Parker Hannifin France SAS
Quick Coupling Products

Quick Coupling Products

Product catalog summary

Overview: This document is a comprehensive catalog from Parker Hannifin Corporation, detailing their range of quick coupling products, including swivels, valves, diagnostic sensors, and equipment. It serves as a guide for selecting and ordering various types of couplings and related components.

Key Sections:

Pneumatic Quick Couplings: This section introduces pneumatic quick couplings and provides a selection and ordering guide. It includes various series such as the 20, 30, and 50 Series, each designed for specific interchange standards and applications.
Hydraulic Quick Couplings: This section covers hydraulic couplings, offering a detailed guide on selection and ordering. It includes general-purpose couplings, non-spill couplings, high-pressure couplings, and high-flow couplings, with specific series like the 60, 6600, and 4000 Series.
Instrumentation Couplings: Focuses on couplings used in instrumentation applications, detailing series like the CPI Series.
Connect Under Pressure Couplings: Describes couplings that can be connected under pressure, including the 59 and FET Series.
Thermoplastic Quick Couplings: Provides information on thermoplastic couplings, including the Spectrum Series.
Swivels: Details the PS and S Series swivels, including introduction, seal options, and ordering information.

Critical Information:

Safety Warning: The document emphasizes the importance of proper selection and use of products to prevent injury or damage.
Offer of Sale: Products are offered for sale under specific terms outlined in the 'Offer of Sale' section.
Locations: Lists the Quick Coupling Division locations in Minneapolis, MN, Grantsburg, WI, Chetek, WI, and Union City, PA.

Conclusion: The catalog serves as a vital resource for selecting and ordering Parker Hannifin's quick coupling products, ensuring users have the necessary information to make informed decisions based on their specific application needs.

Introduction: This document provides detailed information on various types of valves and pneumatic quick couplings manufactured by Parker Hannifin Corporation. It includes specifications, ordering information, and guidelines for selecting the appropriate products for specific applications.

Valves: Check Valves: The document outlines different series of check valves such as DT, CV, DC, CPIFF, S6C, 3C, and 2600 Series. Each series has specific ordering information and technical specifications. Pressure/Vacuum Relief Valves: Includes H1 & HM1 Series and PV Series with their respective ordering details. Thermal Bypass Valves: Details on the TH Series and how to order them.

Pneumatic Quick Couplings: Single Shut-Off Couplings: These are primarily used for pneumatic applications and come in three designs: general purpose/manual connect, general purpose/push-to-connect, and special purpose. The standard seal material is Nitrile, with other options available. General Ordering Information: Instructions on how to order coupler bodies and nipples, emphasizing the importance of specifying part numbers and checking thread or hose sizes. Checklist for Selecting Quick Couplings: A list of questions to consider when selecting quick couplings, such as functional requirements, maximum working pressure, and compatibility with system fluids.

Coupling Selection & Ordering Guide: This section provides a detailed guide on selecting the appropriate pneumatic couplings based on interchange, body size, connection style, material, locking mechanism, seal material, temperature range, and rated pressure. It includes a comprehensive chart for easy reference.

Appendices: Includes a Fluid Compatibility Chart, Part Number Index, Safety Guide, Offer of Sale, and Glossary of Terms to assist users in understanding and selecting the right products.

Warnings: The document contains warnings about exposure to chemicals like Lead, which are known to cause cancer and birth defects, urging users to refer to www.P65Warnings.ca.gov for more information.

Specifications:

20 Series Couplers: Available in 1/4", 3/8", and 1/2" sizes, with a rated pressure of 300 psi and a temperature range of -40º to +250º F. They feature a manual sleeve and single shut-off mechanism.
30 Series Couplers: Available in 1/4", 3/8", 1/2", and 3/4" sizes, also rated at 300 psi with the same temperature range. These couplers use a push-to-connect sleeve and single shut-off mechanism.
Rectus 21, 23, 30 Series: These couplers are designed for 1/8", 1/4", and 3/8" sizes, with rated pressures of 250 psi for 1/8" and 300 psi for larger sizes. They feature a push-to-connect sleeve and single shut-off.

Materials and Features:

Brass and steel construction with options for stainless steel components.
Standard seals are made of Nitrile, with options for Ethylene Propylene and Fluorocarbon for different temperature ranges.
Optional features include Sleeve-Lok, grip-ring sleeves, and various seal materials for enhanced performance.

Applications:

Commonly used with air compressors, pneumatic tools, water, grease, and paint applications.

Performance:

Performance graphs indicate air flow in SCFM against pressure drop in PSID for different inlet pressures (100 PSI and 80 PSI).

Warnings:

The document includes a Prop 65 warning about exposure to chemicals like Lead, which is known to cause cancer and reproductive harm.

Repair Kits:

Available for different body sizes and seal materials, with specific part numbers provided for easy reference.

Specifications:

Rectus Series: Available in 1/4 and 3/8-inch body sizes, these couplers are designed for industrial interchange nipples and feature a push-to-connect sleeve with single shut-off.
10 Series: Known for the Tru-Flate design, these couplers come in 1/4, 3/8, and 1/2-inch sizes, with a rated pressure of 300 psi and a temperature range of -40º to +250º F. They include options for brass bodies with steel sleeves and various seal materials.
50 Series: Interchangeable with ARO's 210 series, these couplers feature brass bodies and steel nipples, with a similar pressure and temperature range as the 10 Series.

Features:

Integral sleeve guard to prevent accidental disconnection.
Tubular valve design for high airflow with minimal pressure drop.
Optional materials include stainless steel springs and locking balls for corrosion resistance.

Applications: These couplings are suitable for use with air compressors, pneumatic tools, water, grease, and paint.

Warnings: The document includes a Proposition 65 warning about exposure to chemicals like lead, which can cause cancer and reproductive harm.

Performance Data: Graphs illustrate air flow in SCFM against pressure drop in PSID for different inlet pressures, highlighting the performance of various coupler sizes.

