PAIXIE Product Catalogue
17Pages

Shanghai Paixie Packing Machinery Co.. Ltd

COMPANY INTROE UCTION Shanghai Paixie Packaging Machinery Co..Ltd. Dedicated to packaging machinery,packaging equipment design, manufacturing and sales, is specialized in automated packaging machinery products development production, sales and service in one of the manufacturing company;Main types of packaging machinery, packaging equipment. filling machines, semiautomatic,fully automatic filling production line and all kinds of filling equipment, auxiliary equipment. For the Chinese food pharmaceutical, cosmetic, lubricants, cosmetics and other industries to provide grain tling machine...

AUTOMATIC E-LI^U Application and Description: The Automatic E-liquid filling line is specially used in the process of fully automatic bottle sorting,bottle washing,filling, capping,labeling,packing for glass and plastic bottles. Paixie makes everyone trust the machinery made in China

MACHINEApplication and Description: This machine is designed for filling e-liquid into 5-120 mL plastic and glass bottles. It integrates a high-precision cam indexing mechanism, rotary dial positioning filling, inner plug insertion, and outer cap screwing. Equipped with a servo motor for adjustable torque capping and a peristaltic pump or piston pump for metered filling, it features touchscreen control with "no bottle, no filling" logic (omitting inner plugs and caps if bottles are absent). Benefits include smooth operation, precise positioning, accurate dosing, and user-friendly operation....

MACHINE Application and Description: This machine is designed for filling essential oils into 5 - 120 mL glass bottles. It consists of a high-precision cam indexing mechanism, rotary dial positioning filling, dropper insertion, and outer cap screwing. Featuring servo motor-driven adjustable torque capping and metered filling via peristaltic or piston pumps, it offers touchscreen control with "no bottle, no filling" logic (skipping dropper and cap placement if bottles are absent). The system ensures smooth operation, precise positioning, accurate dosing, and user-friendly performance....

NAIL POLISH FILLING MACHINEIntroduction: The filling method of the equipment adopts the precision piston pump filling type, the material contact part is ceramic material or 316L stainless steel, the brush and the outer cap are grasped by the robot, the capping head adopts the three-claw type,and the servo motor is used to control the torsion force to ensure the rotation. The tightness of the cover is consistent, and the torque can be adjusted in the man-machine interface,which is convenient and quick. Features: 1. The machine is widely used in the daily chemical industry. It is suitable for...

FILLING MACHINE Introduction: PX-LFM4-2-2 eye drop filling linkage line is a new product developed by our company in recent years It uses metering filling with peristaltic pump (ceramic pump for special occasions),automatic pressure inner plug and pressure outer cover, screw cap,automatic visual analysis function, in line with GMP verification requirements. Features: 1. Touch screen setting,peristaltic pump for filling, easy cleaning, no pollution,ceramic pump can also be used for special occasions. 2. Can achieve accurate fine-tuning of the filling amount on the touch screen. 3. Filling...

Washing, filling and capping production line for paste like ketchup and peanut butter Purpose and Introduction： The production line is a new product which imports advanced technology from abroad and is twice developed by our team.It integrates machinery, electronics and pneumatic. The production line consists of bottle washing system, bottle drying system, linear multi-head filling system, vacuum capping machine, labeling and packing system. It has high automation, high yield, wide applicability and is favored by users. The production line can automatically complete bottle management,...

Introduction(General Production Line): The production line can automatically complete bottle management, bottle washing, filling, capping, and other functions. It offers high filling accuracy, long service life, high-temperature resistance, and acid and alkali resistance. It is suitable for the production of granular sauce, thick sauce, paste, and semi-fluid. 1. It uses a volumetric piston pump and a pneumatic control rotary valve for filling, making it applicable to various viscous materials. The servo-controlled piston pump allows for convenient and reliable measurement adjustment. 2. The...

ROUND SHAPE LABELING MACHINE Suitable for automatic labeling of round bottle products in food, medicine, daily chemical and other light industries. One machine can be used for multiple purposes, both standalone and online. 1. An advanced and user-friendly human-machine interface system, with simple and intuitive operation, complete functions, and rich online help functions. 2. By adjusting, one machine can complete various specifications of cylindrical surface labeling. 3. The machine is designed with a convenient and adjustable mechanism for bottles of different diameters and heights to...

Double sided labeling machine Suitable for automatic double-sided labeling of flat, square, and round bottle products in food, medicine, daily chemical, and other light industries. 1. One machine is versatile and suitable for both square and flat bottles. It can be used as a standalone device or for online use. 2. An advanced and user-friendly human-machine interface system, with simple and intuitive operation, complete functions, and rich online help functions. 3. One machine can complete double-sided labeling for four types (square bottle, flat bottle, round bottle, irregular bottle) and...

SLEEVE SHRINK LABELING This machine uses servo motors, PLC programmable controllers, and frequency converters,The unique touch screen is more user-friendly to operate. 1. This labeling machine is suitable for various bottle types. It not only has high precision in labeling position, but also can highlight the perfect shape of the bottle after shrinking. 2. Highly stable mechanical structure: The entire machine adopts stainless steel protective frame cover and aluminum alloy body frame, which is stable and rust free. 3. Unique synchronous cutter holder, within the specification range, no...
