARKERS - 5 - • A cable marker that can be mounted on a holder and then mounted on a cable with cable ties. • The Cable marker can also be punched so that it can be mounted directly onto a cable with cable ties + Availible in PVC (PK) or halogen free (PKZ) material. + One...

- 6 - Many companies in the Track and Signal industry uses PARTEX as a supplier. They work with third rail and infrastructure maintenance for main line, metro and light rail systems. PARTEX has markers suited for all applications When laying new track or maintenance existing tracks these companies uses PARTEX PKS system. The AISI 316 steel has good resistance to heat, cold, corrosion, acids, chemicals etc. and this makes it an ideal marker to use for marking every cable along the tracks. The PKS system can be ordered as customized (M2) and we punch in the information you want on each text carrier....

• Marking can be carried out on site with the help of easy-to-use single-characters, sets. • Good resistance to heat, cold, corrosion, acids, chemicals etc. + The system comprises marker carriers with holes at either end or as slots for direct threading + AISI 316 PKS SINGEL CHARACTERS - 7 - • Text is stamped on the marker carriers themselves, to form complete multicharacter markers • Good resistance to heat, cold, corrosion, acids, chemicals etc. • One or two rows of text + The system comprises marker carriers with holes at either end or as slots for direct threading of + AISI 316 PKS MULTI...

- 8 - All trains need maintenance, from the simplest train to a bullet train. A train will not make any money during the time it is in maintenance. Therefore it is very important to repair the train and get it to haul cargo or passengers in the fastest way possible. One way to do this is to minimize the time the technician has to troubleshoot. Less time is needed if the cable systems aboard the trains are labeled correctly. Time and money is one thing, but the most important a system were the cables contain high voltage and not labeled at all? It is also very important to make sure that after...

• Compact, portable, ID printer for cable, wire and component marking on site. • Feeds, prints and cuts PARTEX PO/POZ (PO/POZ-02 to PO/POZ-07), PP, PPA and PHZ (PHZ032 to PHZ064) and self adhesive labels (PL) + Print: Ribbon, thermal transfer printing, + Speed: up to 25 mm/s, MK9 - Thermal transfer printer - 9 - • Compact heavy duty printer for high demand production for wire, cable and component marking. (PO, PHZ, PP, PK etc.) • MK10 - Thermal transfer printer • Feeds, cuts and prints on both sides of bulk • Compact heavy duty printer for high demand production for wire, cable and component...

- 10 - M2: Customized multi-character marking on one single sleeve Rational installation with one step mounting procedure saves time and marking costs. Selection between three packagings consisting of: 1. Semi detached unsorted sleeves in big loops. 2. Customized sorted according to project demands. 3. Sorted and put on a cardboard sheet for excellent overview, random picking and mounting order. The markers can be printed with black etching ink or on some products with laser. White and yellow are the standard colours, other colours on request. MARKING TYPES 1. Closed wire marking: PY, PA+/PAZ...