Repair Kits and Options: The document lists available repair kits and optional features, such as Sleeve-Lok and Grip-Ring sleeves, and provides part numbers for ordering.

Specifications:

UC Series: Compatible with Industrial Interchange, 10 series (Tru-Flate), and 50 series (ARO 210) style nipples. Features include sleeve guard, push-to-connect operation, and brass construction. Rated pressure: 150 psi; Temperature range: -40º to +250º F. Not recommended for vacuum service.
70 Series: Interchangeable with Lincoln’s “Long Stem” series couplings. Brass bodies and steel valves; nipples are steel. Rated pressure: 300 psi; Temperature range: -40º to +250º F. Not recommended for vacuum service.
Rectus 25 Series: High flow European interface, formerly RF Series. Nickel-plated brass couplers and steel nipples. Rated pressure: 300 psi; Temperature range: -4º to +212º F. Not recommended for vacuum service.
TL Series: Interchangeable with Schrader Twist-Lock style couplings. Brass bodies and steel sleeves; nipples are steel. Rated pressure: 300 psi; Temperature range: -40º to +250º F. Not recommended for vacuum service.
IH Series: Steel couplers with cylindrical valve for pneumatic use. Standard seal is nitrile; optional sleeve lock available. Working pressures vary by body size, up to 6500 psi for 1/4" size.

Warnings:

Products may expose users to chemicals including Lead, known to cause cancer and reproductive harm.

Applications:

Air compressors, pneumatic tools, water, grease, paint, and industrial air lines.

Additional Information:

Repair kits and optional materials are available for various series.
Contact Quick Coupling Division for availability and additional options.

Specifications:

Tool-Mate Series: Available in standard and exhaust styles, these couplers are lightweight, non-marring, and constructed with polyamide material. They feature push-to-connect operation and are designed for pneumatic tools and drop-down air lines. Rated pressure is 300 psi with a temperature range of 0 to 160º F.
E-z-mate Series: Designed for safe disconnection at zero pressure, these couplers feature a self-locking valve sleeve and meet ISO 4414 requirements. They are available in sizes from 1/4" to 3/4" with a rated pressure of 300 psi and a temperature range of -40º to +250º F.

Performance:

Graphs indicate air flow in SCFM against pressure drop in PSID for different sizes and configurations, demonstrating the efficiency of the couplings under various conditions.

Safety and Compliance:

Products may expose users to chemicals like Lead, which is known to cause cancer and birth defects. Users are advised to refer to www.P65Warnings.ca.gov for more information.

Applications:

These couplings are suitable for use with pneumatic tools, drop-down air lines, and small gas appliances. The GF Series is specifically designed for natural and propane gas applications, featuring a safety fuse nipple to prevent gas-fed fires.

Ordering Information:

Detailed part numbers and configurations are provided for each series, including port sizes, body sizes, and thread types.

Introduction: Parker Straight-Thru couplings are designed for maximum flow applications with no valves in either half, minimizing pressure drop and allowing thorough cleaning. Fluid flow should be shut off before disconnection.

Rated Pressure: The rated pressure for Parker hydraulic couplings ranges from 30 to 15,000 psi, depending on series, size, and materials. These pressures are based on ISO 5598 standards and laboratory tests. High cycling rates and shocks can reduce coupling life.

Selection Considerations: When selecting quick couplings, consider functional requirements, maximum working pressure, seal and body material compatibility, application type (static or dynamic), coupler size, pressure drop, connection under pressure capability, media and ambient temperature, end configurations, industry interchange requirements, and concerns about air inclusion and fluid loss.

General Purpose Couplings: Includes various series such as 60, 6600, H, PH, EA, SM, HP, 4000, and 4200, each with specific features like poppet or ball valving, material compatibility, and pressure ratings.

Non-Spill Couplings: Designed to minimize fluid loss, these include the NS, NSS, FF/FC, FEM/FEC, and FS series, with flush face designs and various pressure ratings.

Connect Under Pressure Couplings: These couplings, such as the 59, FET, 6100, 8200, 9200, and 5000 series, allow connection under pressure with specific thread and ball designs.

High Pressure Couplings: Includes the 71, FH, 3000, TC, and 1141 series, designed for pressures up to 10,000 psi with various valving styles.

High Flow Couplings: The ST series offers unvalved designs for high flow applications with pressures ranging from 2,500 to 6,700 psi.

Conclusion: For detailed specifications and assistance, refer to the Parker catalog or contact the Quick Coupling Division in Minneapolis.

Overview: The document is a technical guide from Parker Hannifin Corporation's Quick Coupling Division, detailing specifications and options for hydraulic quick couplings, specifically the 60 Series, which comply with ISO 7241 Series B standards.

Specifications: The 60 Series couplings are designed for a variety of hydraulic applications, offering features such as poppet valves, metal-to-metal valve stops, and a range of material options including steel, brass, and stainless steel. They are suitable for dynamic applications with normal to moderate hydraulic shocks and are impulse tested at 125% to 133% of rated pressure.

Seal Material Options: Various seal materials are available, including Ethylene Propylene, Fluorocarbon, and Neoprene, each suitable for different series and temperature ranges. The standard seal for brass, steel, and 303 stainless steel couplings is Nitrile (-40°F to +250°F), while Fluorocarbon (-15°F to +400°F) is standard for 316 stainless steel couplings.

Applications: These couplings are versatile for use in industrial hydraulic lines, food and chemical processing, water and coolant lines, and mobile equipment. They can also be used with some gases.

Performance Data: The document includes performance graphs showing pressure drop versus flow rate for different body sizes, tested with oil at 150 SUS and 200 SUS.

Materials and Features: Optional materials and features include valve actuators, Sleeve-Lok, and heavy-duty steel nipples. The document provides part numbers and descriptions for these options.

Repair and Replacement Parts: The document lists repair kits and replacement parts for couplers and nipples, including O-rings and back-up rings for various body sizes.

Warnings: A Prop 65 warning is included, indicating that the product can expose users to chemicals known to cause cancer and reproductive harm.

Overview: This document provides detailed specifications and features of Parker Hannifin Corporation's hydraulic quick couplings, specifically the 6600 Series and H & PH Series. These couplings are designed for various hydraulic applications, offering features like poppet valves, manual sleeves, and compatibility with ISO standards.

6600 Series Specifications:

Body sizes range from 1/4 to 1 inch.
Standard seal material is Ethylene Propylene, with a temperature range up to +400°F.
Features include poppet valves, metal-to-metal valve stops, and hardened coupler sleeves for damage resistance.
Applications include steam systems, cleaning equipment, truck trailer connections, and mobile applications.
Rated flow and pressure vary by size, with the 1/4 inch size rated at 0.8 gpm and 5000 psi, and the 1 inch size rated at 50 gpm and 4000 psi.

H & PH Series Specifications:

Available in sizes from 1/4 to 4 inches, with materials including steel, brass, aluminum, and 316 stainless steel.
Standard seal material is nitrile, with options for fluorocarbon and ethylene propylene.
Features include a manual sleeve, poppet valve, and optional sleeve lock to prevent accidental disconnection.
Designed to MIL-C 51234 standards, suitable for industrial hydraulic lines, water and coolant lines, and mobile equipment.
Working pressures vary by material and configuration, with steel offering the highest ratings.

Performance and Applications:

The 6600 Series is versatile for hydraulic applications requiring frequent connection and disconnection.
The H & PH Series offers both valved and unvalved options, with the PH version allowing connection under pressure.
Applications include industrial hydraulic lines, mobile equipment, and systems requiring double or single shut-off couplings.

Warnings:

Products may expose users to chemicals like Lead, known to cause cancer and reproductive harm. More information is available at www.P65Warnings.ca.gov.

Additional Information:

Repair kits and replacement parts are available for various body sizes and configurations.
Optional materials and features can be specified using part number suffixes, such as sleeve lock or different seal materials.

Overview: This document provides detailed specifications for Parker Hannifin Corporation's hydraulic quick couplings, specifically the H & PH Series and EA Series. These couplings are designed for general-purpose hydraulic applications and are available in various materials including stainless steel, aluminum, brass, and steel.

Specifications:

H Series Couplers: Available in valved and non-valved options, with female and male threads. Sizes range from 1/4" to 2" with various port end configurations such as NPTF, NPSF, and UNF.
PH Series Connect-Under-Pressure Couplers: Designed for applications requiring connection under pressure, available in steel with female threads.
EA Series Couplings: Designed for vacuum and medium pressure service, featuring single and double shut-off combinations. Pressure ratings vary by material and size, with maximum working pressures up to 3000 psi for steel and stainless steel.

Warnings: The document includes a Proposition 65 warning indicating that some products may expose users to chemicals known to cause cancer and reproductive harm.

Applications: These couplings are suitable for various applications including aircraft fabrication, plastic molding, and dewatering.

Performance Data: The document provides flow rate and pressure loss data for the EA Series, indicating performance under different conditions.

Repair Kits and Replacement Parts: Available for the EA Series, with options for different seal materials such as nitrile and fluorocarbon.

Additional Information: For further details, users are directed to contact the Quick Coupling Division or refer to the Fluid Compatibility Chart for selecting appropriate seal materials.

Overview: The document provides detailed specifications and options for various series of hydraulic quick couplings manufactured by Parker Hannifin Corporation. It includes information on materials, types, sizes, and optional seal materials for couplers and nipples, as well as performance data and warnings related to chemical exposure.

Seal Materials: The document lists optional seal materials for couplers and valved nipples, including Fluorocarbon (VEAN4-4FV), Ethylene Propylene (EPR, VEAC6-6ME), and Aflas (VEAC6-6FAS). These materials are identified by specific suffixes added to part numbers.

Material and Type Options: Couplers and nipples are available in different materials such as Steel, Aluminum, Brass, and 316 Stainless Steel. They can be valved (V) or plain (P), with various body sizes ranging from 1/4" to 3/4".

EA Series Specifications: The EA Series includes couplers and nipples with female and male threads, available in brass, steel, and stainless steel. The document provides part numbers, port end specifications, and dimensions for each size and type.

SM Series Specifications: The SM Series features high-pressure manual sleeve, poppet valve hydraulic quick couplings. It includes specifications for body sizes 1/4", 1/2", and 3/4", with rated pressures up to 6000 psi and temperature ranges from -40° to +250°F. Performance graphs illustrate flow rates and pressure drops.

HP Series Specifications: Designed for high-pressure applications up to 5000 psi, the HP Series includes couplers and nipples in sizes 1" and 1-1/2". The document details part numbers, thread sizes, and dimensions, along with performance data.

4000 Series Specifications: The 4000 Series is suitable for agricultural machinery and rugged applications, with body sizes from 1/4" to 1". It features manual sleeve, poppet/ball valve options, and protective zinc plating. Performance graphs show flow rates and pressure drops.

Warnings: The document includes warnings about exposure to chemicals such as Lead and DEHP, which are known to cause cancer and birth defects. Users are directed to www.P65Warnings.ca.gov for more information.

Overview: The document provides detailed specifications and features of various series of hydraulic quick couplings manufactured by Parker Hannifin Corporation. These couplings are used in a range of applications including agricultural machinery, construction equipment, and high-tech industry cooling applications.

4000 Series Couplers: This series includes ISO 5675 nipples with manual sleeve and poppet/ball valve options. The couplers are designed for general-purpose hydraulic applications. A warning is included about potential exposure to chemicals like Lead.

4200 Series Couplers: Designed for rugged applications, these couplers feature a push/pull/breakaway sleeve and are compatible with ISO 5675 universal tips. They are suitable for hydraulic loaders and tools, with a rated pressure of 3000 psi and a temperature range of -40°F to +250°F.

NS Series Couplers: These non-spill couplings minimize spillage and air inclusion. They are made of steel with nitrile seals and are suitable for hydraulic hand tools and mining equipment. The series supports a rated pressure of 2500 psi and includes various standard port configurations.

NSS Series Couplers: High flow, stainless steel couplings designed for minimal fluid loss and low air inclusion. They are ideal for cooling lines and chemical transfer lines, with a rated pressure of 2000 psi for 3/8" and 300 psi for 1/2" sizes. The couplers feature corrosion-resistant construction and easy push-to-connect operation.

Key Features and Applications: The document highlights features such as non-spill valving, corrosion resistance, and high flow rates. Applications include hydraulic tools, utility equipment, and high purity systems.

Warnings: The document includes warnings about exposure to chemicals known to cause cancer and reproductive harm, directing users to www.P65Warnings.ca.gov for more information.

Overview: This document provides technical specifications and details for Parker Hannifin's hydraulic quick couplings, specifically focusing on the NSS, FF, FC, and FEM series. These couplings are designed for various hydraulic applications, offering features like non-spill valving and connect-under-pressure capabilities.

NSS Series Nipples:

Designed for use with Parker Push-Lok hoses, eliminating the need for clamps.
Specifications include body size, part number, port end, length, largest diameter, wrench flats, and weight.
Available in different configurations such as A-Lok compression fittings, bulkhead mount, and panel mount.

FF Series Couplings:

Features include flush, non-spill valving, hardened steel sleeves, and a sleeve-lock mechanism to prevent accidental disconnection.
Complies with Hydraulic Tool Manufacturers Association standards.
Specifications cover body size, rated pressure, flow, temperature range, spillage, air inclusion, body material, sleeve type, and seal material.

FC Series Connect Under Pressure Nipples:

Allows connection under pressure up to 3000 psi.
Features include hardened locking surfaces and blow-out resistant seals.
Specifications include body size, rated pressure, connect-under-pressure capability, flow, spillage, and air inclusion.

FEM Series Couplings:

Meets ISO 16028 standards with global interchangeability.
Features flush, non-spill valving and a modular design for increased flexibility.
Specifications include body size, rated pressure, flow, temperature range, spillage, air inclusion, body material, sleeve type, and seal material.

Warnings:

Products may expose users to chemicals like Lead, known to cause cancer and reproductive harm.
For more information, users are directed to www.P65Warnings.ca.gov.

Applications:

Hydraulic tools, mobile equipment, industrial hydraulics, and skid loader attachments.

Overview: This document provides technical specifications and guidelines for Parker Hannifin's quick action couplings, specifically the FEM and FEC series. It includes details on design, performance, and safety standards.

Specifications:

Meets ISO16028 standards.
Operating pressure: 5000 PSI (345 BAR).
Pressure drop: 14.5 PSI (1 BAR) max at 6.1 GPM (23 L/MIN).
Temperature range: -13°F (-25°C) to 212°F (100°C).
Seal materials: Polyurethane and Nitrile.
Plating: Zinc Nickel for corrosion resistance.

Product Details:

FEM Series Nipples: Available in various sizes with different port configurations such as NPTF, UNF, and BSPP.
FEC Series: Designed for connect-under-pressure applications, suitable for construction equipment with up to 3000 PSI trapped pressure.
FH Series: High-pressure, non-spill couplings with a rated pressure of 10,000 PSI, featuring push-to-connect operation and red finish for easy identification.

Performance and Features:

FEC Series: Connect-under-pressure capability, hardened locking surface, and anti-blowout bonded nipple seal.
FH Series: Flush face valves to minimize spillage and air inclusion, with a standard sleeve lock to prevent accidental disconnection.

Applications:

FEC Series: Ideal for hydraulic attachments in skid steer applications.
FH Series: Suitable for hydraulic crimpers, cutters, rescue equipment, and high-pressure test equipment.

Warnings: The product contains chemicals known to cause cancer and birth defects, as per California's Proposition 65.

Overview: The document provides detailed specifications and features of Parker Hannifin Corporation's hydraulic quick couplings, focusing on the 59 Series, FET Series, 6100 Series, and 8200 Series. These couplings are designed for high-pressure, high-impulse applications, offering secure threaded connections and the ability to connect under pressure.

59 Series Specifications: This section lists various nipple and coupler part numbers, detailing their port end sizes, lengths, diameters, wrench flats, weights, and rated pressures. The 59 Series is designed for pressures up to 6000 psi, with body sizes ranging from 1/2" to 1-1/2".

FET Series Features: The FET Series couplings are non-spill, screw-to-connect types that can connect under residual pressure up to 5000 psi. They are made from high-strength materials with FNC coating for durability and corrosion resistance. Applications include mobile drill rigs and oil field equipment.

FET Series Specifications: The document provides detailed specifications for FET Series couplers and nipples, including body sizes, port ends, lengths, diameters, wrench flats, and weights. The series supports pressures up to 6000 psi and temperatures from -40º to +250ºF.

6100 Series Overview: This series features threaded connections with flush valves for high flow. It is designed for pressures up to 3000 psi and includes features like a visual connection indicator and rugged wing nut sleeves. Applications include submersible pumps and oil field equipment.

8200 Series Features: The 8200 Series allows connection under pressure with a unique valve design. It accepts ISO 5675 universal tips and is suitable for tractors and mid-sized agricultural equipment. The series supports a rated flow of 12 gpm and pressures up to 3000 psi.

Warnings: The document includes a warning about exposure to chemicals like Lead, which is known to cause cancer and reproductive harm, with a reference to the California Proposition 65 warning.

Overview: The document provides detailed specifications and features of various series of hydraulic quick couplings manufactured by Parker Hannifin Corporation. These couplings are designed for high-pressure hydraulic applications and are used in various industrial and mobile equipment settings.

8200 Series: This series includes couplers and replacement parts designed for push/pull/breakaway operations. They accept ISO 5675 nipples and are suitable for connecting under pressure. The series features protective zinc plating and is not recommended for gaseous media.

9200 Series: These couplers allow zero pressure connection and disconnection, featuring a lever-operated cam for locking valves. They are designed to replace double shut-off quick couplings and high-pressure ball valves. The series is suitable for mobile equipment and industrial hydraulics.

5000 Series: Known for its economical design, this series allows connection under pressure using manual threaded actuation. It is suitable for lubrication systems and hydraulic tools, featuring protective zinc plating.

75 Series: This rugged series is designed for high-pressure hydraulic service, particularly in oil fields and offshore drilling. It features thread-to-connect couplings with a maximum working pressure of up to 5,000 psi. The series includes options for "Fire Safe" rated couplings and various seal materials.

Key Features and Applications: The document highlights the compatibility with ISO 5675 universal tips, protective coatings, and various seal material options. Applications include mobile equipment, industrial hydraulics, cranes, and power tongs.

Warnings: The document includes a warning about exposure to chemicals like lead, which can cause cancer and birth defects, as per California's Proposition 65.

Overview: The document provides detailed specifications and features of Parker Hannifin Corporation's hydraulic quick couplings, focusing on the 71 Series and 3000 Series. These couplings are designed for high-pressure applications and are available in various materials and sizes.

71 Series Specifications:

Designed for working pressures up to 10,000 psi (690 bar).
Features include flush face/non-spill design, push-to-connect operation, and heavy-duty construction.
Available in steel, 316 stainless steel, and high-pressure stainless steel.
Applications include industrial hydraulic lines and offshore drilling.
Pressure ratings vary by body size and material, with maximum working pressures ranging from 5,000 to 10,000 psi.

3000 Series Specifications:

Designed for high-pressure applications with manual threaded connection and actuation.
Features hard chrome alloy ball valves and polyurethane interface seals.
Protective zinc plating with clear trivalent chromate finish.
Applications include hydraulic rams and portable hydraulic tools.
Rated pressure up to 10,000 psi with a temperature range of -22°F to +230°F.

TC Series Specifications:

Used in high-pressure applications with hydraulic and mechanical shock.
Features manual sleeve operation and fluorocarbon seals.
Rated pressure up to 10,000 psi and rated flow of 6 gpm.
Applications include hydraulic jacking and construction equipment.

Warnings: The document includes a Prop 65 warning indicating that the product can expose users to chemicals, including lead, which is known to cause cancer and birth defects.

Ordering Guide: Provides detailed part numbers and configurations for ordering, including material, series, coupling half, body size, end fitting size, and seal options.

Overview: The document provides detailed specifications and features of various hydraulic quick coupling series by Parker Hannifin Corporation, including the ST Series, HO Series, and Moldmate Series. These couplings are designed for high-pressure applications and are used in various industries such as offshore equipment, hydraulic lines, and mold coolant lines.

ST Series:

Features: Made from 303 stainless steel, rated for pressures up to 10,000 psi, with polyurethane seals for abrasion resistance. Includes self-locking threads and a visual connection indicator.
Applications: Offshore equipment and hydraulic lines in corrosive environments.
Specifications: Available in sizes from 1/8" to 1-1/2", with rated pressures varying by material and size. Temperature range for standard seals is -40º to +250º F.

HO Series:

Features: High flow, high pressure steel couplings with electroless nickel plating for corrosion resistance. Nitrile seals with PTFE backup ring, rated up to 15,000 psi.
Applications: Paper and pulp processing, refinery systems, and testing systems.
Specifications: Available in sizes 1/4", 3/8", and 1/2", with rated flow up to 12 GPM.

Moldmate Series:

Features: Designed for connecting coolant lines to molds and dies, with options for valved and non-valved couplers. Made from brass with silicone seals, rated for 200 psi.
Applications: Mold coolant lines and die casting equipment.
Specifications: Available in sizes 1/4", 3/8", and 1/2", with rated flow up to 12 GPM. Temperature range for standard silicone seals is -20° to +400° F.

Warnings: The document includes a Prop 65 warning about exposure to chemicals like Lead, which can cause cancer and birth defects.

Additional Information: The document provides part numbers, dimensions, and weights for various couplers and nipples, along with optional materials and features for customization.

Overview: The document provides detailed specifications and ordering information for Parker Hannifin's hydraulic quick couplings, specifically focusing on the Moldmate and DM Series. These couplings are designed for use in various applications, including mold coolant lines and miniature hydraulic systems.

Specifications: The Moldmate Series features brass bodies with silicone seals, suitable for mold coolant applications. The DM Series offers miniature couplings with double shut-off and push-to-connect features, rated for 250 psi and suitable for dental equipment, lubrication lines, and fluid transfer.

Components: The document lists various components such as couplers, nipples, and sub-assemblies, detailing their sizes, weights, thread sizes, and other dimensions. It distinguishes between valved and non-valved options, as well as Push-Lok and standard hose barbs.

Materials and Safety: The couplings are primarily made of brass, with some components available in stainless steel. A warning is included about the presence of lead, which is known to cause cancer and reproductive harm, in compliance with California's Proposition 65.

Ordering Information: Instructions are provided for ordering coupler bodies and nipples, emphasizing the need to specify part numbers and check thread or hose sizes. Optional features and seal materials are also discussed, with a chart provided for selecting appropriate seals based on application needs.

Performance and Applications: The DM Series is highlighted for its performance in high-pressure applications, with a flow rate of 0.8 gpm and a temperature range of -15°F to +400°F. The document also includes a test port coupling selection guide for diagnostic applications.

Overview: The document is a technical catalog from Parker Hannifin Corporation's Quick Coupling Division, detailing various hydraulic products, specifically focusing on the PD, PDP, and EMA3 series couplings used for diagnostic and condition monitoring applications.

PD Series Couplings:

Designed for easy connection of mechanical gauges and diagnostic equipment.
Features include flush-face poppet valves to minimize air inclusion and spillage, grip-tight knurled sleeves for easy handling, and high tensile steel nipples for strength.
Specifications include a rated pressure of 6000 PSI, temperature range from -40°F to +250°F, and various optional seals.

PDP Series Couplings:

Similar to PD series but designed to connect under full system pressure up to 6000 PSI.
Features include a push-to-connect mechanism with a constant force of six pounds and a durable ball valve nipple.
Specifications include a rated pressure of 6000 PSI and a temperature range from -40°F to +250°F.

EMA3 Series Couplings:

Used for diagnostic connections with Parker SensoControl® equipment.
Features a twist-to-connect design, rugged construction for connect-under-pressure operation up to 5800 PSI, and a maximum rated working pressure of 9000 PSI.
Specifications include a compact design, Chromium-6 Free plated steel body, and a temperature range from -15° to +250°F.

Key Specifications and Features:

All series offer various thread sizes and materials, including steel, brass, and stainless steel options.
Optional seals and dust caps are available for enhanced protection and compatibility.
Each series is designed to meet or exceed specific industry standards such as SAE J1502 and ISO 15171-1.

Ordering Information:

Products can be ordered with different body materials and seal options, indicated by specific prefixes and suffixes in part numbers.
Detailed part numbers and specifications are provided for each coupling type, including dimensions and weight.

Overview: The document provides detailed technical specifications and product information for various hydraulic components offered by Parker Hannifin Corporation's Quick Coupling Division. It includes data on hose assemblies, couplings, diagnostic fittings, thermoplastic quick couplings, and swivels.

Hose Assemblies: The document lists hose assemblies with part numbers, lengths in inches and millimeters, and coupling types. For example, the PDH-19 has a length of 19 inches (483 mm) with a PD coupling.

Hydraulic Products: This section covers couplings, test port couplings, transducer adapters, and flexible hoses. It includes specifications such as thread size and maximum pressure ratings, with test hoses rated up to 9000 psi.

Fluid Sampling: Diagnostic fluid sampling products are designed for easy access to fluid samples without shutting down systems. Specifications include a body size of 1/8, rated pressure of 500 PSI, and a temperature range of -40° to +250° F.

Diagnostic Fittings: Parker's in-line diagnostic tees are compatible with SensoControl diagnostic couplings and are available in ORFS and 37° flare configurations. They feature elastomeric sealing and are adaptable to various diagnostic and fluid sampling tips.

Thermoplastic Quick Couplings: The Spectrum Series offers advanced engineered thermoplastic couplings with features like chemical compatibility, high flow capacity, and a four-point locking mechanism. They are available in valved and unvalved options, with materials such as Acetal/SS and PVDF/PEEK™.

Swivels - PS Series: Designed for dynamic applications, the PS Series Swivels offer pressure capabilities up to 5000 psi and feature hardened bearing races, full flow design, and Chromium-6 Free plating for corrosion resistance. They are available in body sizes from 3/8 to 1 inch.

Key Chains and Promotional Products: Quick Coupling Key Chains are available in various colors and materials, including anodized aluminum and nickel-plated versions. A warning is included regarding exposure to chemicals like Lead.

Introduction: The document introduces the Parker Hannifin Corporation's S Series Swivels and various valve products, designed for hydraulic systems. The S Series Swivel is highlighted for its pressure-balanced, compact forged body design, which minimizes torque increase with pressure rise and reduces hose twist and stress.

Specifications and Features: The S Series Swivel features a 3000 psi working pressure rating, nitrile seals, and dust seals for environmental protection. It offers a 360° swivel to eliminate hose stress and a compact design for tight spaces. Repair kits are available for maintenance.

Performance Data: The document provides performance data for different swivel sizes (1/4”, 3/8”, 1/2”, 3/4”) with a focus on pressure drop versus flow rate.

Ordering Information: Details on how to order the S Series Swivels are provided, including part numbers and port configurations.

Valve Products: The document also covers various valve products, including check valves and thermal bypass valves. Check valves are used to prevent back pressure damage in hydraulic systems, while thermal bypass valves ensure efficient operation by modulating fluid temperature.

Check Valves: Parker's check valves are available in several series, each with specific features such as metal or soft seats, various pressure ratings, and crack pressure settings. The DT Series is noted for its compact design and high operating pressure.

Safety Warning: A warning is included about the potential exposure to chemicals like Lead, which is known to cause cancer and reproductive harm, in compliance with California's Proposition 65.

Overview: The document provides detailed specifications and features of various series of check valves manufactured by Parker Hannifin Corporation. These include the DT, CV, DC, and CPIFF series, each designed for specific applications and pressure ratings.

DT Series Check Valves:

Available in sizes from 1/4" to 1-1/4".
Constructed from steel with a pressure rating between 2500-5000 psi.
Crack pressure ranges from 5 to 200 psi.
Different fitting styles include Male Flare, Male O-Ring Boss, and Male Face Seal.
Flow data charts indicate pressure drop across various sizes using oil as the test fluid.

CV Series Check Valves:

Designed for low pressure drop and high flow.
Sizes range from 1/4" to 1" with a maximum operating pressure of 3000 psi.
Standard crack pressures are 5 and 65 psi, with other options available.
Features include nitrile O-ring, all-steel construction, and modular design.

DC Series Check Valves:

Rugged and cost-competitive, available in sizes from 1/4" to 2".
Pressure rating up to 3000 psi with flow capacities up to 300 GPM.
Features include all-steel construction, one-piece body, and optional crack pressures.

CPIFF Series Check Valves:

Soft seat design for positive shut-off to prevent reverse flow.
Available in sizes from 1/4" to 1" with a pressure rating up to 5000 psi.
Standard fluorocarbon poppet seal with optional crack pressures.

Warnings:

Products may expose users to chemicals like Lead, known to cause cancer and reproductive harm.

Ordering Information:

Includes series, size, fitting style, and crack pressure options.
Custom crack pressures available upon request.

Overview: The document provides detailed technical specifications and features of various check valves and pressure/vacuum relief valves manufactured by Parker Hannifin Corporation's Quick Coupling Division. It includes information on materials, pressure ratings, flow rates, and specific applications for each valve series.

Check Valves - C Series: The S6C and 3C Soft Seat Check Valves are designed to prevent reverse flow in hydraulic systems. The S6C series is made of stainless steel with a pressure rating of 6000 psi, while the 3C series is made of steel with a pressure rating of 3000 psi. These valves are available in sizes ranging from 1/4” to 2” with various crack pressure options.

2600 Series Swing Check Valves: These lightweight aluminum valves are suitable for low-pressure applications, such as fuel lines and lubrication systems. They feature a trapdoor style valve with a maximum crack pressure of 1/2 psi and are available with Nitrile or Fluorocarbon seals.

Pressure/Vacuum Relief Valves - H1 and HM1 Series: These valves maintain positive pressure in hydraulic reservoirs and feature a reusable bronze filter. The HM1 series includes a manual pressure relief option. They offer pressure relief settings from 5 psi to 50 psi.

PV Series Pressure/Vacuum Relief Valves: Designed for use in contaminated environments, these valves feature a large filter area and can be mounted in the tank filler port. They offer pressure relief settings from 5 psi to 30 psi.

Thermal Bypass Valves - TH Series: These valves regulate fluid temperature by directing flow through a cooler or bypassing it. They include an integral pressure relief function and are suitable for hydrostatic drive circuits. The valves are available with various shift temperatures and crack pressure settings.

Appendices: The document includes a fluid compatibility chart to assist in selecting appropriate seal materials and body materials for specific applications. It emphasizes the importance of considering operating and environmental conditions when selecting quick couplings.

Safety Guide for Selecting and Using Quick Coupling Division Products:

Introduction:
This document provides a comprehensive safety guide for selecting and using Quick Coupling Division (QCD) products and related accessories. It emphasizes the importance of proper selection and usage to prevent potential hazards such as high-speed ejection of parts, fluid discharge, and explosions.

1. Scope and User Responsibility:
The guide outlines the scope of instructions for selecting, installing, connecting, disconnecting, and maintaining QCD products. Users are responsible for ensuring the suitability of products for their specific applications and must provide appropriate safety warnings.

2. Product Selection Instructions:
- Pressure: Ensure the rated pressure of QCD products is equal to or greater than the system's maximum pressure.
- Fluid Compatibility: Verify compatibility of product materials with the fluid media.
- Temperature: Ensure fluid and ambient temperatures do not exceed product limitations.
- Size: Select appropriate sizes to minimize pressure losses and avoid damage.
- Environment: Protect products from environmental conditions that could cause degradation.
- Locking Means: Consider sleeve lock designs to prevent accidental disconnection.
- Mechanical Loads: Account for external forces that could reduce product life.
- Specifications and Standards: Follow applicable specifications and standards.
- Vacuum and Fire Resistant Fluids: Ensure products are suitable for vacuum service and compatible with fire-resistant fluids.

3. Installation Instructions:
- Pre-Installation Inspection: Inspect products for correct style and material before installation.
- Fitting Installation: Use compatible thread sealants and avoid excessive torque.
- Caps and Plugs: Use dust caps and plugs to protect uncoupled products.
- Quick Coupling Location: Position couplings for safe access during connection and disconnection.

Conclusion:
This safety guide is essential for ensuring the safe and effective use of QCD products. Users must thoroughly understand and apply the instructions provided to prevent accidents and ensure system integrity.

QCD Product Maintenance Instructions:

Maintenance is crucial for extending the life of QCD products. The frequency of maintenance should be based on application severity and risk potential.
Visual inspections are necessary to identify conditions requiring immediate shutdown and replacement, such as cracks, leaks, or broken hardware.
Functional tests should be conducted at maximum operating pressure to check for malfunctions and leaks, ensuring personnel safety.
Replacement intervals should be determined based on service life, recommendations, or risk of failure.

Offer of Sale Terms:

All sales are governed by specific terms, including price validity, payment terms, and shipment details.
Products are warranted against defects for specified periods, with disclaimers on other warranties.
Claims must be reported promptly, and liability is limited to the purchase price of the products.
Confidential information shared by the seller must be kept confidential by the buyer.
Special tooling remains the property of the seller, and the buyer is responsible for compliance with all instructions and specifications.
Force majeure events relieve the seller from liability for delays or failures to perform obligations.
Termination of agreements can occur with notice or immediately under certain conditions.

Intellectual Property Rights and Liability: The seller is not liable for infringement of intellectual property rights unless specified. The seller will defend and cover costs for claims against the buyer regarding product infringement in the delivery country, contingent on timely notification and control over the defense. Options include procuring usage rights, modifying products, or refunding with depreciation. Exclusions apply for buyer-provided information or designs, and modifications or combinations by the buyer.

Governing Law: The terms are governed by Ohio law, with disputes resolved in Cuyahoga County courts.

Entire Agreement: The terms and any quote form the complete agreement, overriding prior agreements. Modifications require written consent from the seller.

Compliance with Laws: The buyer must comply with applicable laws, including U.S. regulations, and indemnify the seller against violations. The buyer must not engage in improper payments or actions that would cause legal violations.

Technical Glossary: Definitions related to quick disconnect couplings, including terms like burst pressure, case hardening, and rated pressure, are provided to clarify technical specifications.

About Parker Hannifin Corporation: Parker Hannifin is a global leader in motion and control technologies, offering products for various industries. The company emphasizes engineering expertise and customer service.

Product Information: Parker provides a wide range of products, including fittings, hoses, and couplings, available globally through a network of distributors and service centers.

Catalog excerpts

Quick Coupling Products Quick Couplings, Swivels, Valves, Diagnostic Sensors and Equipment Catalog 3800 USA | November 2022 PDF Update: June 3, 2024 FOR MOST UPDATED CATALOG SCAN WITH CAMERA

Open the catalog to page 1

Quick Coupling Division Locations FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE. • This document and other information from Parker-Hannifin Corporation, its subsidiaries and authorized distributors provide product or system options for further investigation by users having technical expertise. • The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and...

Open the catalog to page 2

Table of Contents Pneumatic Quick Couplings Hydraulic Quick Couplings General Purpose Couplings * UC Series is a replacement for the HA Series. Parker Hannifin Corporation Quick Coupling Division Minneapolis, MN www.parker.com/quickcoupling

Open the catalog to page 3

Parker Hannifin Corporation Quick Coupling Division Minneapolis, MN www.parker.com/quickcouplings

Open the catalog to page 5

Single Shut-Off Couplings General Ordering Information Single Shut-Off couplings are primarily used for pneumatic applications, connecting air tools, hoses, or other implements to compressed air supplies. They are also used with other gases, and with the exception of the E-z-mate Series can be used with low pressure fluids. The coupler half contains a shut-off valve that is automatically opened when a mating nipple is inserted and automatically closes when the nipple is removed. When ordering Parker coupler bodies and nipples, please state the part number of each type of coupler body and each...

Open the catalog to page 6

Parker Hannifin Corporation Quick Coupling Division Minneapolis, MN www.parker.com/quickcoupling

Open the catalog to page 7

Pneumatic Coupling Selection Guide (by Interchange) Body Sizes (in.) Connection style Locking Mechanism Std Seal Temp Range Rated Pressure Coupler Series Industrial Interchange Couplers General Purpose 1/4 to 1/2 Manual Sleeve Universal Series Tool-Mate (PBS) (non-marring, exhaust) E-z-mate (exhaust) Universal Series Universal Series Tru-Flate Interchange Couplings 1/4 to 1/2 1/4 Manual Sleeve Manual Sleeve Lincoln “Long Stem” Interchange Couplings 1/4 Manual Sleeve Common High-Flow European Interchange Couplings 1/4 Tool-Mate (PES) (non-marring, exhaust) Schrader Twist -Lock Interchange Couplings...

Open the catalog to page 8

Pneumatic Coupling Selection Guide - continued Pneumatic Coupling Selection Guide Body Sizes (in.) Connection style Locking Mechanism Std Seal Temp Range Rated Pressure Coupler Series Special Purpose - Natural and Propane Gas Couplings 1/4 to 1-1/4 Manual Sleeve Spectrum Series Finger Lock Nitrile or Fluo- 0° to +180° F rocarbon 0° to +250° F * Material Code: B = Brass, S = Steel, SS = Stainless Steel, P = Plastic ** Spectrum Series material options: • Acetal/316SS • PVDF/316SS (subject to quote from the division) • PVDF/PEEK™ (subject to quote from the division) WARNING: This product can expose...

Open the catalog to page 9

Pneumatic Quick Couplings General Purpose Interchange Match-up Chart Parker’s Quick Coupling Division manufactures quick couplings to interchange with popular designs that have become accepted standards in the industry today. The actual size nipple chart below can be used to help select Parker Quick Couplings that will interchange with specific nipple designs and sizes. 10 Series (Tru-Flate Automotive Interchange) 20 Series, 30 Series, Rectus 21, 23, 30 Series, E-z-mate (Industrial Interchange) 1/4” Body Size 1/8” Body Size 1/4” Body Size 3/8” Body Size 1/4” Body Size 70 Series (Lincoln Interchange)...

Open the catalog to page 10

Industrial Interchange Nipples A-A-59439, MIL- C-4109F Design Pneumatic Quick Couplings General Purpose Non-valved, straight through Parker Industrial Interchange Nipples are compatible for use with 20 Series, 30 Series, Rectus 21, 23, 30 Series, Universal or E-z-mate couplers. The standard male tip of the pneumatic industry, these nipples are interchangeable with similar nipples manufactured to the same requirements. Features: • Conforms to A-A-59439 (MIL-C-4109F, ISO 6150-B) requirements for global interchangeability • Steel nipples have hardened wear points and load-bearing areas • Unvalved...

Open the catalog to page 11

Industrial Interchange Nipples A-A-59439, MIL- C-4109F Design Pneumatic Quick Couplings General Purpose Non-valved, straight through Body Size Nipples - Male Pipe Thread Part Number Stainless Steel (303)** Thread Size Exposed Length* Largest Diameter Wrench Flats Part Number Brass Part Number Steel Nipples - Standard Hose Barb Body Size Part Number Brass Part Number Steel H8C Part Number Stainless Steel (303) ** Exposed Length* Largest Diameter * This dimension represents the portion of the nipple that is exposed when the nipple is connected to a Parker 20 Series coupler. **Prop 65 Warning does...

Open the catalog to page 12

Industrial Interchange Nipples A-A-59439, MIL- C-4109F Design Pneumatic Quick Couplings General Purpose Non-valved, straight through Nipples - Push-Lok Hose Barb** Body Size Part Number Brass Part Number Steel Exposed Length* Largest Diameter * This dimension represents the portion of the nipple that is exposed when the nipple is connected to a Parker 20 Series coupler. * *Push-Lok hose barbs are designed for use with Parker Push-Lok hose and do not require clamps. WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth...

Open the catalog to page 13

20 Series Couplers Accepts Industrial Interchange Nipples Pneumatic Quick Couplings General Purpose 20 Series Pneumatic Couplers mate with Industrial Interchange nipples, the standard male tip of the pneumatic industry. Available options include Sleeve-Lok, stainless steel locking balls and springs, and grip-ring sleeve. Features: • Mates with Industrial Interchange nipples manufactured to A-A-59439 (MIL-C-4109F, ISO 6150-B) global standards • 1/4” body size has a brass body and steel valve, 3/8” body size has all steel construction • Tubular valve delivers high flow with minimal pressure drop...

Open the catalog to page 14
